Using gRPC Bidirectional Streaming Without Dropping Idle Connections

The problem: real-time updates over a request that never ends

You need a client and server to exchange messages as they happen—chat messages, telemetry, or cursor positions in a collaborative editor. A unary gRPC call handles one request and one response, but the client would have to poll or open new connections for every update. That adds latency and head-of-line blocking.

gRPC bidirectional streaming lets both sides send a sequence of messages over one long-lived HTTP/2 connection. HTTP/2 is the protocol gRPC uses over TCP; it allows multiple streams to share a single connection. The trade-off is operational: long-lived streams are more likely to be killed by idle timeouts, load balancers, or proxy settings that assume short request-response lifecycles.

Takeaway: use bidirectional streaming when both sides need to push data without waiting for a request, but configure keep-alive and timeouts explicitly or the connection will drop silently.

Defining a bidirectional stream in Protocol Buffers

A .proto file marks both request and response as streams using the stream keyword:

syntax = "proto3";

package chat;

service ChatService {
  rpc SendMessage(stream ChatMessage) returns (stream ChatMessage);
}

message ChatMessage {
  string user = 1;
  string text = 2;
  int64 sent_at = 3;
}

The stream keyword on both sides means the client can send many messages and the server can send many messages, independently and interleaved, over a single HTTP/2 stream.

Worked example: server and client handlers

Generate language-specific stubs from the proto file. Run this in your project root:

protoc --go_out=. --go-grpc_out=. chat.proto

Required permissions: write access to the output directory. Required tools: protoc, the Go protobuf plugin, and the Go gRPC plugin. Risk: generated code overwrites existing files with the same package and service names.

On the server, the handler receives a stream object. It reads incoming messages in a loop and writes replies back:

func (s *server) SendMessage(stream chat.ChatService_SendMessageServer) error {
  for {
    msg, err := stream.Recv()
    if err == io.EOF {
      return nil
    }
    if err != nil {
      return err
    }
    // process or broadcast msg here
    if err := stream.Send(&chat.ChatMessage{User: "server", Text: "ack"}); err != nil {
      return err
    }
  }
}

On the client, open the stream once, then run a sender goroutine and a receiver goroutine:

stream, err := client.SendMessage(ctx)
// sender goroutine: stream.Send(msg)
// receiver goroutine: stream.Recv()

Expected check: messages sent by the client arrive at the server, and server replies arrive at the client without opening a new RPC call for each message. You can verify this with BloomRPC or grpcurl by opening a bidirectional call and observing interleaved messages.

Operational limits: keep-alive, proxies, and load balancing

Because the stream stays open, idle connections are the most common failure mode. Intermediate proxies often close TCP connections after a few minutes of silence. If your client stops sending but expects server pushes, the connection may close without either side noticing until the next send fails.

Configure client keep-alive so the transport sends HTTP/2 PING frames periodically:

conn, err := grpc.NewClient(
  "localhost:50051",
  grpc.WithKeepaliveParams(keepalive.ClientParameters{
    Time:                15 * time.Second,
    Timeout:             5 * time.Second,
    PermitWithoutStream: true,
  }),
)

PermitWithoutStream: true allows pings even when no application messages are in flight. Place this where the client creates its gRPC connection, typically during service startup. Risk: overly frequent keep-alive can waste bandwidth and may be rejected by some load balancers.

Load balancing is another limit. A long-lived stream usually stays pinned to one backend pod, so round-robin at connection setup does not spread message load evenly across pods. If one client streams heavily, that pod carries more load. Consider client-side load balancing or a service mesh that understands gRPC routing.

Memory usage grows with concurrent streams. Each open stream holds buffers and goroutine state. Set server-side limits on concurrent streams and message size to protect against runaway memory consumption.

Practical verification

• Open a bidirectional call with BloomRPC or grpcurl and send messages from both sides. Confirm messages arrive in near real time.
• Stop sending from the client for longer than your proxy’s idle timeout. Confirm the connection stays alive due to keep-alive pings, or observe the exact error code when it does close.
• Check server memory and goroutine count under sustained concurrent streams to validate your resource limits.

When to choose a different pattern

Use unary RPCs for request-response actions like creating a record or fetching a profile. Use server streaming when only the server pushes updates. Use bidirectional streaming when both sides need to send freely. If your infrastructure cannot support long-lived HTTP/2 connections or your load balancer does not pass gRPC headers correctly, fall back to polling unary calls or WebSockets.

Closing

Bidirectional streaming is powerful for low-latency, two-way communication, but it shifts complexity from the application protocol to network operations. Define the stream in proto, generate code, implement reader/writer loops, then tune keep-alive and timeouts before deploying to production.
