Using F# Discriminated Unions to Model Domain States Safely

Problem: Modeling domain states without missing cases

When you model domain concepts such as user account status, order processing steps, or game entities, you often end up with a set of distinct states. Using strings, integers, or scattered boolean flags makes it easy to forget a case or to introduce invalid combinations. The compiler cannot help you spot missing handling, which leads to runtime bugs that are hard to trace.

How discriminated unions help

A discriminated union (also called a tagged union or algebraic data type) lets you declare a closed set of shapes, each with its own associated data. The F# compiler knows every possible case and can check that you handle them all when you pattern match. This replaces long if‑else chains or visitor patterns with a clear, declarative match expression.

Worked example: calculating the area of a shape

type Shape =
    | Circle of radius:float
    | Rectangle of width:float * height:float
    | Triangle of sideA:float * sideB:float * angle:float

let area shape =
    match shape with
    | Circle r -> System.Math.PI * r * r
    | Rectangle (w, h) -> w * h
    | Triangle (a, b, ang) -> 0.5 * a * b * System.Math.Sin(ang)

If you omit one of the branches, for example the Triangle case, the compiler emits warning FS0025: "Incomplete pattern matches on this expression. For example, the value 'Triangle (_,_,_)' is not matched." This warning appears at compile time, so you cannot ship code that forgets a case.

Trade‑offs and limitations

• Very large discriminated unions with many alternatives produce long match expressions. When a union grows beyond a handful of cases, consider splitting it into smaller, related unions or using active patterns to group logic.
• Serializing a discriminated union to JSON is not straightforward. The default representation (e.g., {"Circle":5.0}) varies by serializer and may not be what external systems expect. You typically need a custom System.Text.Json converter that encodes each case with a tag property, such as {"type":"Circle","radius":5.0}.

Actionable next steps

1. Create a new F# console project: dotnet new console -lang F# -n DomainModel
2. Add the union and the area function shown above to a file such as Program.fs.
3. Build the project: dotnet build. Verify that the build succeeds.
4. Experiment: comment out the Triangle branch in the match expression and rebuild. You should see warning FS0025 indicating an incomplete match.
5. Restore the branch, then add a new case, for example | Ellipse of rx:float * ry:float, and rebuild. The compiler will flag the existing area function as incomplete, prompting you to update it.
6. For JSON serialization, add a System.Text.Json converter that writes a "type" discriminator and the associated fields. Test the converter with a unit round‑trip to ensure the produced JSON matches the expected format.

By using discriminated unions you gain a compile‑time safeguard that keeps your domain model consistent as it evolves, while keeping the code concise and expressive.
