Using Dynamic Supervision in Elixir for Scalable WebSocket Connections

Problem: managing a varying number of WebSocket connections

When a server accepts WebSocket connections, the number of active clients can rise and fall unpredictably. Creating a fixed pool of worker processes at compile time either wastes resources when traffic is low or risks exhausting the system when traffic spikes. Elixir’s supervision tree offers a way to add and remove workers at runtime without restarting the whole supervisor.

Thesis: dynamic supervision lets you start child processes on demand while keeping fault isolation

By using Supervisor.start_child/3 with a :one_for_one strategy, each WebSocket connection runs in its own child process. If a single connection crashes, only that child is restarted (or left stopped, depending on the restart policy), and the supervisor itself continues to manage other connections.

Worked example: a minimal WebSocket connection supervisor

1. Create a new Mix project: mix new ws_demo --sup
2. Add a simple GenServer that represents a connection (in lib/ws_demo/connection.ex):

   defmodule WsDemo.Connection do
     use GenServer

     # client‑side API
     def start_link(_) do
       GenServer.start_link(__MODULE__, :ok, name: via_tuple())
     end

     defp via_tuple() do
       {:via, Registry, {WsDemo.Registry, make_ref()}}
     end

     # server callbacks
     def init(:ok) do
       {:ok, %{}}
     end

     def handle_info(:timeout, state) do
       {:noreply, state}
     end
   end

3. Define a registry to look up connections by a unique reference (in lib/ws_demo/registry.ex):

   defmodule WsDemo.Registry do
     use Registry, keys: :duplicate, names: :local
   end

4. Create the supervisor that will dynamically start children (in lib/ws_demo/supervisor.ex):

   defmodule WsDemo.Supervisor do
     use Supervisor

     def start_link(_) do
       Supervisor.start_link(__MODULE__, :ok, name: WsDemo.Supervisor)
     end

     def init(:ok) do
       children = []
       opts = [strategy: :one_for_one, name: WsDemo.Supervisor]
       Supervisor.init(children, opts)
     end

     # helper to start a new connection child
     def start_connection() do
       spec = {
         WsDemo.Connection,
         [],
         [id: WsDemo.Connection, restart: :temporary]
       }
       Supervisor.start_child(WsDemo.Supervisor, spec)
     end
   end

5. Start the supervisor in your application (lib/ws_demo/application.ex):

   defmodule WsDemo.Application do
     use Application

     def start(_type, _args) do
       children = [WsDemo.Supervisor, WsDemo.Registry]
       opts = [strategy: :one_for_one, name: WsDemo.Application]
       Supervisor.start_link(children, opts)
     end
   end


6. When a new WebSocket handshake succeeds, call WsDemo.Supervisor.start_connection() from your socket module. The supervisor spawns a fresh WsDemo.Connection process without restarting itself.

Trade‑offs and limitations

• Runtime overhead: Each call to start_child/3 incurs a small supervision cost. For extremely short‑lived tasks (e.g., fire‑and‑forget messages), a Task pool or :poolboy may be more efficient.
• Restart intensity limits: The supervisor’s max_restarts and max_seconds apply to all its children. If many connections fail rapidly, the supervisor itself can shut down, taking down the whole service. Adjust these values in the child spec or use a :transient restart policy to avoid cascading restarts.
• Visibility: Dynamically added children do not appear in the module’s static child list, so tools like observer show them only after they start. Monitoring must therefore rely on the supervisor’s internal state or a registry.

Actionable closing

If your workload consists of long‑lived, connection‑oriented processes such as WebSocket channels, dynamic supervision gives you the elasticity you need while preserving fault isolation. Start with a :one_for_one supervisor, use :temporary or :transient restart policies, and monitor restart intensity. For high‑frequency, short‑lived jobs, consider a task pool instead.
