Using Akka Typed Actors to Eliminate Unhandled Messages

Why use Akka Typed Actors

Typed actors give each actor a single message type, so the compiler can verify that every possible message is handled. This removes the need for runtime pattern matches on untyped ActorRef and reduces the chance of unhandled messages.

Worked example: a simple counter

sealed trait CounterCmd
case object Increment extends CounterCmd
final case class GetValue(replyTo: ActorRef[Int]) extends CounterCmd

val counterBehavior: Behavior[CounterCmd] = Behaviors.setup { ctx =>
  var count = 0
  Behaviors.receiveMessage {
    case Increment =>
      count += 1
      Behaviors.same
    case GetValue(replyTo) =>
      replyTo ! count
      Behaviors.same
  }
}

val system = ActorSystem(Behaviors.empty, "counter-demo")
val counter = system.spawn(counterBehavior, "counter")
counter ! Increment
counter ! GetValue(replyTo = system.ignoreRef) // replace with a test probe in real code

How the typed behavior works

The Behavior[Msg] defines a state transition function. Behaviors.setup creates the actor instance and provides a context for spawning children or accessing the system. Behaviors.receiveMessage processes each incoming message of type Msg and returns the next behavior, enabling immutable or mutable state updates.

Configuration considerations

Typed actors inherit the same dispatcher and mailbox settings as untyped actors. You can override them in application.conf:

akka.actor.default-dispatcher {
  type = Dispatcher
  executor = "thread-pool-executor"
  thread-pool-executor.fixed-pool-size = 16
}
my-bounded-mailbox {
  mailbox-type = "akka.dispatch.BoundedMailbox"
  mailbox-capacity = 1000
  mailbox-push-timeout-time = 10s
}

Assign the mailbox to an actor:
val counter = system.spawn(counterBehavior, "counter", Props.empty.withMailbox("my-bounded-mailbox"))

Limits and common mistakes


Blocking calls inside a Behavior – Using Thread.sleep or synchronous I/O occupies dispatcher threads, reducing throughput and can cause deadlocks, especially in a cluster. Replace blocking work with the ask pattern or offload to a dedicated blocking dispatcher.

Mixing typed and untyped APIs – Passing an UntypedActorRef to a typed actor or expecting an untyped ask to work with a Behavior leads to dead letters or unhandled messages. Keep the API boundary consistent.

Missing message case – If a Behavior does not handle a message type and is not defined with Behaviors.unhandled, the message is silently dropped. Enable akka.log-unhandled to detect this.

How to verify the example


Create an sbt project with Akka 2.6.x or 2.7.x dependency.

Place the code snippet in src/main/scala/CounterDemo.scala.

Run sbt run (requires read/execute permissions on the project directory).

Observe the console; the program should terminate without errors. To see the reply, replace system.ignoreRef with a test probe and print the received integer.

Practical check: enable akka.log-config-on-start = on and akka.log-dead-letters = 10 to see if any messages are dropped or sent to dead letters.
When to consider alternatives
If you need dynamic message handling or integration with legacy untyped code, the untyped API may be simpler, but you lose compile‑time safety. For high‑throughput, non‑blocking workloads, typed actors paired with Akka Streams provide back‑pressure and bounded mailboxes.
