Understanding Mithril’s Auto‑Redraw Mechanism: Architecture and Practical Use

Requirements

Mithril’s auto‑redraw feature must keep the view in sync with model changes that happen as a result of asynchronous work (e.g., network requests, timers, DOM events) without requiring the developer to call m.redraw() manually. It should also allow developers to suppress or batch redraws when performance is critical.

Smallest Suitable Design

The design consists of three parts:

1. Wrap – All Mithril‑provided asynchronous APIs (m.request, m.route resolvers, onmatch hooks) and DOM event handlers are wrapped so that, after the wrapped promise settles or the event callback finishes, a flag is set indicating that a redraw is needed.
2. Schedule – At the end of the current microtask queue, Mithril checks the flag. If set, it schedules a view update using requestAnimationFrame, ensuring the redraw happens just before the browser paints.
3. Control – Developers can temporarily disable the flag with m.redraw.sync(false) or bracket code with m.startComputation() / m.endComputation() to batch multiple state changes into a single redraw.

Trust/Data Boundaries

The auto‑redraw system trusts only the asynchronous entry points that Mithril itself wraps. Direct DOM mutations or state changes performed outside those wrappers (e.g., using element.textContent = … from plain JavaScript) do not trigger the flag, so the view may become stale unless the developer explicitly calls m.redraw(). Conversely, any change made through Mithril’s wrappers is guaranteed to be observed by the redraw scheduler.

Operational Checks

To verify that the mechanism works as expected in a component:

1. Create a component that fetches data in oninit using m.request.
2. Log a message in oncreate and again in onupdate.
3. After the request resolves, you should see the onupdate log, indicating the view redrew.
4. For manual control, wrap a series of rapid state changes with m.redraw.sync(false) before the changes and m.redraw.sync(true) after; only one onupdate log should appear.

Failure Modes

• Excessive redraws – If asynchronous calls are issued inside a tight loop without batching, each settlement will set the redraw flag, potentially causing a redraw per iteration. This can be mitigated by using m.redraw.sync or moving the loop outside of asynchronous boundaries.
• Stale view from direct DOM changes – Mutations that bypass Mithril’s wrappers do not set the flag, so the view will not update until the next automatic redraw from another source or an explicit m.redraw() call.
• Missed redraw if flag cleared early – If a developer mistakenly calls m.redraw.sync(false) and never restores sync, the view will never redraw again until sync is re‑enabled.

Conditions That Would Change the Design

The current design assumes a browser environment with a functional requestAnimationFrame and a microtask‑based event loop (as in modern browsers). If Mithril were to target a non‑browser runtime (e.g., server‑side rendering or a native UI bridge) where those primitives are absent or behave differently, the scheduling step would need to be replaced with an appropriate flush mechanism (e.g., a custom tick callback). Additionally, if the framework introduced a new primitive that bypasses the existing wrappers (such as a low‑level mutable store), the trust boundary would shift and the auto‑redraw logic would have to be extended to observe that primitive.
