Throttle Request Rates in Gatling Load Tests

Desired outcome

You need a Gatling simulation that generates a controlled request rate—ramping up to a target, holding it, then ramping down—so you can observe system behavior under a known load pattern rather than relying solely on virtual‑user concurrency.

Necessary prerequisites

• Gatling 3.7+ installed and available on the PATH (the throttle DSL is present from 3.0).
• A Scala build tool (SBT or Maven) or the standalone Gatling bundle for quick runs.
• A simple HTTP endpoint to test, e.g. a mock service returning 200.
• Basic knowledge of Gatling scenarios: exec, feed, http.
• Permission to execute the Gatling launcher and read the simulation sources.

Focused procedure

1. Create a scenario that performs the request you want to throttle. Example:

val scn = scenario("Throttled API")
  .exec(http("Get item"))
        .get("/items/${itemId}")
        .check(status.is(200))

2. Prepare a feeder or hard‑coded data if needed. For illustration a CSV feeder:

val feeder = csv("itemIds.csv").circular

3. Attach the feeder to the scenario:

val scnWithFeed = scn.feed(feeder)

4. Define the throttle injection profile. The following example ramps to 50 requests/second over 10 seconds, holds for 30 seconds, then ramps down to 0 over 10 seconds:

setUp(
  scnWithFeed.inject(
    nothingFor(5 seconds), // optional warm‑up
    rampUsersPerSec(1) to 50 during(10 seconds),
    constantUsersPerSec(50) during(30 seconds),
    rampUsersPerSec(50) to 0 during(10 seconds)
  ).protocols(httpConf)
)

If you prefer the explicit throttle DSL, you can write:

setUp(
  scnWithFeed.inject(
    rampUsersPerSec(1) to 50 during(10 seconds)
  ).protocols(httpConf)
   .throttle(
     reachRps(50) in(10 seconds),
     holdFor(30 seconds),
     jumpToRps(0) in(10 seconds)
   )
)

5. Place the simulation file under src/test/scala (SBT) or any folder read by the standalone launcher.
6. Run the test:
• SBT: sbt gatling:test
• Standalone: ./gatling.sh -s com.example.ThrottledSimulation

Expected checks

• Open the generated HTML report (results//index.html).
• In the “Requests per second” chart verify that the curve follows the ramp‑up, hold, and ramp‑down phases you defined.
• Check the “Global statistics” table: the total number of requests should be close to target_rps × hold_time + area under ramp triangles (e.g. 50 × 30 + 0.5×50×10 + 0.5×50×10 = 2000 requests).
• Ensure error rates are low; any spikes should be inspected against the target endpoint.

Recovery options

Symptom	Likely cause	Recovery action
Requests per second stay flat at the initial value	The throttle block was omitted or the scenario was not attached to the injector	Confirm that .throttle(...) or the rampUsersPerSec chain is present and that the scenario passed to inject includes the feeder.
Observed rate exceeds the configured target	Multiple injection profiles were added without throttling each, or the protocol level maxConnections is too high	Either apply throttle to every injector or consolidate them into a single throttled injection; review httpConf.maxConnectionsPerHost.
Test aborts with “java.lang.IllegalArgumentException: throttle must be positive”	A ramp target of zero or negative was supplied	Check the arguments to rampUsersPerSec or reachRps; ensure the final value is ≥ 0.
High error rates (5xx) during the hold phase	The target system cannot sustain the requested load	Lower the target RPS, increase ramp‑up/down times, or add think time (pause) inside the scenario.

Version considerations

Gatling 3.0 introduced the throttle DSL; earlier 2.x versions required manual shaping with constantUsersPerSec and rampUsersPerSec only. If you are on Gatling 3.5 or later the nothingFor warm‑up step is available; otherwise omit it. Always verify your installation with gatling -version before copying the snippet.
