Splitting a Ceylon Project into Multiple Modules

Decision and constraints

You are maintaining a Ceylon application and the source tree has grown past a few dozen files. You must decide whether to keep all code in one module declared in module.ceylon or split it into multiple modules with explicit imports. A Ceylon module is a named, versioned unit of code whose dependencies are declared explicitly rather than discovered by classpath scanning. The wrong choice makes refactoring slow or produces circular import errors that the Ceylon 1.3.x compiler reports only at build time.

Constraints in Ceylon 1.3.x:

• Every module needs a module.ceylon descriptor with a name, version, and import list.
• Module names should follow reverse-domain notation (for example, com.example.core) and match the directory layout.
• Only packages listed with export are visible to other modules.
• Code in the default package cannot be imported by another module.

Useful takeaway. Split code into separate modules when subsystems release independently or when you want to enforce dependency direction with compiler errors. Keep code in one module when everything ships together. Always pin dependency versions in module.ceylon so the toolchain resolves the same artifacts on every machine.

Supported options compared

Option	Best for	Visibility control	Build impact	Version coupling
Single module	Small applications and prototypes	Package-level shared only	One compile unit	None
Multiple modules, built together	Large codebase, single release train	Module boundary via export	Separate compile units, same version	High—changing one version requires editing every importer
Multiple modules, published separately	Shared libraries consumed by many applications	Module boundary via export	Independent builds	Low—consumers pin exact versions

Trade-offs

A single module is the simplest starting point. You avoid maintaining several descriptors, but you lose compiler-enforced boundaries between packages. Multiple modules give you stronger encapsulation: if com.example.app does not import com.example.core.internal, the compiler rejects the code even if both packages exist in the same repository.

The cost is version churn. Because Ceylon imports are versioned, bumping com.example.core from 1.0.0 to 1.0.1 means updating every module that imports it. In a large multi-module repository this can become tedious, which is why the separately published option only makes sense when modules genuinely have independent release cycles.

Concrete implementation: two modules

This example splits a tiny application into a library module and an application module. The source root contains two module directories.

com/example/core/
  module.ceylon
  com/example/core/Greeting.ceylon
com/example/app/
  module.ceylon
  com/example/app/Main.ceylon

The library module declares its name, version, SDK import, and exported package.

module com.example.core "1.0.0" {
    import ceylon.language "1.3.3";
    export com.example.core;
}

shared class Greeting {
    shared String sayHello() => "Hello, Ceylon";
}

The application module imports the library by module name and version.

module com.example.app "1.0.0" {
    import ceylon.language "1.3.3";
    import com.example.core "1.0.0";
}

import com.example.core {
    Greeting
}

shared void run() {
    print(Greeting().sayHello());
}

Commands and checks

Run these commands from the project root as a normal user with read access to the source files and write access to the compiler output directory (default is typically modules/ or output/, depending on your Ceylon setup).

1. Verify the toolchain version:

   ceylon version

   Expected: output identifying Ceylon 1.3.x. Module semantics changed between early milestones and 1.3.x, so do not assume 1.2 behavior applies.
2. Compile the application module:

   ceylon compile com.example.app

   Expected: exit code 0 and generated module output under the configured output directory.
3. Inspect the resolved module graph (if your toolchain provides it):

   ceylon doc com.example.app

   Expected: documentation listing com.example.core as an imported dependency.

Risks: if the directory path does not match the module name in module.ceylon, compilation fails with a module-not-found error. If com.example.core omits export com.example.core;, the application module cannot see Greeting. If the version constraint in the importer is too strict—for example, requiring "1.0.0" while the provider publishes "1.0.0+beta"—resolution fails even though the code is compatible.

Diagnostic decision table

Build failure	Likely cause	Check
module com.example.core not found	Directory name or descriptor name mismatch	Confirm module.ceylon declares com.example.core and the package lives under com/example/core/.
package com.example.core is not exported	Missing export statement	Add export com.example.core; to the provider's module.ceylon.
version constraint unsatisfied	Version string mismatch between importer and provider	Align the version in the provider descriptor with the constraint in the importer descriptor.

Limitations and verification

The Ceylon toolchain is not actively maintained at the level of mainstream JVM languages. Before relying on module resolution in a CI pipeline, run ceylon version on the build machine and pin that toolchain version. Changing a module version requires updating every importing module's descriptor, so prefer semantic versioning only when you can automate the update across the repository.

Practical verification: after editing descriptors, run ceylon compile and confirm exit code 0. Then run ceylon doc against the consuming module to confirm the imported module appears in the documentation. If the build breaks, revert the descriptor edits with your version-control system; there is no database or system state to roll back beyond the changed files.
