Spack Concrete Specs: Pinning Versions, Compilers and Build Options for Reproducible Builds

If you need the same binary layout on two machines, the useful answer is to stop installing from an abstract spec and commit a concrete spec. A concrete spec is Spack's fully resolved dependency graph with exact package versions, compilers, variants and hashes pinned. Once concretized, the same spec always maps to the same build.

What a concrete spec locks down

An abstract spec describes intent: hdf5 ^zlib %gcc. It leaves version, compiler version, and variant choices open. Concretization resolves those choices against the package registry, your installed compilers, platform, and existing constraints.

A concrete spec pins:

• package name and exact version
• compiler name and version
• variants and build options
• dependencies with their own pins

The result is a deterministic install plan. Spack stores it in the database and reuses it for spack install.

How concretization resolves a spec

Concretization evaluates the user spec, consults the package registry, and applies compiler, platform and constraint rules to select a mutually compatible set. Spack's concretizer is a constraint solver. It picks versions that satisfy dependencies, then chooses a compiler that satisfies all packages, and finally fixes variants.

Worked example. You want HDF5 1.14.3 built with GCC 13.2.0 and a specific zlib.

# Run in a shell where spack is initialized. No elevated permissions needed.
spack concretize hdf5@1.14.3 ^zlib@1.3.1 %gcc@13.2.0

The command is read‑only. It prints a concrete spec without building. For a project, pin the intent in spack.yaml:

spack:
  specs:
    - hdf5@1.14.3 ^zlib@1.3.1 %gcc@13.2.0
  concretization: together

Then run:

spack concretize -f spack.yaml

Expected checks: the output contains a fully specified node for hdf5 with version, compiler, and a hash, and a child node for zlib with its own pins. If you save the spec with spack spec --concrete --json you get a machine‑readable record you can commit.

Reading and verifying the result

Verify reproducibility by inspecting the concrete spec:

spack concretize hdf5@1.14.3 ^zlib@1.3.1 %gcc@13.2.0 --format yaml

Look for pinned fields: version, compiler, variants, and hash. A concrete spec will show no wildcards.

Compare across runs. With identical inputs, the same spec should produce the same compiler and version choices and the same content hash. Differences indicate a change in the package repository, compiler availability, or environment.

Limits, failures and common mistakes

Concretization fails when no compatible set exists. Common causes:

• Conflicting compiler requirements. One dependency requires %gcc@12: and another requires %clang@17:. Resolution requires explicit compiler selection or relaxing a version constraint.
• Platform mismatch. A package variant requires a library unavailable on your OS.
• Overly broad specs. hdf5 ^zlib without versions forces the solver to explore many combinations, increasing time and risk of non‑determinism.

Large dependency graphs cause long concretization times because the solver explores combinations exhaustively. Mitigate by narrowing constraints and pinning key versions.

Common mistake: assuming spack install will always pick the same compiler. It uses the environment's default unless you specify %compiler in the spec or set spack config defaults. Pin the compiler in the spec for reproducibility.

Practical habits for stable concretization

• Specify compiler and major versions explicitly for top‑level packages.
• Use spack concretize before install to review the graph without triggering builds.
• Commit the concrete spec or lockfile for projects. Re‑run concretization only after intentional changes.
• When a conflict appears, relax the least critical constraint first, then re‑concretize.

Concrete specs are the mechanism Spack uses to turn intent into a fixed, repeatable build. Pinning versions, compilers and variants, and verifying the YAML output is the practical way to keep environments identical.
