Solving Stale UI: Diagnosing Missing Redraws in Mithril.js

The Problem: State Updates Without UI Changes

In Mithril.js, you may encounter a scenario where your JavaScript state (the data) updates correctly, but the browser DOM remains unchanged. This typically happens when state mutations occur outside of Mithril's managed event loop, leaving the framework unaware that it needs to perform a virtual DOM diff and update the screen.

Diagnostic Matrix: Why the UI is Stale

Use this table to identify if your issue is a missing redraw cycle or a logic error in your component.

Symptom	State Value (Console)	DOM State	Likely Cause
UI doesn't update after API response	Updated/Correct	Old/Stale	External callback bypasses auto-redraw
Timer/Clock doesn't tick	Updated/Correct	Old/Stale	setInterval/setTimeout bypasses loop
UI doesn't update on click	Old/Incorrect	Old/Stale	Event handler logic error or state mutation failure
UI updates, then reverts	Correct	Flickering	Race condition or conflicting redraw calls

Step-by-Step Diagnostic Process

1. Verify State Mutation: Place a console.log() immediately after the line of code that modifies your state. If the log shows the new value but the screen is static, the problem is the redraw cycle, not your data logic.
2. Identify the Trigger Source: Determine what triggered the change. Mithril automatically triggers a redraw for events it manages (e.g., onclick, oninput). If the trigger is a WebSocket message, a setTimeout, or a third-party library callback, Mithril will not auto-redraw.
3. Check Lifecycle Placement: Ensure you aren't attempting to update state in a way that conflicts with the current rendering phase. Updates inside a render function are ignored or can cause instability.

Fixes Based on Findings

Scenario A: External Callbacks or Timers

When using setInterval or an external API callback, you must manually notify Mithril to synchronize the DOM.

// Example: A timer that updates a counter
let state = { count: 0 };

setInterval(() => {
    state.count++;
    // The state changes, but the UI stays the same without this call:
    m.redraw();
}, 1000);

Scenario B: Refactoring to Managed Events

To avoid scattering m.redraw() calls throughout your codebase, wrap external updates in a handler that ensures a redraw is scheduled. This keeps your business logic separate from the rendering trigger.

Implementation Risks and Constraints

Manual redraws are powerful but can introduce performance bottlenecks or application crashes if misused.

• Infinite Loop Risk: Never call m.redraw() inside a render function or a lifecycle hook that is triggered by a redraw (like oncreate or onupdate). This creates a recursive loop that will freeze the browser tab.
• Performance Degradation: Avoid calling m.redraw() inside high-frequency events such as onmousemove or onscroll. Constant virtual DOM diffing can lead to significant input lag.

Verification and Testing

To verify the fix, follow these steps:

1. Open Browser Developer Tools (F12) and navigate to the Elements tab.
2. Trigger the state change (e.g., wait for the timer or trigger the API call).
3. Observe the DOM elements. If the redraw is working, you will see the specific HTML nodes flash or update in the inspector.
4. Check the Console to ensure no "Maximum call stack size exceeded" errors appear, which would indicate an infinite redraw loop.

Rollback Procedure

If adding m.redraw() causes performance drops or crashes, remove the manual call and move the state mutation into a Mithril-managed event handler (e.g., moving a manual trigger into an onclick handler) to restore the default automatic redraw behavior.
