Shrink Your Java App Docker Image with Multi‑Stage Builds

Problem: Monolithic Docker Images

When you package a Java application into a single Docker image, the container usually contains the JDK, Maven/Gradle, build tools, and the compiled JAR. A typical image may end up between 200 MB and 1 GB. This bloat inflates deployment time, consumes network bandwidth, and expands the attack surface because every package is exposed to the running container.

Thesis: Multi‑Stage Builds Separate Build Artifacts

Docker’s multi‑stage build feature lets you define several named stages in one Dockerfile. The first stage (often called builder) pulls a full JDK image, runs the build, and produces the final JAR. The second stage starts from a lightweight runtime image (e.g., openjdk:17-jre-slim) and copies only the artifact produced by the builder. The resulting image contains only what the application needs at runtime, usually 3–10× smaller than the monolithic version.

Example Dockerfile

Below is a minimal Dockerfile that builds a Maven project and then packages it into a small runtime image. Replace my-app with your project name.

# syntax=docker/dockerfile:1
# Stage 1 – Build the application
FROM maven:3.9.6-openjdk-17 AS builder
WORKDIR /app
# Copy pom.xml and download dependencies first to leverage Docker cache
COPY pom.xml .
RUN mvn dependency:go-offline -B
# Copy source code and build
COPY src ./src
RUN mvn package -DskipTests -B

# Stage 2 – Runtime image
FROM eclipse-temurin:17-jre-jammy
WORKDIR /app
# Copy only the built JAR
COPY --from=builder /app/target/my-app-1.0.0.jar ./app.jar
# Expose the application port
EXPOSE 8080
ENTRYPOINT ["java","-jar","app.jar"]

Build Stage

• Uses maven:3.9.6-openjdk-17, which contains Maven, JDK, and all build tools.
• Copies pom.xml first to take advantage of Docker’s layer caching; if dependencies haven’t changed, this step is fast.
• Runs mvn dependency:go-offline to pre‑download all dependencies.
• Copies source code and runs mvn package to produce my-app-1.0.0.jar.

Runtime Stage

• Starts from eclipse-temurin:17-jre-jammy, a 70‑MB lightweight image that contains only the JRE.
• Copies the JAR from the builder stage using --from=builder.
• Sets the working directory, exposes port 8080, and defines the entrypoint.

Trade‑Offs & Limitations

Build Cache & Build Time

Multi‑stage builds can reduce cache hit rates if the Dockerfile is not structured carefully. For example, copying the entire source tree before downloading dependencies forces Docker to rebuild the dependency layer on every code change. The example above mitigates this by layering pom.xml first.

Missing Runtime Config

Only the JAR is copied into the runtime stage. If your application relies on external configuration files (e.g., application.yml), you must copy them explicitly. Otherwise the container will start but fail due to missing configuration.

Local Build Cache Leakage

When you build locally, the builder stage can contain sensitive artifacts (e.g., credentials from settings.xml). Ensure that such files are not copied into the final stage and that the builder stage is removed from the final image. The COPY --from=builder syntax only copies the specified files, so accidental leakage is unlikely if the Dockerfile is written correctly.

Actionable Next Steps

1. Verify Docker Version
   Run docker version and ensure the Engine is 17.05 or newer. The syntax=docker/dockerfile:1 line requires this feature.
2. Create the Dockerfile
   Place the example Dockerfile in the root of your project. Adjust the artifact name and runtime image as needed.
3. Build the Image
   ```bash # Build locally # Requires Docker Engine permissions # Replace demo-app with your image name docker build -t demo-app . ```

   Check the output for the FROM lines and the final ENTRYPOINT to confirm the syntax is accepted.

4. Compare Image Sizes
   ```bash # Size of multi‑stage image docker images demo-app --format '{{.Size}}' ```

   Build a single‑stage version (e.g., using openjdk:17-jdk-slim as the base) and run the same command. The multi‑stage image should be noticeably smaller.

5. Run the Container
   ```bash # Run the application docker run --rm -p 8080:8080 demo-app ```

   Verify that the endpoint (e.g., http://localhost:8080/health) returns the expected response.

6. Inspect Layers
   ```bash # Inspect the image layers docker image inspect demo-app ```

   Look for a single runtime layer containing only the JAR and any runtime dependencies.

7. Integrate into CI
   Update your CI pipeline to use the multi‑stage Dockerfile. The reduced image size will speed up build and deployment steps.
8. Monitor Runtime Security
   Run docker image inspect demo-app periodically to ensure no unexpected packages appear in the final image.

By following these steps, you’ll reduce image size, lower deployment costs, and tighten your security posture without sacrificing functionality. Happy building!
