Setting Latency Pass/Fail Criteria with k6 Thresholds

Problem: You need a clear, automated way to decide if a load test meets latency expectations

When running a load test, it’s easy to collect lots of numbers but harder to turn them into a go/no‑go signal for your CI pipeline. Without a pass/fail rule, you have to stare at charts or parse logs manually, which slows down releases and lets regressions slip through.

Thesis: k6 thresholds let you declare numeric limits on built‑in metrics (like average request duration) and automatically mark a test run as passed or failed based on those limits

Defining a threshold in the options object

Thresholds are plain JavaScript expressions that k6 evaluates after the test finishes. You attach them to the options object using the metric name, a comparison operator, and a target value. The most common latency metric is http_req_duration, which records the time for each HTTP request.

import http from 'k6/http';

export const options = {
  thresholds: {
    // fail if the average request duration is >= 200 ms
    http_req_duration: ['avg < 200'],
  },
};

export default function () {
  http.get('https://httpbin.org/delay/1');
}

Place this script in a file, e.g., latency-test.js, and run it with k6 run latency-test.js. The command needs only read access to the file and network access to the target endpoint; no special privileges are required.

Using multiple thresholds on the same metric

You can enforce several latency requirements at once by adding more strings to the array. Each string is evaluated independently, and the test fails if any of them fail.

export const options = {
  thresholds: {
    http_req_duration: [
      'avg < 200',          // average latency
      'p(95) < 500',        // 95th percentile
      'max < 1000',         // worst‑case request
    ],
  },
};

This gives you a layered safety net: the average must be fast, most requests must stay under half a second, and no single request may exceed one second.

Worked example: verifying a threshold passes and fails

1. Set a permissive threshold – average latency under 1.5 s.

export const options = {
  thresholds: {
    http_req_duration: ['avg < 1500'],
  },
};

2. Run the test: k6 run latency-test.js. If the average latency observed against https://httpbin.org/delay/1 is below 1.5 s, k6 prints a threshold summary with OK and exits with code 0.
3. Make the threshold impossible – change it to avg < 10 (10 ms).

export const options = {
  thresholds: {
    http_req_duration: ['avg < 10'],
  },
};

4. Run again: k6 run latency-test.js. The summary will show a threshold violation, the overall result will be marked FAILED, and the process will exit with a non‑zero code (typically 1).
5. Optional JSON output – add --out json=result.json to the command. The generated file contains a thresholds section where each rule has an ok boolean (true for pass, false for fail). You can inspect this file programmatically in a CI step.

Where to run the commands and what to check

• Local development machine or a CI agent that has k6 installed (>= v0.45).
• Ensure outbound HTTP(S) to the target endpoint is allowed (firewall/proxy).
• After each run, examine the terminal output for the line starting with thresholds and verify the exit code with echo $? on Unix or %ERRORLEVEL% on Windows.
• Risk: setting thresholds too tight will cause false failures even when the system is acceptable; setting them too loose lets regressions pass. Start with values derived from production SLAs or baseline measurements, then adjust iteratively.

Trade‑offs and limitations

Thresholds are evaluated **after** the virtual users finish, so they do not influence the load pattern during the test. If you need to abort early when latency spikes, you must implement custom logic with the check API or use the execution option gracefulStop. Additionally, thresholds only work with numeric metrics that k6 automatically collects; custom metrics must be numbers and added via the metrics API, otherwise the threshold is silently ignored and the test may appear to pass.

Because threshold values are absolute, they do not scale with the number of virtual users or test duration. A threshold that makes sense for a 5‑minute smoke test may be too strict for a 2‑hour soak test. Always contextualize the numbers to the specific load profile you are simulating.

Actionable closing

1. Identify the latency metric that matters most for your service (usually http_req_duration).
2. Write a threshold expression that reflects your SLO (e.g., p(95) < 300).
3. Add the expression to the options.thresholds block in your k6 script.
4. Run the script locally to confirm the exit code behaves as expected.
5. Integrate the k6 run command into your CI pipeline and treat a non‑zero exit code as a build failure.
6. Monitor the threshold results over time; adjust values only after reviewing baseline data or SLO changes.
