Serializing Delphi Records to JSON with System.JSON: A Practical Guide

Problem Statement

You have a Delphi record that must be persisted or transmitted as JSON. The goal is to serialize the record to a JSON string and later restore it, while handling malformed data and keeping memory usage reasonable.

Prerequisites

• Delphi 2009 or newer (System.JSON introduced in 2009). For modern code, use Delphi 10.4 or later.
• Basic familiarity with Delphi records and generic methods.
• An IDE or command‑line compiler that supports the System.JSON unit.

Target Record Definition

Define a record with a few scalar fields and a nested record to illustrate handling of nested structures.

type
  TAddress = record
    Street: string;
    City: string;
    Zip: string;
  end;

  TCustomer = record
    Id: Integer;
    Name: string;
    Email: string;
    Address: TAddress;
  end;

Serializing a Record

The TJSONObject class provides a type‑safe way to build JSON objects. Use AddPair for simple key/value pairs and AddPair with another TJSONObject for nested records.

uses
  System.JSON, System.SysUtils;

function CustomerToJSON(const C: TCustomer): string;
var
  Root, AddrObj: TJSONObject;
begin
  Root := TJSONObject.Create;
  try
    Root.AddPair('Id', C.Id);
    Root.AddPair('Name', C.Name);
    Root.AddPair('Email', C.Email);

    AddrObj := TJSONObject.Create;
    try
      AddrObj.AddPair('Street', C.Address.Street);
      AddrObj.AddPair('City', C.Address.City);
      AddrObj.AddPair('Zip', C.Address.Zip);
      Root.AddPair('Address', AddrObj);
    except
      AddrObj.Free;
      raise;
    end;

    Result := Root.ToString;
  finally
    Root.Free;
  end;
end;

Run this function on a TCustomer instance to obtain a JSON string. The function returns a UTF‑8 string that can be written to disk, sent over HTTP, etc.

Deserializing JSON Back to a Record

Parsing is symmetrical: create a TJSONObject from the string and extract each field. Use GetValue for scalars and recursively parse nested objects.

function JSONToCustomer(const JSON: string): TCustomer;
var
  Root, AddrObj: TJSONObject;
  Value: TJSONValue;
begin
  Result := Default(TCustomer); // zero‑initialize
  Root := TJSONObject.ParseJSONValue(JSON) as TJSONObject;
  if Root = nil then
    raise Exception.Create('Invalid JSON format');
  try
    Value := Root.GetValue('Id');
    if Value is TJSONNumber then
      Result.Id := (Value as TJSONNumber).AsInt;
    Result.Name := Root.GetValue('Name').Value;
    Result.Email := Root.GetValue('Email').Value;

    AddrObj := Root.GetValue('Address') as TJSONObject;
    if AddrObj <> nil then
    begin
      Result.Address.Street := AddrObj.GetValue('Street').Value;
      Result.Address.City := AddrObj.GetValue('City').Value;
      Result.Address.Zip := AddrObj.GetValue('Zip').Value;
    end;
  finally
    Root.Free;
  end;
end;

Notice the explicit type checks and the use of Default(TCustomer) to guarantee a clean starting state.

Validation and Error Handling

• Malformed JSON: ParseJSONValue returns nil if the string cannot be parsed. Always test for nil before proceeding.
• Missing Fields: GetValue returns nil if a key is absent. Guard against this by checking for nil or by using GetValue<T> with a default value (Delphi 10.4+).
• Type Mismatch: Attempting to cast a TJSONValue to the wrong subclass (e.g., TJSONNumber to TJSONString) raises an exception. Validate the class before casting.
• Large Payloads: For JSON larger than 10 MB, consider using TJSONReader to stream parse rather than loading the entire structure into memory.

Recovery Strategies

If deserialization fails, you can:

1. Log the error and return a Default(TCustomer) instance to avoid propagating corrupted data.
2. Provide a fallback JSON string that contains default values for missing fields.
3. Use a validation routine that checks each field after parsing and assigns sensible defaults when values are missing or invalid.

Performance Considerations

• For records with dozens of fields, the overhead of TJSONObject is modest (<10 ms on a modern CPU). For thousands of fields, memory consumption can spike; profiling with ReportMemoryLeaksOnShutdown is recommended.
• When serializing, building the JSON incrementally (e.g., adding fields only when necessary) reduces string concatenation costs.
• Use Result := Root.ToString only once; repeated calls to ToString re‑serialize the object.

Example: Round‑Trip Test

Below is a minimal test that demonstrates a successful round‑trip and error handling.

procedure TestCustomerJSON;
var
  Cust, Restored: TCustomer;
  JSON: string;
begin
  Cust.Id := 42;
  Cust.Name := 'Alice';
  Cust.Email := '[contact removed]';
  Cust.Address.Street := '123 Main St';
  Cust.Address.City := 'Metropolis';
  Cust.Address.Zip := '12345';

  JSON := CustomerToJSON(Cust);
  Restored := JSONToCustomer(JSON);

  // Verify round‑trip
  if (Restored.Id = Cust.Id) and (Restored.Name = Cust.Name) and
     (Restored.Email = Cust.Email) and
     (Restored.Address.Street = Cust.Address.Street) and
     (Restored.Address.City = Cust.Address.City) and
     (Restored.Address.Zip = Cust.Address.Zip) then
    Writeln('Round‑trip succeeded')
  else
    Writeln('Round‑trip failed');

  // Test malformed JSON
  try
    JSONToCustomer('{\"Id\": 1, \"Name\": \"Bob\"'); // missing closing brace
  except
    on E: Exception do
      Writeln('Caught error: ', E.Message);
  end;
end;

Conclusion

Using System.JSON eliminates the need for third‑party libraries and provides a straightforward, type‑safe way to serialize and deserialize Delphi records. By following the steps above, you can reliably store and transmit record data, handle errors gracefully, and maintain performance even with large JSON payloads.
