Selecting and Tuning Physics Engines for Contact-Rich Gazebo Simulations

The Challenge of Contact Fidelity

In robotics simulation, a common failure point is the "jitter" or "tunneling" (objects passing through each other) that occurs during high-impact contacts or complex manipulation. This usually stems from a mismatch between the physics engine's solver constraints and the robot's physical properties, such as stiff actuators or low-inertia links.

The primary goal is to balance Real-Time Factor (RTF)—the ratio of simulation time to wall-clock time—against the stability of contact forces. Choosing the wrong engine or leaving default solver parameters often leads to unstable simulations that do not translate to real-world hardware behavior.

Comparing Gazebo Physics Engines

Depending on your version of Gazebo (Classic or the modern gz-sim/Ignition), you have access to different physics backends. The choice depends on whether you prioritize raw speed, multi-body stability, or biomechanical accuracy.

Engine	Primary Strength	Trade-off	Best Use Case
ODE	High performance / Low latency	Can jitter with high stiffness	Simple mobile robots, fast prototyping
Bullet	Robust cluttered contacts	Slower than ODE in simple scenes	Manipulation, grasping, debris
DART	Model-based control stability	Requires explicit plugin setup	Legged locomotion, optimal control
Simbody	High-fidelity biomechanics	Highest compute cost	Medical robotics, compliant joints

Tuning the Solver for Stability

Regardless of the engine, the simulation stability is governed by the time step and the solver iterations. If a robot "explodes" upon contact, the first step is usually to decrease the max_step_size and increase the iters (iterations).

Key Parameter Definitions

• ERP (Error Reduction Parameter): Determines what fraction of a joint or contact error is corrected in the next simulation step. Higher values make contacts feel "stiffer" but can cause oscillations.
• CFM (Constraint Force Mixing): Adds a small amount of compliance to the constraint. A non-zero CFM prevents the solver from crashing when encountering mathematically "impossible" constraints.
• Max Step Size: The temporal resolution of the simulation. For high-speed impacts, 1ms (0.001s) is standard; highly dynamic systems may require 0.1ms.

Implementation: Configuring the World SDF

To apply these settings, modify the <physics> block in your world SDF file. The following example configures the ODE engine for a balance between stability and performance.

<sdf version='1.6'>
  <world name='default'>
    <physics name='stable_physics' type='ignored'>
      <engineprecipitation>
        <ode>
          <max_step_size>0.001</max_step_size>
          <real_time_factor>1.0</real_time_factor>
          <solver>
            <type>quick</type>
            <iters>100</iters>
          </solver>
          <constraints>
            <contact>
              <erp>0.2</erp>
              <cfm>0.00001</cfm>
            </contact>
          </constraints>
        </ode>
      </engineprecipitation>
    </physics>
  </world>
</sdf>

Execution and Permissions

Run the simulation using your standard Gazebo launch command (e.g., gz sim world_file.sdf). No root permissions are required for launching, but ensure that the physics plugins (especially for DART or Simbody) are installed via your system package manager (e.g., apt install libgazebo-dart-plugin) before attempting to switch engines.

Validation: The Drop Test

To verify if your physics settings are appropriate for your robot's mass and stiffness, perform a controlled drop test before integrating the full robot model.

1. Setup: Create a minimal world with a ground plane and a 1 kg primitive cube placed 1 meter above the plane.
2. Observation: Launch the simulation and observe the impact.
3. Metrics:
   • Penetration Depth: Does the cube sink into the floor? If yes, increase iters or decrease max_step_size.
   • Settling Time: Does the cube bounce indefinitely or jitter? If yes, lower the erp or increase cfm.
   • RTF Check: Monitor the simulation clock. If the RTF drops significantly below 1.0, you may need to reduce the solver iterations.

Verification Command

To capture the average step time without the overhead of the GUI, run the simulation in headless mode:

gz sim -s -r --iterations 1000 world_file.sdf

Check the terminal output for the average simulation step time. If the time per step exceeds your max_step_size, your simulation will lag behind real-time.

Limitations and Risks

Reducing the step size increases the CPU load linearly. On edge devices or limited hardware, a 0.1ms step size may make the simulation unusable. Additionally, avoid using extremely high ERP values (e.g., > 0.8) with stiff joint controllers, as this often creates a positive feedback loop that leads to numerical instability and "exploding" models.
