Securing Public Clients with OAuth 2.0 Authorization Code Grant + PKCE

Why PKCE Matters for Public Clients

Public clients—mobile apps, single-page applications, or any client that cannot keep a secret—must rely on OAuth 2.0 without a client secret. The classic Authorization Code Grant protects the code by binding it to a client secret, which public clients lack. PKCE (Proof Key for Code Exchange) fills this gap by adding a dynamic code challenge that ties the authorization request to the token request. This eliminates the risk that an intercepted authorization code can be swapped for tokens by an attacker.

Step-by-Step PKCE Flow

1. Generate a Code Verifier
   • Random string, 43–128 characters, using unreserved characters (A-Z, a-z, 0-9, "-", ".", "_", "~").
   • In many libraries this is a base64url-encoded random byte array.
2. Create a Code Challenge
   • Hash the verifier with SHA-256.
   • Encode the hash in base64url. This is the code_challenge.
   • Set code_challenge_method=S256 in the request.
3. Authorization Request
   • Send code_challenge and code_challenge_method to the provider's authorization endpoint.
   • Redirect the user to the authorization URL; the user authenticates and authorizes.

   https://auth.example.com/authorize?response_type=code
     &client_id=YOUR_CLIENT_ID
     &redirect_uri=YOUR_REDIRECT_URI
     &scope=openid profile
     &code_challenge=REPLACE_WITH_CHALLENGE
     &code_challenge_method=S256

4. Receive Authorization Code
   • The provider redirects to redirect_uri with code=AUTH_CODE.
5. Token Exchange
   • POST to the token endpoint with the original code_verifier.
   • If the verifier matches the challenge, the provider returns an access token (and optionally a refresh token).

   curl -X POST https://auth.example.com/token \
     -H "Content-Type: application/x-www-form-urlencoded" \
     -d "grant_type=authorization_code" \
     -d "code=AUTH_CODE" \
     -d "redirect_uri=YOUR_REDIRECT_URI" \
     -d "client_id=YOUR_CLIENT_ID" \
     -d "code_verifier=REPLACE_WITH_VERIFIER"

Worked Example with cURL

Below is a minimal, fully commented example that you can copy into a terminal. Replace placeholders with your values. This example assumes the provider supports PKCE and that TLS is correctly configured.

# Generate a verifier
CODE_VERIFIER=$(openssl rand -base64 64 | tr -d '+/=' | cut -c1-64)

# Create the challenge
CODE_CHALLENGE=$(printf "$CODE_VERIFIER" | openssl dgst -sha256 -binary | openssl base64 | tr '+/' '-_' | tr -d '=')

# Build the authorization URL
AUTH_URL="https://auth.example.com/authorize?response_type=code"
AUTH_URL="$AUTH_URL&client_id=YOUR_CLIENT_ID"
AUTH_URL="$AUTH_URL&redirect_uri=https://your.app/callback"
AUTH_URL="$AUTH_URL&scope=openid profile"
AUTH_URL="$AUTH_URL&code_challenge=${CODE_CHALLENGE}"
AUTH_URL="$AUTH_URL&code_challenge_method=S256"

echo "Open the following URL in a browser:"
echo "$AUTH_URL"

# After user logs in, you will receive a redirect like:
# https://your.app/callback?code=AUTH_CODE

# Capture the code (replace with actual value)
AUTH_CODE=REPLACE_WITH_CODE_FROM_QUERY

# Exchange for tokens
curl -X POST https://auth.example.com/token \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "grant_type=authorization_code" \
  -d "code=${AUTH_CODE}" \
  -d "redirect_uri=https://your.app/callback" \
  -d "client_id=YOUR_CLIENT_ID" \
  -d "code_verifier=${CODE_VERIFIER}"

Trade-offs and Limitations

• No Client Secret Needed
  • Public clients avoid storing secrets, reducing credential exposure.
  • However, if the provider does not support PKCE, the Authorization Code Grant reverts to a risky state.
• Redirect URI and TLS Still Critical
  • PKCE protects the code, but the redirect URI must be trusted and served over HTTPS to avoid token leakage.
• Refresh Tokens
  • Some providers issue refresh tokens only to confidential clients. Check the provider's documentation before assuming long-lived sessions.
• Implementation Complexity
  • Generating and storing the verifier securely adds a small overhead. Most modern OAuth libraries handle this automatically.

Actionable Checklist

1. Verify that your OAuth provider advertises PKCE support in its documentation.
2. Use a trusted OAuth library for your platform; most include PKCE support out of the box.
3. Generate a high-entropy code verifier (≥ 43 characters) and store it only for the duration of the flow.
4. Always serve the redirect URI over TLS and restrict it to a known set of URLs.
5. Inspect the network traffic during development to confirm the code challenge is sent and the verifier is included in the token request.
6. Test the flow against a sandbox or test account before going live.
7. Document the flow in your security policy and ensure your team understands the PKCE steps.

Implementing PKCE turns the Authorization Code Grant into a robust, secret-less flow suitable for mobile and SPA clients. By following the steps above, you can protect your users' tokens without exposing any credentials.
