Scaling ClickHouse Reads with Distributed Tables: A Practical Guide

Problem: Single‑Node Read Bottlenecks

When a reporting dashboard hits a ClickHouse instance with millions of rows, a single node can become a choke point. Even with a powerful CPU, the latency of aggregations and joins can grow linearly with the data size. Applications that rely on real‑time insights often need to keep query times under a few seconds, which is hard to achieve on a single shard.

Thesis: Use a Distributed Table to Parallelize SELECTs

ClickHouse’s Distributed table engine lets you expose a single logical table name that automatically routes SELECT statements to all shards in a cluster. The engine executes sub‑queries in parallel, collects the results, and returns a single result set to the client. This approach scales read workloads without changing application code.

Setting Up the Cluster

1. Define the cluster configuration on every node. Create /etc/clickhouse-server/config.d/cluster.xml with the same content on all servers:

   <clickhouse>
       <remote_servers>
           <cluster>
               <shard>
                   <replica>shard1-1</replica>
                   <replica>shard1-2</replica>
               </shard>
               <shard>
                   <replica>shard2-1</replica>
                   <replica>shard2-2</replica>
               </shard>
           </cluster>
       </remote_servers>
   </clickhouse>

   Replace replica hostnames with your actual server addresses. Restart ClickHouse after editing.

2. Create local tables on each shard. On every node, run:

   CREATE TABLE local_sales (
       id UInt64,
       date Date,
       amount Float64
   ) ENGINE = MergeTree()
   ORDER BY (date, id);


   Populate each table with a subset of your data (e.g., by date range) to keep shards balanced.

3. Define the Distributed table. On any node, execute:

   CREATE TABLE distributed_sales ENGINE = Distributed(
       'cluster',   -- cluster name from cluster.xml
       'default',   -- database name
       'local_sales',
       rand()        -- sharding key; rand() distributes evenly
   );


   The Distributed engine does not store data; it merely forwards queries to the appropriate local tables.

Running a Parallel Query

Now a simple aggregation runs across all shards:

SELECT
    date,
    sum(amount) AS total
FROM distributed_sales
GROUP BY date
ORDER BY date;

ClickHouse will issue a sub‑query to each shard, aggregate locally, then merge the partial results. You can confirm parallelism by checking system.query_log for multiple query_start_time entries from different nodes.

Trade‑offs and Limitations

• INSERT routing: The Distributed engine only distributes SELECTs. Inserts go to a single replica unless you explicitly route them. Use a ReplicatedMergeTree with a write‑through proxy or manually target a shard.
• Data skew: If one shard holds significantly more data, it becomes the slowest sub‑query, limiting overall performance. Keep shard sizes balanced.
• Network overhead: Parallel queries increase traffic between nodes. Ensure sufficient bandwidth and monitor system.network_events.
• Complex JOINs: Joins that reference the Distributed table still hit the slowest shard. For heavy cross‑shard joins, consider pre‑aggregated tables.

Actionable Next Steps

1. Verify that /etc/clickhouse-server/config.d/cluster.xml is identical on all nodes. A simple diff across servers is a quick sanity check.
2. Run SELECT COUNT(*) FROM local_sales on each shard to confirm data distribution.
3. Execute a test SELECT on the Distributed table and compare system.query_log entries against a single‑node query to measure speedup.
4. Implement a write‑routing strategy: either use a ReplicatedMergeTree with a proxy or add a sharding key to inserts.
5. Set up monitoring for system.network_events and system.merges to detect stragglers early.

By following these steps, you can expose a horizontally scalable read layer in ClickHouse, keeping your dashboards responsive while keeping the application code unchanged.
