Safe Realm Database Schema Migrations: A Step-by-Step Guide for Mobile Apps

Desired Outcome

Apply additive schema changes — such as new properties or new object types — to an existing Realm Database without losing user data. Realm handles this through a migration block that runs automatically when the schemaVersion in Realm.Configuration is incremented. The block receives a Migration object with access to both the old and new Realm instances, allowing you to transform objects on first open after an app update.

Prerequisites

• Realm SDK 10.x or later integrated via Swift Package Manager, CocoaPods, or Carthage.
• Current schemaVersion integer stored in your Realm.Configuration (default is 0).
• Backup strategy for production data: use Realm.copyRealm(configuration:) to create a pre-migration snapshot, or rely on server-side backup for synced realms.
• Test devices or simulators with representative datasets covering each prior schema version.
• Understanding of property attribute changes: making a property required, adding an index, or changing optionality.

Procedure

1. Increment the schema version

Update the configuration where you initialize Realm, typically in AppDelegate or a dedicated Realm manager:

let config = Realm.Configuration(
  schemaVersion: 1, // was 0
  migrationBlock: { migration, oldSchemaVersion in
    // migration logic here
  }
)
Realm.Configuration.defaultConfiguration = config

Each release that changes the schema must bump this integer by exactly 1.

2. Define the migration block

The block runs on the same thread that opens the Realm. Keep it fast — avoid network calls or heavy computation.

migrationBlock: { migration, oldSchemaVersion in
  if oldSchemaVersion < 1 {
    // Example: add required 'createdAt' property to Task objects
    migration.enumerateObjects(ofType: Task.className()) { oldObj, newObj in
      let defaultDate = Date()
      newObj?["createdAt"] = defaultDate
    }
  }
}

Key points:

• Use oldSchemaVersion to guard incremental steps; the block runs once per version bump.
• Access properties via string keys — Realm Swift 10+ stores property names in lowercase with underscores (e.g., Swift createdAt becomes created_at in the schema).
• For renames, create a new object and copy values: newObj?["newName"] = oldObj?["oldName"].
• Deletions require no action; Realm ignores removed properties.

3. Handle property type changes

Changing a property type (e.g., String to Int) is not automatic. Convert manually in the block:

if oldSchemaVersion < 2 {
  migration.enumerateObjects(ofType: User.className()) { oldObj, newObj in
    if let str = oldObj?["ageString"] as? String,
       let intVal = Int(str) {
      newObj?["age"] = intVal
    } else {
      newObj?["age"] = 0 // fallback
    }
  }
}

4. Test the migration

1. Create a test Realm file with schemaVersion = 0 and sample data (use a unit test or a debug build).
2. Increment to schemaVersion = 1 with the migration block above.
3. Open the Realm — the block executes and transforms objects.
4. Verify the new property exists and holds the default value.

Expected Checks

• Migration block executes exactly once per version increment — log entry at start/end of block.
• All existing objects have valid values for new required properties (no nil where non-optional).
• Object counts before and after migration match; run realm.objects(Task.self).count in tests.
• Indexes and primary keys remain functional — query by primary key and indexed properties.
• Test both upgrade paths: clean install (no migration) and sequential upgrades (v0 → v1 → v2).

Recovery Options

If the migration block throws (e.g., MigrationException), Realm aborts the open. Catch and log:

do {
  let realm = try Realm(configuration: config)
} catch let err as MigrationException {
  // Option 1: delete and start fresh (dev only)
  try? Realm.deleteFiles(for: config)
  // Option 2: prompt user to reinstall or contact support
  // Option 3: fall back to a read-only backup copy
}

For production:

• Create a pre-migration snapshot with Realm.copyRealm(configuration:) before opening.
• Implement server-side backup for synced realms (Flexible Sync or Partition Sync).
• Automate CI tests that run the full migration chain from v0 to current on every PR.

Limitations and Caveats

• Migration blocks run on the calling thread — do not block the main thread with complex transforms.
• Removing a property does not reclaim storage until Realm.compactRealm(configuration:) is called; plan for bloat if you frequently drop columns.
• Synced realms require additive-only, backward-compatible changes; the server schema must accept the new properties.
• Property names in the migration block use the stored schema naming (snake_case), not Swift camelCase.

Verification Steps

1. Open the migrated .realm file in Realm Studio — confirm schema version, property presence, and data integrity.
2. Run automated migration tests in CI for each version step, simulating fresh install and sequential upgrades.
3. Monitor migration block execution count via logging to ensure it runs only once per version increment.
