Replace Long‑Lived Secrets in GitHub Actions with Short‑Lived OIDC Tokens for AWS

Why the Problem Matters

Most teams store AWS access keys in GITHUB_SECRETS and reference them in workflows. Those keys are long‑lived, must be rotated manually, and if a workflow or a fork accidentally leaks the secret, every service that trusts the key is exposed. The blast radius is huge and the operational overhead is high.

Thesis: Pin Credentials to Identity, Not to Copy

GitHub Actions can generate a short‑lived OpenID Connect (OIDC) token for each job. The token is signed by token.actions.githubusercontent.com and contains claims that uniquely identify the repository, ref, and actor. By configuring a cloud provider to trust this issuer, you can assume a role without ever storing static keys in the repository. The IAM role’s policy remains the single source of truth for permissions, and the token’s lifetime is automatically revoked when the job ends.

Setting Up Federation with AWS

1. Create an IAM Role that Trusts GitHub

In the AWS console or via CLI, create a role (e.g., GitHubActionsDeployRole) and attach a trust policy that accepts tokens from GitHub’s issuer. The policy must also match the sub claim to restrict which repository and ref can assume the role.

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": {
        "Federated": "arn:aws:iam::123456789012:oidc-provider/token.actions.githubusercontent.com"
      },
      "Action": "sts:AssumeRoleWithWebIdentity",
      "Condition": {
        "StringEquals": {
          "token.actions.githubusercontent.com:sub": "repo:myorg/myrepo:ref:refs/heads/main"
        }
      }
    }
  ]
}

Replace 123456789012 with your AWS account ID, and adjust the repo and ref values to match the repository and branch you want to allow. For production environments, you can use a GitHub Environment name as the subject instead of a branch.

2. Grant the Role the Needed Permissions

Attach the minimal IAM policy required for the workflow’s tasks. For example, to deploy a CloudFormation stack:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": [
        "cloudformation:CreateStack",
        "cloudformation:UpdateStack",
        "cloudformation:DescribeStacks"
      ],
      "Resource": "*"
    }
  ]
}

Workflow Example

Below is a minimal GitHub Actions workflow that requests an OIDC token and uses the aws-actions/configure-aws-credentials action to assume the role. No AWS keys appear in secrets.

name: Deploy to AWS

on:
  push:
    branches: [main]

jobs:
  deploy:
    runs-on: ubuntu-latest
    permissions:
      id-token: write  # enable OIDC token generation
    steps:
      - uses: actions/checkout@v4
      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v5
        with:
          role-to-assume: arn:aws:iam::123456789012:role/GitHubActionsDeployRole
          aws-region: us-east-1
      - name: Deploy CloudFormation
        run: |
          aws cloudformation deploy \
            --stack-name my-stack \
            --template-file template.yaml \
            --capabilities CAPABILITY_NAMED_IAM

Key points:

• The job declares permissions: id-token: write to allow the OIDC token to be minted.
• The role-to-assume argument points to the IAM role created earlier.
• No AWS_ACCESS_KEY_ID or AWS_SECRET_ACCESS_KEY secrets are used.

Debugging a Failed Federation Attempt

When the role assumption fails, the error message usually references a mismatched claim. Common culprits:

• Incorrect sub format (e.g., missing repo: prefix or wrong ref).
• Audience mismatch: by default the aud claim is sts.amazonaws.com, but some setups use a custom audience; set the audience explicitly on the workflow.
• Typos in the trust policy string.

To inspect the raw token, add a debugging step:

      - name: Print OIDC token
        run: |
          echo ${{ steps.configure-aws-credentials.outputs.id-token }} | base64 -d | jq .

Verify that the sub and aud fields match what the trust policy expects.

Trade‑Offs and Limitations

• Token Lifetime: The OIDC token is short‑lived (≈1 hour). Jobs that run longer than that or hand off credentials to downstream systems must re‑authenticate. AWS does not allow configuring the token TTL.
• Exact String Matching: Trust policies use StringEquals on the sub claim. A single typo can silently deny access, so careful version control and automated tests of the trust policy are advised.
• Least‑Privilege Still Needed: Federation removes the need for static keys, but the IAM role must still be scoped tightly. A mis‑configured role can give the workflow more permissions than intended.
• Environment Mapping: To map to GitHub Environments, the sub claim can be repo:myorg/myrepo:environment:prod. This requires the environment to be defined in GitHub and the trust policy updated accordingly.

When to Use Federation

If your CI pipeline:

• Needs to deploy to a cloud provider on a regular basis.
• Has multiple branches or environments that should be isolated.
• Wants to eliminate manual key rotation and reduce blast radius.

Then OIDC federation is a strong fit. For very short pipelines or where the cloud provider does not support OIDC, static keys may still be acceptable but should be rotated automatically.

Actionable Closing

Replace static AWS credentials in your GitHub Actions workflows with OIDC tokens by:

1. Create an IAM role that trusts token.actions.githubusercontent.com and matches the sub claim to your repo/branch or environment.
2. Attach the minimal policy needed for the workflow.
3. Update the workflow to enable id-token: write and use configure-aws-credentials with role-to-assume.
4. Verify the token’s claims before committing the workflow.
5. Pair the role with a GitHub Environment for production deployments to add a manual approval gate.

By shifting the credential surface from the repository to an identity, you gain automatic revocation, tighter auditability, and a cleaner secrets store. The trade‑offs—short token lifetime and exact claim matching—are manageable with careful policy design and automated checks.
