Reducing Latency in Streamlit with st.fragment

The Cost of the Full Rerun

Streamlit's execution model is straightforward: whenever a user interacts with a widget, the entire script runs from top to bottom. While this simplifies development, it creates a performance bottleneck when your app mixes lightweight UI controls with heavy computations. If you have a data-heavy dashboard where a simple slider update triggers a five-second ML inference or a massive SQL query, the user experience suffers from noticeable lag.

The st.fragment decorator (introduced in version 1.33) solves this by allowing you to isolate specific sections of your UI. When a widget inside a fragment changes, only the code within that decorated function re-executes, leaving the rest of the page frozen.

How Fragments Isolate Execution

A fragment is essentially a scoped rerun. By wrapping a block of code in @st.fragment, you tell Streamlit to treat that function as an independent unit of execution. This is particularly useful for "interactive zones"—like a chart with its own set of filters—that don't need to trigger a refresh of the entire page header, sidebar, or other unrelated data tables.

Key behaviors of fragments include:

• Automatic Triggering: Any widget interaction inside the fragment automatically triggers a rerun of only that fragment.
• State Isolation: While fragments can access st.session_state, they operate as a distinct execution block.
• Execution Scope: Fragments cannot contain page-level configurations like st.set_page_config or st.navigation.

Practical Implementation: The Interactive Filter

Consider a scenario where you have a global app state (like a user profile) and a specific, expensive data visualization. Without fragments, changing a filter on the visualization would force the app to re-verify the user profile and re-render the entire layout.

import streamlit as st
import time
import pandas as pd
import numpy as np

st.title("Performance Dashboard")

# This part is expensive and runs on every full rerun
st.write("Loading global app state...")
time.sleep(2)
st.success("Global state loaded!")

@st.fragment
def render_data_explorer():
    st.subheader("Data Explorer")
    # This widget only triggers the fragment, not the whole script
    threshold = st.slider("Select Threshold", 0, 100, 50)

    st.write(f"Filtering data for threshold: {threshold}")
    # Simulate a medium-weight operation
    time.sleep(0.5)
    df = pd.DataFrame(np.random.randn(10, 2), columns=['A', 'B'])
    st.line_chart(df)

render_data_explorer()

Verification: To verify this is working, open your browser's Developer Tools (F12) and go to the Network tab. When you move the slider, you will see a POST request to /_stcore/fragment rather than a full stream request. The "Global state loaded!" message will not flicker or reappear, confirming the rest of the page remained static.

Constraints and Engineering Trade-offs

While fragments significantly reduce latency, they introduce specific constraints that can lead to bugs if ignored:

Widget Key Collisions

Every widget in a Streamlit app must have a unique key. Even if two widgets are in different fragments, they share the same global namespace. If you use a generic key like key="filter_input" in two different fragments, Streamlit will throw a DuplicateWidgetID error.

The Rerun Scope

Using a standard st.rerun() inside a fragment will trigger a full-page refresh, effectively bypassing the fragment's benefit. To force a refresh of only the fragment, you must use st.rerun(scope="fragment") (available in version 1.37+).

Nesting Limitations

Fragments cannot be nested. You cannot define a fragment inside another fragment. If your UI requires multiple independent update zones, define them as separate, top-level decorated functions.

Decision Matrix: Fragment vs. Full Rerun

Scenario	Recommended Approach	Reasoning
Global setting change (e.g., Theme/User)	Full Rerun	Affects the entire app state and layout.
Local chart filter/slider	st.fragment	Prevents expensive global re-computations.
Multi-step form submission	st.session_state + Full Rerun	Ensures data consistency across different page sections.

Summary Checklist

To implement fragments successfully, ensure the following:

• Verify your Streamlit version is >= 1.33.0 using st.__version__.
• Assign unique keys to all widgets within the fragment to avoid ID collisions.
• Move any logic that must update the rest of the page outside of the fragment.
• Use st.rerun(scope="fragment") for internal updates.
