Realm Schema Migration: Choosing Between Automatic and Custom Approaches

The Decision You're Facing

Your Realm-backed mobile app needs a schema change. Maybe you're adding a lastSyncedAt field to a User object, or you need to split a fullName string into firstName and lastName. The choice isn't academic: pick the wrong migration strategy and you'll silently lose user data or corrupt the Realm file.

Takeaway: Use automatic migration (schemaVersion bump only) for purely additive changes. For any rename, transform, split, merge, or field removal where data must survive, write a custom Migration class. Flexible Sync is a third path — only if you already depend on Atlas App Services.

Constraints That Shape Every Choice

• No downgrades: A Realm file opened at schemaVersion N can never be opened at N-1. Test upgrade paths from at least two prior versions in CI.
• Mandatory version bump: Every schema change — even additive — requires schemaVersion(N+1) in RealmConfiguration.Builder.
• Thread confinement: Migration runs on the thread that first opens the Realm. Do not dispatch the initial Realm.getInstance(config) call to Dispatchers.IO; the migration callback executes on that same thread.
• Encryption key first: If the Realm is encrypted, the key must be in the configuration before migration starts. Changing keys requires a full rewrite, not a migration.

Supported Options Compared

Trade-offs in Practice

Automatic Migration

Zero code. You increment schemaVersion and Realm adds new fields with default values (null for nullable, 0/false/empty for primitives). But removing a field silently discards its data — no callback, no warning. Never rely on automatic migration for production schema reductions.

Custom Migration

You implement Migration and register it via .migration(AppMigration()). Inside migrate(dynamicRealm, oldVersion, newVersion) you get a DynamicRealm — a stringly-typed API to read/write any schema version. This preserves data through transforms, but bugs in your migration logic run inside a write transaction; an unhandled exception corrupts the file. Wrap every step in try/catch and log extensively.

Flexible Sync

Schema lives in Atlas App Services. Clients pull schema changes automatically. You trade local migration code for backend operational complexity: schema deployments, versioning, and network latency on first open. Local-only apps cannot use this path.

Concrete Kotlin Implementation (Realm 10.x / Kotlin SDK 1.x+)

Below is a production-ready pattern for additive and destructive changes. It uses a when(oldVersion) ladder so each version step is explicit and testable.

class AppMigration : Migration {
    override fun migrate(dynamicRealm: DynamicRealm, oldVersion: Long, newVersion: Long) {
        // Each case handles ONE version step. Fall-through is intentional.
        when (oldVersion) {
            0L -> {
                // v0 → v1: add nullable 'lastSyncedAt' to User
                val userSchema = dynamicRealm.schema["User"]
                userSchema.addField("lastSyncedAt", RealmFieldType.INTEGER, true)
                // No data transform needed; new field defaults to null
            }
            1L -> {
                // v1 → v2: split 'fullName' into 'firstName' + 'lastName'
                val userSchema = dynamicRealm.schema["User"]
                userSchema.addField("firstName", RealmFieldType.STRING, false)
                userSchema.addField("lastName", RealmFieldType.STRING, false)

                val users = dynamicRealm.where("User").findAll()
                for (i in 0 until users.size()) {
                    val user = users[i]
                    val fullName = user.getString("fullName") ?: ""r>                    val parts = fullName.split(" ", limit = 2)r>                    user.setString("firstName", parts[0])r>                    user.setString("lastName", parts.getOrElse(1) { "" })r>                }r>                // Remove old field AFTER data is copied
                userSchema.removeField("fullName")r>            }r>            2L -> {r>                // v2 → v3: add 'isActive' with default true for existing usersr>                val userSchema = dynamicRealm.schema["User"]r>                userSchema.addField("isActive", RealmFieldType.BOOLEAN, false)r>                val users = dynamicRealm.where("User").findAll()r>                for (i in 0 until users.size()) {r>                    users[i].setBoolean("isActive", true)r>                }r>            }r>            else -> throw IllegalStateException("Unhandled migration from v$oldVersion")r>        }r>    }r>}

// Register in your Application or Realm module
val config = RealmConfiguration.Builder()
    .schemaVersion(3)
    .migration(AppMigration())
    .build()
Realm.setDefaultConfiguration(config)

Key details:

• DynamicRealm.schema["ClassName"] returns a DynamicRealmObjectSchema for field add/remove.
• Field removal (removeField) happens after data transformation in the same version step.
• Nullable fields (true third arg) default to null; non-nullable get zero-values unless you explicitly set them.
• The when block falls through: a device jumping from v0 to v3 executes v0→v1, v1→v2, v2→v3 in one transaction.

Validation: Test the Migration, Not Just the Schema

Write instrumented tests that exercise the full upgrade path. The pattern:

1. Create a Realm file at schemaVersion 0 with realistic data (use Realm Studio or a script).
2. Copy that file into androidTest/assets/realm_v0.realm.
3. In the test, open it with a config targeting schemaVersion(3) and your AppMigration.
4. Assert field existence, transformed values, and query performance.

@RunWith(AndroidJUnit4::class)
class MigrationTest {
    @Test
    fun `v0 to v3 migration preserves and transforms data`() {
        val src = ApplicationProvider.getApplicationContext()
            .assets.open("realm_v0.realm").readBytes()
        val dest = File(ApplicationProvider.getApplicationContext()
            .cacheDir, "migrated.realm")
        dest.writeBytes(src)

        val config = RealmConfiguration.Builder()
            .name(dest.name)
            .schemaVersion(3)
            .migration(AppMigration())
            .build()

        Realm.getInstance(config).use { realm -
            val users = realm.where().findAll()
            assertEquals(3, users.size)
            users.forEach { user -
                assertNotNull(user.lastSyncedAt) // added v1
                assertFalse(user.firstName.isBlank()) // transformed v2
                assertFalse(user.lastName.isBlank())
                assertTrue(user.isActive) // defaulted v3
            }
            // Verify old field is gone
            val schema = realm.schema["User"]
            assertFalse(schema.fieldNames.contains("fullName"))
        }
    }
}

Performance and Post-Migration Checks

• Large datasets (>100k objects): Batch transforms in background transactions. The example above runs on the calling thread; for 50k+ objects, move the forEach loop into a realm.executeTransactionAsync and await completion before returning from migrate().
• Reclaim space: After migration, call Realm.compactRealm(config) on a background thread. Verify file size reduction — fragmented Realm files can grow 2-3x during multi-step migrations.
• Target: <2 seconds on mid-tier devices (Snapdragon 7-series / A13) for 50k objects. Measure in CI with a device farm or local emulator.

Limitations and Gotchas

• No rollback: Migration is one-way. If AppMigration throws, the Realm file may be left in an inconsistent state. Your only recovery is restoring from backup or clearing app data.
• Encryption key rotation: Not a migration. Changing the encryption key requires exporting all objects, deleting the Realm, and re-importing with the new key.
• Sync vs local: If you later adopt Flexible Sync, local migration code becomes obsolete for synced realms — but unsynced (local-only) realms still need it.
• Version sensitivity: Realm Core 12+ changed encryption handling during migration. Verify key management if you're on Core 12+ (Realm Java/Kotlin 10.10+, Kotlin SDK 1.2+).

Verification Checklist Before Shipping

• ☐ Test upgrade from vN-2 and vN-1 to vN in CI (not just v0 → vN).
• ☐ Assert no RealmMigrationNeededException is thrown on fresh installs at vN.
• ☐ Run migration on a 50k-object dataset; confirm <2s duration and <10% file size overhead post-compaction.
• ☐ Attempt downgrade (open vN file with vN-1 config) — expect clear RealmMigrationNeededException with version mismatch message.
• ☐ Log migration entry/exit with old/new version numbers; correlate with crash reports.
