Rancher Cluster Agent Connectivity: Diagnosing WebSocket Failures

The Problem: Agents Stuck in CrashLoopBackOff

When downstream clusters appear Unavailable or Waiting in the Rancher UI, the cattle-cluster-agent and cattle-node-agent pods are often in CrashLoopBackOff. The root cause is typically a WebSocket connection failure to wss://<rancher-url>/v3/connect. This guide helps you diagnose and fix the issue systematically. Commands assume you have cluster-admin access to the downstream cluster via kubectl and network access from a cluster node.

Quick Diagnostic Table

Symptom	Most Likely Cause
CrashLoopBackOff + bad handshake	Proxy/LB missing WebSocket headers or low timeout
CrashLoopBackOff + x509 error	TLS certificate mismatch or missing CA
Error=connection refused	Network policy or firewall blocking port 443
Waiting > 15 min, no logs	Registration token expired or agent version skew

Step-by-Step Checks

1. Verify Rancher server reachability
   Run from a node in the downstream cluster (replace <rancher-url> with your server hostname):

   curl -vk https://<rancher-url>/v3/connect

   Expected: an HTTP response indicating a WebSocket upgrade endpoint. If the connection times out or is refused, check network connectivity first.
2. Inspect agent logs

   kubectl logs -n cattle-system -l app=cattle-cluster-agent --tail=100

   Look for failed to connect to wss://, websocket: bad handshake, or x509: certificate signed by unknown authority.
3. Check pod events

   kubectl describe pod -n cattle-system -l app=cattle-cluster-agent

   Events like FailedMount or Pod Security admission denials point to RBAC or PSA issues.
4. Validate TLS trust

   openssl s_client -connect <rancher-url>:443 -servername <rancher-url>

   Verify the certificate chain is trusted and the hostname matches the SAN list.
5. Confirm registration token validity

   kubectl get secret -n cattle-system cattle-credentials -o jsonpath='{.data.value}' | base64 -d

   An empty or malformed token indicates the cluster needs re-registration.
6. Review network policies

   kubectl get networkpolicy -A -o wide

   Ensure no policy blocks egress to port 443 on the Rancher server IP.
7. Check proxy/load balancer config
   For NGINX or HAProxy in front of Rancher, verify:
   • proxy_set_header Upgrade $http_upgrade;
   • proxy_read_timeout 300s;
   • The Connection: upgrade header is passed through

Applying Fixes

• Network/Firewall: Open outbound TCP 443 to the Rancher server from all cluster nodes.
• TLS Certificate Issues: Add the Rancher CA certificate to the cluster's trusted store, or reinstall the agent with the CA provided (for example --set rancherServerCA=<ca-content> during registration).
• Proxy/LB Misconfiguration: Enable WebSocket upgrade headers and increase the idle timeout to at least 60 seconds (300s recommended).
• Token Expired: Delete the cattle-credentials secret and re-register the cluster via the Rancher UI. Schedule this during a maintenance window; re-registration can briefly disrupt Rancher-managed resources.
• Version Skew: Align the agent image tag with the Rancher server version. Changing the image on an existing cluster requires a helm upgrade of the agent release, not just a pod restart.
• RBAC/PSA Blocking: Grant the cattle-system namespace the required Pod Security Admission level (privileged) so the node-agent can use hostPath mounts.

When to Escalate to SUSE

Escalate if:

• Network and TLS checks pass but bad handshake persists after 30 minutes.
• The cluster remains in Waiting state with no agent logs.
• Failure occurs immediately after a Rancher server upgrade.
• Custom CNI plugins appear to block WebSocket upgrade traffic.
• The environment has FIPS or air-gapped restrictions preventing standard diagnostics.

Verification Steps

1. Test agent connectivity from inside the pod

   kubectl exec -n cattle-system -it deploy/cattle-cluster-agent -- wget -qO- https://<rancher-url>/v3/connect

   Should return a WebSocket upgrade response rather than a connection error.
2. Check cluster state via the Rancher API

   curl -k -H 'Authorization: Bearer <token>' https://<rancher-url>/v3/clusters/<cluster-id>

   Verify state: "active".
3. Validate version alignment

   kubectl get pods -n cattle-system -o jsonpath='{.items[*].spec.containers[*].image}'

   Ensure the agent image minor version matches the Rancher server.
4. Monitor for certificate errors

   kubectl logs -n cattle-system -l app=cattle-cluster-agent --since=30m | grep -iE 'cert|tls|x509'

   Should return no results over a 30-minute window.

Caution: Do not delete the cattle-system namespace on production clusters without a backup; it removes Rancher-managed resources. Test NetworkPolicy changes in staging first, since they can affect other workloads.
