Plotly ScatterGL: Rendering Hundreds of Thousands of Points with WebGL

Goal

Plotly’s scattergl renderer allows you to display hundreds of thousands of points in a browser with far less CPU usage than the standard scatter trace. This article shows how to enable it, verify performance, and fall back when WebGL2 is unavailable.

Prerequisites

• Modern browser with WebGL2 support (Chrome, Firefox, Edge, Safari on recent OS). Older browsers will silently fall back to scatter.
• Plotly.js v5.x (or later) loaded in the page. If using npm, install plotly.js-dist-min or plotly.js-dist.
• Basic JavaScript knowledge to generate data arrays.
• Optional: a performance monitoring tool (Chrome DevTools Performance panel).

Step‑by‑Step Procedure

1. Generate a large dataset. The following code creates 200 000 random points. In practice replace this with your real data.

   const n = 200000;
   const x = new Array(n).fill(0).map(() => Math.random() * 100);
   const y = new Array(n).fill(0).map(() => Math.random() * 100);
   const z = new Array(n).fill(0).map(() => Math.random() * 100); // optional for 3D


2. Build the trace. Use type: 'scattergl' and set marker properties. Note that line width and other advanced styles are limited.

   const trace = {
     x: x,
     y: y,
     z: z, // omit for 2D
     mode: 'markers',
     type: 'scattergl',
     marker: {
       size: 5,
       color: x, // color by x value
       colorscale: 'Viridis',
       opacity: 0.8
     }
   };


3. Define layout. Keep it simple; complex axis transforms may not work with scattergl.

   const layout = {
     title: 'Large Point Cloud with ScatterGL',
     scene: { // 3D only if z is provided
       xaxis: {title: 'X'},
       yaxis: {title: 'Y'},
       zaxis: {title: 'Z'}
     }
   };


4. Render the figure. Call Plotly.newPlot in a container element.

   Plotly.newPlot('myDiv', [trace], layout);


5. Verify performance. Open Chrome DevTools, go to the Performance tab, record a few seconds, and check the frame rendering time. A smooth 60 fps run indicates that scattergl is working.

Expected Behavior

• Initial render is noticeably faster than a CPU‑based scatter trace of the same size.
• Zoom, pan, and hover remain responsive. Selection tools may be slower depending on the GPU.
• If the browser lacks WebGL2, the plot still appears but falls back to scatter without error.

Common Pitfalls & Recovery

• Low‑end GPU. On older laptops the frame rate may drop. Test on target devices before deployment. If performance is unacceptable, chunk the data.
• Memory limits. GPU memory can hold ~1–2 million points. For larger datasets, split the array into multiple traces or load data incrementally.

  // Example chunking: 5 traces of 200k points each
  const chunks = 5;
  const chunkSize = n / chunks;
  const traces = [];
  for (let i = 0; i < chunks; i++) {
    const start = i * chunkSize;
    const end = start + chunkSize;
    traces.push({
      x: x.slice(start, end),
      y: y.slice(start, end),
      mode: 'markers',
      type: 'scattergl',
      marker: {size: 5, color: 'rgba(0,0,255,0.5)'}
    });
  }
  Plotly.newPlot('myDiv', traces, layout);


• Unsupported styling. Features like marker.line.width are ignored. Stick to size, color, opacity, and colorscale.
• 3D rotations. Complex 3D interactions are not fully supported with scattergl; fall back to scatter3d if needed.

Fallback Strategy

Plotly automatically detects WebGL2 availability. If it’s missing, the trace reverts to the CPU implementation. No additional code is required. To force a fallback for testing, disable WebGL in the browser or use an older browser and observe the slower rendering.

Conclusion

By setting type: 'scattergl', you can efficiently plot large point clouds while preserving interactivity. Remember to test on the target hardware, monitor frame rates, and chunk data when approaching GPU memory limits. When WebGL2 is unavailable, Plotly’s graceful fallback ensures the plot still renders, albeit with reduced performance.
