Paginating Trello Board Cards with the REST API: A Reliable Export Pattern

Problem

Exporting or syncing all cards from a large Trello board fails when a single request returns only the first 1000 items. The API uses cursor‑based pagination (the before and since parameters) rather than offset/limit, so a script must walk backward through card IDs to retrieve every card without gaps or duplicates.

Prerequisites

• A Trello API key and a user token with read scope for the target board.
• Network access to https://api.trello.com from the machine running the script.
• Basic familiarity with HTTP GET requests (e.g., curl, httpie, or a language‑specific HTTP client).
• Board ID (the short alphanumeric string visible in the board URL).

Procedure

1. Choose a safe page size

The endpoint GET /1/boards/{id}/cards accepts limit up to 1000. Use a smaller value (e.g., 200) to reduce latency and the chance of hitting rate limits.

2. Initial request – newest cards first

curl -G "https://api.trello.com/1/boards/{BOARD_ID}/cards" \
  --data-urlencode "key={API_KEY}" \
  --data-urlencode "token={TOKEN}" \
  --data-urlencode "limit=200" \
  --data-urlencode "fields=id,name,dateLastActivity" \
  --data-urlencode "actions=none"

Run this in a terminal where curl is installed. The response is a JSON array of card objects, newest first.

3. Extract the cursor for the next page

Take the id of the last element in the returned array (the oldest card in that page). That ID becomes the before value for the next call.

4. Loop until the page is smaller than the requested limit

#!/usr/bin/env bash
# paginate_trello_cards.sh
BOARD_ID="{BOARD_ID}"
KEY="{API_KEY}"
TOKEN="{TOKEN}"
LIMIT=200
BEFORE=""

while true; do
  QUERY=(--data-urlencode "key=$KEY" --data-urlencode "token=$TOKEN" \
         --data-urlencode "limit=$LIMIT" --data-urlencode "fields=id,name,dateLastActivity" \
         --data-urlencode "actions=none")
  if [[ -n "$BEFORE" ]]; then
    QUERY+=(--data-urlencode "before=$BEFORE")
  fi
  RESPONSE=$(curl -sS -G "https://api.trello.com/1/boards/$BOARD_ID/cards" "${QUERY[@]}")
  COUNT=$(echo "$RESPONSE" | jq 'length')
  echo "$RESPONSE" >> all_cards.json
  if (( COUNT < LIMIT )); then
    break
  fi
  BEFORE=$(echo "$RESPONSE" | jq -r '.[-1].id')
  sleep 0.2   # polite back‑off to avoid 429
 done

Save the script, make it executable (chmod +x paginate_trello_cards.sh), and run it. Each iteration appends a page to all_cards.json.

5. Optional forward pass for cards created during the export

Because the loop walks backward, any card added after the first request will not appear. After the backward walk finishes, run a second pass using since with the ID of the newest card you captured:

SINCE=$(jq -r '.[0].id' all_cards.json)
curl -G "https://api.trello.com/1/boards/{BOARD_ID}/cards" \
  --data-urlencode "key={API_KEY}" \
  --data-urlencode "token={TOKEN}" \
  --data-urlencode "since=$SINCE" \
  --data-urlencode "fields=id,name,dateLastActivity" \
  --data-urlencode "actions=none" >> all_cards.json

Verification

1. Spot‑check page size: Run a single request with limit=5 and confirm exactly five cards return. Then use the last card’s ID as before and verify the next page contains older, non‑overlapping cards.
2. Max‑limit guard: On a board known to have >1000 cards, request limit=1000 and ensure the response never exceeds 1000 items.
3. Auth error path: Temporarily invalidate the token and confirm a 401 Unauthorized response; your script should surface this and stop.

Limitations and Recovery

• Hard limit: No single request can return more than 1000 cards; the script must paginate.
• Cursor semantics: before and since accept card IDs, not timestamps. Supplying a date string yields an error.
• Concurrent changes: Cards created while the backward loop runs are missed. The forward since pass mitigates this but cannot capture cards deleted between the two passes.
• Rate limiting: HTTP 429 responses require exponential back‑off. The example includes a minimal sleep 0.2; production code should implement a full retry strategy.
• Rollback: This operation is read‑only; no state is changed on Trello, so no rollback is needed.

Practical Check

After the script finishes, count the unique card IDs in all_cards.json and compare with the board’s card total shown in the UI (Board → Menu → More → Print and Export → JSON). A match within a few cards (accounting for concurrent edits) confirms a complete export.
