OpenTelemetry Collector Tail Sampling: Reduce Ingestion Costs While Keeping Errors and Slow Traces

The Problem: Full-Fidelity Tracing Is Expensive

Sending every trace to your observability backend works fine at low volume. At scale, ingestion costs and storage retention become the primary constraints. Head-based sampling (deciding at trace start) is cheap but blind—you cannot preferentially keep errors or high-latency requests because you don't know the outcome yet.

Use the Tail Sampling Processor when you need to sample after a trace completes, so you can apply policies like "always keep errors," "keep traces slower than 500 ms," and "probabilistically sample the rest." This runs in the OpenTelemetry Collector, not in your application code.

How Tail Sampling Works

The tail_sampling processor buffers spans by trace ID until one of two conditions occurs:

• The trace appears complete (all spans have ended), detected via span end signals.
• A configurable wait_time elapses (default 30 s), forcing a decision on potentially incomplete traces.

Once the buffer window closes, the processor evaluates policies in order. The first matching policy decides: sample or drop. If no policy matches, the trace is dropped. Policies include:

• latency — sample traces exceeding a duration threshold.
• status_code — sample traces with a specific status (e.g., ERROR).
• probabilistic — sample a percentage of remaining traces.
• string_attribute, numeric_attribute — sample based on span attributes.

The processor stores trace data in memory by default. For multi-instance collectors, an optional Redis backend shares state, but adds network latency and operational complexity.

Worked Configuration Example

Below is a minimal, production-style collector configuration. Save it as collector-config.yaml and run the collector with --config=collector-config.yaml. Requires a collector binary v0.100.0 or later.

receivers:
  otlp:
    protocols:
      grpc:
      http:

processors:
  # Bound memory before tail sampling sees the data
  memory_limiter:
    check_interval: 1s
    limit_mib: 512
    spike_limit_mib: 128

  # Batch spans to reduce downstream calls; MUST precede tail_sampling
  batch:
    timeout: 10s
    send_batch_max_size: 1024

  tail_sampling:
    # Total traces held in memory at once
    num_traces: 50000
    # Wait longer than your p99 trace duration
    wait_time: 30s
    policies:
      - name: errors-always
        type: status_code
        status_code:
          status_codes: [ERROR]
      - name: slow-requests
        type: latency
        latency:
          threshold_ms: 500
      - name: baseline-10pct
        type: probabilistic
        probabilistic:
          sampling_percentage: 10

exporters:
  otlp:
    endpoint: tempo:4317
    tls:
      insecure: true

service:
  pipelines:
    traces:
      receivers: [otlp]
      processors: [memory_limiter, batch, tail_sampling]
      exporters: [otlp]

Key Placement Rule

Place tail_sampling after batch (and any other span-aggregating processors) but before exporters. If you put it before batch, each span is evaluated individually, breaking trace assembly and defeating the purpose.

Policy Order Matters

The example orders policies from most specific to least specific:

1. errors-always — catches any trace with an ERROR status code, regardless of latency.
2. slow-requests — catches traces > 500 ms that didn't already match errors.
3. baseline-10pct — probabilistically samples 10 % of everything else.

Reversing this order would cause the probabilistic policy to consume traces before the error/latency policies ever see them.

Operational Limits and Trade-offs

Memory and CPU

The processor holds complete trace data in memory until wait_time expires. With num_traces: 50000 and average trace size of 2 KB, expect ~100 MB baseline plus overhead. Monitor the collector's process_memory_bytes and the processor's traces_dropped metric (exposed via Prometheus). If traces_dropped rises, increase num_traces or scale horizontally.

Added Latency

Traces that complete before wait_time are released immediately. Incomplete traces wait the full wait_time. Set wait_time to your 99th-percentile trace duration plus a safety margin (e.g., if p99 is 12 s, use 30 s). Longer wait times increase memory pressure; shorter times risk sampling incomplete traces.

Multi-Instance State

Without Redis, each collector instance makes independent decisions. The same trace ID arriving at different instances (due to load balancing) will be evaluated separately, potentially causing inconsistent sampling. Redis backend (policy_evaluator: redis in config) solves this but introduces a network hop and a single point of failure—run Redis with HA (Sentinel or Cluster) if you go this route.

Common Mistakes

Mistake	Symptom	Fix
tail_sampling before batch	Traces never sampled; traces_received increments but traces_sampled stays zero	Move tail_sampling after batch in the pipeline
wait_time too short (e.g., 5 s)	Long-running traces sampled incompletely; missing root spans	Set wait_time > p99 trace duration
Probabilistic policy first	Errors and slow traces dropped at the probabilistic rate	Order policies: specific → general
No memory_limiter	Collector OOM-killed under load	Add memory_limiter before tail_sampling
Redis backend without HA	Collector stalls when Redis node fails	Deploy Redis Sentinel/Cluster; tune redis_timeout

Verification Steps

1. Deploy the collector with the example config to a test environment.
2. Generate synthetic traces:

   # Run from a host with network access to the collector
   otel-cli span --service test-svc --name "fast-ok" --duration 50ms
   otel-cli span --service test-svc --name "slow-ok" --duration 800ms
   otel-cli span --service test-svc --name "error-case" --status error --duration 100ms


3. Query your backend (Tempo, Jaeger, etc.) and confirm:
   • fast-ok appears ~10 % of the time.
   • slow-ok appears 100 % of the time.
   • error-case appears 100 % of the time.
4. Check collector metrics (Prometheus endpoint, usually :8888/metrics):

   otelcol_processor_tail_sampling_traces_received_total
   otelcol_processor_tail_sampling_traces_sampled_total
   otelcol_processor_tail_sampling_traces_dropped_total


   Verify the counters align with your policy expectations.

When Not to Use Tail Sampling

• Throughput exceeds what a single collector instance can buffer (consider head sampling in the SDK instead).
• Your traces are extremely long-running (minutes), making wait_time impractically large.
• You cannot tolerate the added tail latency for incomplete traces.

Summary Checklist

• Place memory_limiter → batch → tail_sampling in the traces pipeline.
• Set wait_time > p99 trace duration.
• Order policies: status_code/latency first, probabilistic last.
• Monitor traces_dropped and collector memory.
• Test with synthetic traces before production rollout.
