Moleculer Built-in Fault Tolerance: Policy Composition Without Library Sprawl

The problem: resilience without the baggage

You're running Node.js microservices. One calls a flaky third‑party API, another hits a database that occasionally stalls. The typical solution is to pull in opossum for circuit breaking, async-retry for retries, p-timeout for timeouts, and maybe bottleneck for concurrency limits. Then you wire them together, configure each differently per service, and hope the composition order doesn’t bite you at 3 AM.

How the policy stack composes

When you declare:

policy: { timeout: 3000, bulkhead: 10, retry: 3, circuitBreaker: { threshold: 0.5, windowTime: 60000 } }

The middleware chain executes in this order: timeout → bulkhead → retry → circuit‑breaker. That means:

• A request first hits the timeout wrapper. If the handler exceeds 3 seconds, ERR_TIMEOUT is thrown (the original handler keeps running unless you hook ctx.cancel()).
• If the timeout passes, the bulkhead checks concurrent executions. At 10 concurrent calls, further requests get ERR_BULKHEAD_REJECTED immediately—before any retry logic sees them.
• Only then does retry kick in, with exponential backoff and optional jitter. You can supply a check function to retry only on specific error codes (e.g., err.code === 'ETIMEDOUT').
• Finally, the circuit breaker records the outcome. When the failure rate crosses the threshold (0.5 = 50 %) over windowTime, it opens and short‑circuits subsequent calls.

This order is intentional: you want to fail fast on timeout and overload before burning retry budget, and you want the circuit breaker to see the final outcome after retries.

Circuit breaker state: local by default, shared on demand

By default, each Moleculer node maintains its own circuit‑breaker state (closed/open/half‑open). In a cluster, that means Node A can hammer a failing dependency while Node B has already opened its circuit—until the transporter syncs the state.

With a shared transporter (NATS, Redis, MQTT) you can enable synchronization via the nodeID filter in the circuitBreaker options. The syncInterval (default 10 s) controls how often nodes exchange state. Tighten it for tighter coordination, but know that every sync adds broker chatter.

circuitBreaker: {
  threshold: 0.5,
  windowTime: 60000,
  minRequestCount: 5,
  syncInterval: 5000 // ms, requires shared transporter
}

Caution: threshold is a failure rate, not an absolute count. Low‑traffic actions may never trip or trip too eagerly. Set minRequestCount to require a minimum sample size before evaluating the rate.

Worked example: a flaky downstream HTTP service

Imagine a payments service that calls an external provider. The provider occasionally hangs (timeout), returns 5xx (retryable), or gets overwhelmed (bulkhead). Here’s a minimal action with all four policies:

const axios = require('axios');

module.exports = {
  name: 'payments',
  actions: {
    charge: {
      policy: {
        timeout: 2000,
        bulkhead: 5,
        retry: {
          count: 3,
          delay: 200,
          factor: 2,
          check: (err) => err.code === 'ETIMEDOUT' || (err.response && err.response.status >= 500)
        },
        circuitBreaker: {
          threshold: 0.5,
          windowTime: 60000,
          minRequestCount: 10
        }
      },
      async handler(ctx) {
        const controller = new AbortController();
        ctx.on('cancel', () => controller.abort());

        const resp = await axios.post('https://provider.example/charge', ctx.params, {
          signal: controller.signal,
          timeout: 1900 // slightly under policy timeout
        });
        return resp.data;
      }
    }
  }
};

What happens under load?

1. Concurrent calls > 5 → immediate ERR_BULKHEAD_REJECTED (HTTP 503 from API gateway).
2. Provider hangs 2.1 s → timeout fires, ERR_TIMEOUT, retry logic sees ETIMEDOUT and retries up to 3 times with 200/400/800 ms delays.
3. Provider returns 503 → retry logic catches it (status ≥ 500) and retries.
4. After 10+ requests with > 50 % failure rate → circuit opens, further calls fail fast with ERR_CIRCUIT_OPEN until half‑open probe succeeds.

The AbortController wiring is critical: without it, a policy timeout leaves the outbound HTTP request running, leaking sockets and connection‑pool slots. Moleculer’s timeout does not automatically cancel downstream I/O—you must integrate with the HTTP client’s cancellation mechanism.

Trade‑offs and limitations

• Bulkhead before retry: A transient spike that fills the bulkhead returns 503 immediately rather than queuing. If you prefer queueing, wrap the action with a small async queue (e.g., p-queue) inside the handler.
• Timeout ≠ cancellation: As shown above, you must wire ctx.cancel() to AbortController or axios cancel tokens. This is a common source of resource leaks.
• Low‑traffic circuit breaker: With minRequestCount: 10, an action called once per minute will never trip. Tune per action.
• Hot‑reload caveat: Policy options merge at service load time. Changing policies on a running service requires a full broker restart or the hotReload plugin; otherwise the old middleware chain persists.
• Sync interval latency: In multi‑node deployments, a failing dependency can be hammered independently by each node until syncInterval propagates the open state. For tighter coordination, use a shared Redis store and lower syncInterval (at the cost of more broker traffic).

Observability: metrics you can actually use

Each policy emits Moleculer events ($metrics.trace, $metrics.stat) that the official moleculer-prometheus module scrapes. Key counters:

• moleculer_circuit_breaker_state_changes_total — tracks open/half‑open/closed transitions
• moleculer_bulkhead_rejections_total — counts bulkhead rejections
• moleculer_retry_attempts_total — counts retry attempts

Add the module, expose /metrics, and you have dashboards and alerts without custom instrumentation.

What to try next

1. Create a minimal service with the policy config above and an action that sleeps 200 ms then throws. Call it concurrently 10 times; watch broker logs for ERR_TIMEOUT, ERR_BULKHEAD_REJECTED, retry attempts, and circuit‑open events.
2. Enable moleculer-prometheus and verify the counters increment as expected.
3. If you run multiple broker instances, add a NATS transporter, trigger failures on one node, and confirm the circuit opens on the second node within your syncInterval.
4. Wrap an outbound axios call with AbortController linked to ctx.cancel(); verify the underlying TCP connection closes on timeout (inspect with netstat or Wireshark).

Moleculer’s built‑in policies won’t replace a dedicated service mesh for cross‑cutting concerns like mTLS or distributed tracing, but for action‑level resilience they eliminate a whole category of dependency sprawl. The declarative policy object keeps configuration next to the code it protects, and the fixed composition order means fewer surprises at 3 AM.
