Modeling UI Navigation with Kotlin Sealed Classes: Exhaustive When Expressions

Why Boolean Flags Lead to Impossible UI States

Many apps track UI with separate flags like isLoading, hasError, and currentItem. Setting them independently can produce combinations that never make sense—e.g., showing a spinner while also displaying an error.

Sealed Classes as a Closed State Hierarchy

A sealed class limits its subclasses to the same file, giving the compiler full knowledge of all possible states. When used in a when expression, Kotlin checks exhaustiveness, so omitting a branch results in a compile‑time error.

Worked Example: Navigation State for a Profile Screen

sealed class ProfileNavState {
    object Home : ProfileNavState()
    data class Detail(val userId: String) : ProfileNavState()
    data class Error(val message: String) : ProfileNavState()
}

fun describe(state: ProfileNavState): String =
    when (state) {
        is ProfileNavState.Home -> "Showing list of profiles"
        is ProfileNavState.Detail -> "Displaying profile ${state.userId}"
        is ProfileNavState.Error -> "Error: ${state.message}"
        // No else needed; compiler would complain if a new subclass is added
    }

Verification Steps

1. Place the sealed class and function in a Kotlin file.
2. Comment out the is ProfileNavState.Error branch.
3. Recompile; you should see an error like “when expression must be exhaustive”.
4. Restore the branch and the code compiles cleanly.

Trade‑offs and Limitations

• File‑local scope: All subclasses must be declared in the same file. In a multi‑module project you cannot add a new state from another module without editing the sealed class file.
• Serialization: Libraries like Gson need extra configuration to discriminate subclasses; kotlinx.serialization handles this automatically with a @SerialName or a type discriminator.
• Large hierarchies: When a sealed class grows beyond ~15 subclasses, the when block can become verbose. Consider nesting sealed classes or switching to a sealed interface (Kotlin 1.9+) for better modularity.

Practical Next Step

Locate a UI component that currently uses a set of boolean flags or a nullable data holder to represent its state. Replace those variables with a sealed class that enumerates every possible state, then rewrite the UI‑rendering logic as an exhaustive when. Run the verification steps above to confirm the compiler now guards against missing cases.
