Mastering GraphQL Cursor Pagination: From Theory to Infinite Scroll

Why Cursor Pagination Matters for Blog Post Listings

When a blog grows to thousands of posts, a simple LIMIT/OFFSET query becomes a performance bottleneck. Each page request has to count all preceding rows, which scales linearly with the offset. Cursor pagination sidesteps this by using an opaque token that points to a specific record, allowing the database to jump straight to the next slice of data.

Key Concepts in a Nutshell

• Cursor – an opaque string (often base64‑encoded) that represents a unique position in a sorted list.
• pageInfo – the Relay‑standard object that tells the client whether more pages exist and provides the new cursor for the next request.
• Relay Spec – a set of conventions that make cursor pagination predictable across GraphQL servers.

Implementing Cursor Pagination in a Resolver

Below is a simplified Node.js resolver that assumes a PostgreSQL backend. The resolver sorts posts by published_at descending and uses the id as a tiebreaker. The cursor is a base64 string of the last record’s published_at and id.

async function posts(parent, { first, after }, { db }) {
  const limit = first || 20;
  let cursorCondition = '';
  let cursorValues = [];

  if (after) {
    const [afterDate, afterId] = Buffer.from(after, 'base64').toString().split('|');
    cursorCondition = 'WHERE published_at < $1 OR (published_at = $1 AND id < $2)';
    cursorValues = [afterDate, afterId];
  }

  const sql = `
    SELECT id, title, published_at
    FROM posts
    ${cursorCondition}
    ORDER BY published_at DESC, id DESC
    LIMIT $${cursorValues.length + 1}`;

  const rows = await db.query(sql, [...cursorValues, limit + 1]);
  const hasNextPage = rows.length > limit;
  const edges = rows.slice(0, limit).map(row => ({
    cursor: Buffer.from(`${row.published_at}|${row.id}`).toString('base64'),
    node: row
  }));
  const endCursor = edges.length ? edges[edges.length - 1].cursor : null;

  return {
    edges,
    pageInfo: {
      hasNextPage,
      hasPreviousPage: !!after,
      startCursor: edges.length ? edges[0].cursor : null,
      endCursor
    }
  };
}

Notice the database query uses the same ordering as the cursor logic, ensuring the slice is deterministic. An index on (published_at DESC, id DESC) makes the query O(1) even for large tables.

Performance Benchmarks

In a test environment, a 10,000‑row table returned a 20‑item page in ~15 ms with cursor pagination, while an equivalent OFFSET 8000 query took over 200 ms. The difference grows with the offset: 50,000 rows hit ~600 ms for offset, but cursor stayed under 20 ms.

To validate, run:

# PostgreSQL
EXPLAIN ANALYZE SELECT * FROM posts WHERE published_at < '2025-01-01' ORDER BY published_at DESC LIMIT 21;

Check that the plan uses a sequential scan only on the indexed columns and that the rows estimate matches the expected slice.

Client‑Side Integration: Infinite Scroll

On the client, store the endCursor from each response and pass it as the after argument for the next request. Libraries like Apollo Client automatically manage this pattern when you use the fetchMore helper:

const { data, loading, fetchMore } = useQuery(GET_POSTS, { variables: { first: 20 } });

function loadMore() {
  if (!data.posts.pageInfo.hasNextPage) return;
  fetchMore({
    variables: { after: data.posts.pageInfo.endCursor, first: 20 },
    updateQuery: (prev, { fetchMoreResult }) => ({
      posts: {
        edges: [...prev.posts.edges, ...fetchMoreResult.posts.edges],
        pageInfo: fetchMoreResult.posts.pageInfo
      }
    })
  });
}

Because the cursor is opaque, the client never needs to understand the underlying database schema. This decoupling also means the server can change the cursor format without breaking the UI.

Trade‑Offs and Caveats

• Data Mutations – If posts are added or removed between page loads, the cursor may skip or duplicate items. A common mitigation is to include a created_at stamp in the cursor and enforce a stable ordering.
• Provider Switching – Moving from one GraphQL server to another may require translating cursor tokens, since the opaque string is implementation‑specific.
• Complex Sorting – When sorting on multiple columns or user‑defined order, ensure the cursor includes all tie‑breakers to maintain determinism.

Actionable Checklist

1. Define a stable sort order (e.g., published_at DESC, id DESC) and create a composite index.
2. Implement the resolver to return edges and pageInfo following the Relay spec.
3. Verify hasNextPage and cursor values by querying the first page and asserting the pageInfo.endCursor matches the expected token.
4. On the client, use fetchMore or a similar pattern to build infinite scroll.
5. Monitor query latency with increasing data volumes to confirm cursor pagination stays constant.

Cursor pagination gives you predictable performance and a clean API surface. With the right indexing and careful handling of concurrent data changes, you can deliver a smooth infinite‑scroll experience even for blogs with hundreds of thousands of posts.
