Managing Object Lifetimes Across Delphi Runtime Packages using Interfaces

The Problem: Memory Leaks in Dynamic Package Loading

When a Delphi application loads a runtime package with LoadPackage, the host often instantiates objects inside that package. With plain TObject references the host must call Free manually. If the package unloads while the host still holds a reference, or the host forgets to free, the process hits access violations or leaks.

Interface-based reference counting solves this. Returning an interface instead of a class lets the object manage its own lifetime. When the last interface reference is released, the object destroys itself even across module boundaries.

The Smallest Suitable Design

A shared interface definition, a TInterfacedObject implementation hidden in the package, and a factory that returns the interface.

Shared Interface

Define a pure abstract interface in a unit both host and package can see without pulling in implementation details.

type
  IMyService = interface
    ['{GUID-GOES-HERE}']
    function ExecuteTask(const Input: string): string;
  end;

Package Implementation

The implementation inherits from TInterfacedObject to get _AddRef and _Release.

type
  TMyService = class(TInterfacedObject, IMyService)
  public
    function ExecuteTask(const Input: string): string;
  end;

function CreateMyService: IMyService;
begin
  Result := TMyService.Create;
end;

Host Consumption

The host loads the package, obtains the factory via GetProcAddress, and holds the interface. Release is automatic on scope exit.

var
  Service: IMyService;
begin
  Service := GetProcAddress('CreateMyService');
end;

Trust and Data Boundaries

The host only sees the interface pointer and VMT. It cannot access private fields or memory layout of TMyService. This reduces coupling and lets the package change internals without recompiling the host.

Operational Checks

Validate the factory returns non‑nil, and that reference count increments on assignment and decrements on scope exit.

• Log or breakpoint in TMyService destructor to confirm destruction timing.
• Assign the interface inside a limited scope and verify destructor fires after exit.
• Enable ReportMemoryLeaksOnShutdown and repeat load/unload cycles to confirm no growth.

Failure Modes

Scenario	Result	Mitigation
Returning TObject cast to interface	Access violation	Implement _AddRef/_Release via TInterfacedObject
Manual Free on interface	Double free	Never call Free on interface variables
Circular references	Leak	Break cycles or use weak references before unload

When the Design Changes

On Win32/Win64 this pattern is stable. On mobile targets prior to Delphi 10.4 Sydney, ARC behavior differed from desktop TInterfacedObject counting, so test on each target platform.

If the host needs deterministic destruction at an exact moment rather than on reference count zero, replace the interface with an explicit lifecycle manager or DisposeOf call.
