Ktor JWT Authentication with a Minimal Revocation List: An Architecture Note

Problem Statement

When a Ktor API relies on JWTs for stateless authentication, tokens can never be revoked once issued. In many production scenarios—password resets, compromised accounts, or policy changes—revocation is essential. This article shows how to add a lightweight revocation layer without compromising Ktor’s performance or scalability.

Functional Requirements

• Validate JWT signature, issuer, audience, and expiration using Ktor’s Authentication plugin.
• Support revocation of individual tokens identified by their jti claim.
• Keep the revocation check fast enough for high‑throughput APIs.
• Expose only two public endpoints: API calls (HTTPS) and an admin endpoint for revocation management.
• Provide audit logging for authentication failures and revocation hits.

Minimal Architecture

The design keeps Ktor’s core responsibilities untouched and adds a single interceptor that consults a relational revocation table. The table is tiny, indexed by jti, and accessed through a HikariCP pool.

Component Diagram (textual)

┌───────────────────────┐
│  Ktor Application      │
│  (HTTPS API + Admin)   │
└────────────┬──────────┘
             │
             ▼
┌───────────────────────┐
│  Authentication Plugin│  ← JWT validation
└────────────┬──────────┘
             │
             ▼
┌───────────────────────┐
│  Revocation Interceptor │  ← JTI lookup
└────────────┬──────────┘
             │
             ▼
┌───────────────────────┐
│  HikariCP + DB          │  ← Revocation table
└───────────────────────┘

Database Schema

Column	Type	Notes
jti	VARCHAR(64) PRIMARY KEY	JWT ID claim
revoked_at	TIMESTAMP	When revocation was recorded
reason	VARCHAR(255)	Optional revocation reason
expires_at	TIMESTAMP	Optional expiry of revocation entry (for cleanup)

Trust & Data Boundaries

• External Interface: Only HTTPS endpoints are exposed. TLS terminates at the application or a load balancer; Ktor trusts the TLS layer for client authenticity.
• Authentication Boundary: The Authentication plugin validates token integrity. It never reads the revocation table.
• Revocation Boundary: The revocation interceptor runs after authentication, ensuring the token is already trusted before checking the revocation list.
• Admin Boundary: The admin endpoints are protected by a separate API key or mutual TLS, preventing unauthorized revocation operations.

Implementation Details

1. Configure the Authentication Plugin

fun Application.configureAuth() {
    install(Authentication) {
        jwt("auth-jwt") {
            realm = "ktor.io"
            verifier(
                JWT
                    .require(Algorithm.HMAC256(environment.config.property("jwt.secret").getString()))
                    .withIssuer("ktor.io")
                    .withAudience("ktor-api")
                    .build()
            )
            validate { credential ->
                // Basic claim checks – issuer, audience, expiration are handled automatically
                UserIdPrincipal(credential.payload.getClaim("sub").asString())
            }
        }
    }
}

Run on the application JVM with --module=auth-jwt as the authentication name. The plugin automatically rejects tampered or expired tokens.

2. Add the Revocation Interceptor

fun Application.configureRevocation() {
    val dataSource = HikariDataSource(HikariConfig().apply {
        jdbcUrl = environment.config.property("database.jdbcUrl").getString()
        driverClassName = "org.postgresql.Driver"
        maximumPoolSize = 10
        isAutoCommit = false
    })

    install(StatusPages) {
        exception<RevokedTokenException> { cause ->
            call.respond(HttpStatusCode.Forbidden, mapOf("error" to "token revoked"))
        }
    }

    intercept(ApplicationCallPipeline.Features) {
        val principal = call.authentication.principal<UserIdPrincipal>()
        if (principal != null) {
            val jti = call.request.headers["X-JTI"] ?: call.request.headers["Authorization"].substringAfter("Bearer ").split(".")[1]
            // Decode payload to get jti if not passed via header
            val payload = JWT.decode(call.request.headers["Authorization"].substringAfter("Bearer ")
            val jtiClaim = payload.getClaim("jti")
            if (jtiClaim != null) {
                val query = "SELECT 1 FROM revocations WHERE jti = ?"
                val isRevoked = dataSource.connection.use { conn ->
                    conn.prepareStatement(query).use { stmt ->
                        stmt.setString(1, jtiClaim.asString())
                        stmt.executeQuery().next()
                    }
                }
                if (isRevoked) throw RevokedTokenException()
            }
        }
    }
}

class RevokedTokenException : RuntimeException()

Key points:

• The interceptor runs after authentication, ensuring only valid tokens reach this step.
• It performs a single‑row lookup, O(1) on the indexed jti column.
• All operations run within the same request context; no state is mutated.

3. Admin Endpoint for Revocation

routing {
    authenticate("admin-api-key") {
        post("/admin/revoke") {
            val jti = call.receive<String>() // Expect JSON body with jti
            val insert = "INSERT INTO revocations (jti, revoked_at, reason) VALUES (?, NOW(), ?)"
            dataSource.connection.use { conn ->
                conn.prepareStatement(insert).use { stmt ->
                    stmt.setString(1, jti)
                    stmt.setString(2, "admin request")
                    stmt.executeUpdate()
                }
            }
            call.respond(HttpStatusCode.OK, mapOf("status" to "revoked"))
        }
    }
}

Protect this route with an API key or mutual TLS. The revocation table is the only stateful element, so it can be replicated or sharded if needed.

Operational Checks

• Health Endpoint: Expose /health that verifies DB connectivity and plugin readiness.
• Audit Logging: Log each RevokedTokenException with timestamp, client IP, and JTI. Avoid logging the raw token.
• Metrics: Record histogram of revocation lookup latency and counter of revocation hits. Use Prometheus or OpenTelemetry exporters.
• Backup Strategy: Schedule nightly WAL‑based backups of the revocation table. A snapshot restores the revocation state instantly.

Failure Modes & Redesign Triggers

1. Revocation Lookup Bottleneck: If latency > 5 ms under load, consider caching recent JTI lookups in Redis or adding a read‑replica pool.
2. Replication Lag: In a multi‑node deployment, if a token is revoked on one node but accepted on another, the revocation store must be replicated (e.g., via PostgreSQL logical replication) or a distributed cache must be used.
3. Data Loss: Loss of revocation data allows stale tokens to be accepted. Ensure backups are retained for at least 30 days.
4. Algorithm Weakness: If the signing algorithm drops below RS256/HS512, the entire authentication layer becomes insecure. Upgrade the verifier accordingly.
5. Token Payload Growth: Adding sensitive data to the JWT (e.g., PII) increases the risk if a token is intercepted. Enforce minimal payloads.

Practical Verification Steps

1. Deploy the application locally:

   ./gradlew run -Pjwt.secret=supersecret -Pdatabase.jdbcUrl=jdbc:postgresql://localhost:5432/ktor


2. Generate a test JWT (HS256) with jti=abc123 and sub=alice.
3. Send a request to a protected endpoint. Expect 200 OK.
4. Revoke abc123 via the admin endpoint.
5. Repeat the request; expect 403 Forbidden and a log entry for RevokedTokenException.
6. Run pgbench against the revocation table to confirm lookup latency remains <5 ms.

Conclusion

By leveraging Ktor’s Authentication plugin and adding a lightweight revocation interceptor, you achieve a stateless, scalable authentication layer that still supports token revocation. The design keeps the core logic untouched, introduces minimal state, and provides clear operational hooks for monitoring and auditing. Monitor the revocation lookup latency and replication health; if these thresholds are breached, consider moving to a distributed cache or sharding the revocation table.
