Keeping Ballerina REST APIs and OpenAPI Specs in Sync

The problem: drifting API docs

When you maintain a REST service, the OpenAPI document often falls out of sync with the actual implementation. Manual edits are easy to forget, leading to mismatched request/response schemas, broken client generation, and confusing documentation.

Takeaway: By defining Ballerina services with @Service and @Resource annotations, the compiler can derive a correct OpenAPI 3.0 description directly from the code, keeping the spec and implementation in lockstep.

How Ballerina maps annotations to OpenAPI

Each @Resource function becomes an operation. The annotation’s path and method fields populate the OpenAPI path and operation. Parameter annotations (@QueryParam, @Header, @PathParam) become query, header, or path parameters. The function’s return type and any @BodyParam are used to generate request and response schemas from Ballerina records, maps, or JSON/XML types. The compiler collects all of this into an OpenAPI document.

Worked example: a greeting service

import ballerina/http;
import ballerina/log;

@http:ServiceConfig { basePath: '/greet' }
service greet on new http:Listener(9090) {
    @http:ResourceConfig {
        path: '/{name}',
        method: 'GET'
    }
    function greet(string name) returns string|error {
        log:printInfo('Greeting ' + name);
        return 'Hello, ' + name;
    }
}

Running the OpenAPI generator:

ballerina openapi greet.bal

This creates greet.openapi.yaml in the same directory. The file contains a /greet/{name} path with a GET operation, a path parameter name of type string, and a 200 response whose schema is a string. (The exact YAML is omitted here to avoid inventing output.)

You can verify the generated document matches the running service:

1. Start the service: bal run greet.bal
2. In another terminal, fetch the runtime OpenAPI: curl -s http://localhost:9090/openapi.json
3. Compare the two files, for example with diff -u greet.openapi.yaml <(curl -s http://localhost:9090/openapi.json | yq -P) (you need yq to convert JSON to YAML). If there is no output, the documents are identical.

Limitations and when to add manual annotations

• The generator captures only standard HTTP concepts defined by Ballerina’s mapping rules. Custom headers, non‑standard status codes, or vendor extensions require the openapi:add annotation.
• Security schemes (OAuth2, API key, etc.) are not inferred; you must declare them explicitly with openapi:SecurityScheme and reference them via openapi:Security on the service or resource.
• If you need to override a generated description or summary, use openapi:Description or openapi:Summary on the resource function.

These manual annotations are additive; they do not interfere with the auto‑generated parts.

Actionable checklist

1. Write your service using @Service and @Resource (or @http:ServiceConfig and @http:ResourceConfig as shown).
2. Run ballerina openapi filename.bal to produce the OpenAPI file.
3. Start the service and curl <host>:<port>/openapi.json to confirm runtime consistency.
4. If you need custom headers, security, or non‑standard responses, add the appropriate openapi: annotations.
5. Keep the generated file under version control; treat it as a derived artifact and regenerate after any change to the service.
