Kafka Log Compaction: Keep Only the Latest State Per Key and When to Use It

Why Kafka Log Compaction Matters

In many event‑driven systems you only care about the current state of an entity, not every change that happened over time. Storing every update can bloat disk usage and slow down consumers that need to reconstruct the latest state. Kafka’s log compaction feature solves this by keeping only the most recent record for each key while still allowing the topic to act as a log for new events.

What Log Compaction Does

When a topic’s cleanup.policy is set to compact, the broker asynchronously scans log segments and removes older records that share the same key. The compaction algorithm keeps the newest record for each key in the retained segments, discarding older duplicates. Records without a key are never compacted.

Compaction is separate from the normal retention.ms or retention.bytes policies. A record may survive the retention window until a compaction cycle runs, so you can still see old data if compaction is delayed.

When to Use Compaction

• State stores – Rebuilding a key/value store from the topic (e.g., Kafka Streams state stores).
• Configuration topics – Storing the latest configuration for services where only the newest change matters.
• Idempotent event streams – Ensuring that consuming the topic yields the latest value without replaying all updates.

Key Configuration Parameters

Parameter	Typical Value	Effect
cleanup.policy	compact	Enables compaction.
segment.bytes	1073741824 (1 GB)	Size of a log segment; smaller segments compact faster but increase overhead.
min.cleanable.dirty.ratio	0.5	Minimum ratio of dirty (uncompacted) data to segment size before compaction starts.
max.compaction.lag.ms	86400000 (24 h)	Maximum age of a record before it becomes eligible for compaction.
delete.retention.ms	86400000	Grace period after a tombstone before the key is removed.

Concrete Example: Enabling Compaction on a Topic

1. Create a compacted topic

   # Run on a broker host where kafka-topics.sh is available
   kafka-topics.sh --bootstrap-server <bootstrap-server> \
     --create \
     --topic user-profile \
     --partitions 3 \
     --replication-factor 2 \
     --config cleanup.policy=compact \
     --config segment.bytes=104857600 \
     --config min.cleanable.dirty.ratio=0.5


   Replace <bootstrap-server> with your broker address. The topic will now run compaction on each partition.

2. Produce multiple updates for the same key

   # Produce three updates for user key "user-123"
   kafka-console-producer.sh --bootstrap-server <bootstrap-server> \
     --topic user-profile \
     --property key.serializer=org.apache.kafka.common.serialization.StringSerializer \
     --property value.serializer=org.apache.kafka.common.serialization.StringSerializer
   > user-123	{"name":"Alice"}
   > user-123	{"name":"Alice A."}
   > user-123	{"name":"Alice B."}


   Each line is a new record with the same key but different value. The console producer will exit after you send the records.

3. Wait for compaction to run

   Compaction runs asynchronously. On a busy broker it may take a few minutes. You can monitor the broker logs for messages like Compaction for user-profile-0 started or use JMX metrics kafka.log:type=Log,name=CompactionRate to see progress.

4. Consume the topic after compaction

   # Consume with earliest offset to see the compacted log
   kafka-console-consumer.sh --bootstrap-server <bootstrap-server> \
     --topic user-profile \
     --from-beginning \
     --property print.key=true \
     --property key.deserializer=org.apache.kafka.common.serialization.StringDeserializer \
     --property value.deserializer=org.apache.kafka.common.serialization.StringDeserializer


   You should see only one record for user-123 – the last value produced. Older records are removed by compaction.

Trade‑offs and Limitations

• Disk Usage During Compaction – Until the compaction job finishes, both old and new segments coexist. This can temporarily double the storage footprint for a partition.
• Delayed Deletion – Compaction is not instant; records may persist until a compaction cycle runs. If you need immediate removal, combine compaction with retention.ms or use tombstones.
• CPU & I/O Load – Compaction consumes broker resources. On high‑volume clusters, monitor CompactionRate and BytesCompacted metrics to avoid throttling.
• Consumer Ordering Guarantees – Compaction preserves record order within a segment but removes older records. Consumers that rely on seeing every historical event will break.
• Key‑Only Records – Records without a key are ignored by compaction. Ensure your producer always sends keys if you expect compaction to apply.

Practical Check: Verify Compaction Effectiveness

After compaction, run:

# List topic configs to confirm cleanup.policy
kafka-configs.sh --bootstrap-server <bootstrap-server> \
  --describe \
  --entity-type topics \
  --entity-name user-profile

Look for cleanup.policy=compact and segment.bytes values. Then inspect the log directory on the broker (e.g., /var/lib/kafka/data/user-profile-0/) for the number of segments. A reduced segment count after compaction indicates successful cleanup.

When to Avoid Compaction

If your application needs a complete audit trail or depends on replaying every event, compaction is unsuitable. In such cases stick to retention.ms or retention.bytes alone. Also, if you have very short‑lived keys that change frequently, compaction may not keep up, leading to stale data.

Actionable Takeaway

Enable cleanup.policy=compact on topics that represent latest‑state snapshots, but pair it with sensible segment.bytes and min.cleanable.dirty.ratio values. Monitor compaction metrics, and if you need to delete a key entirely, emit a tombstone (a record with the key and a null value) and adjust delete.retention.ms accordingly. By doing so you keep your Kafka cluster lean while still providing a reliable source of truth for consumers.
