Integrating Twilio Verify for OTPs in a Spring Boot Application

Desired Outcome

By the end of this article you will be able to:

• Configure a Twilio Verify service in the Twilio console.
• Send a one‑time password (OTP) via SMS or Voice from a Spring Boot application.
• Validate the OTP entered by a user and handle common error scenarios.
• Check delivery status and cost in the Twilio console and monitor usage.

Prerequisites

• A Twilio account with a verified phone number and an active Verify service. Note: The service SID is required.
• Java 17+ and Maven or Gradle for building the Spring Boot project.
• Spring Boot 3.x (or 2.7.x) with the spring-boot-starter-web and spring-boot-starter-validation dependencies.
• Environment variables or a secrets manager to provide TWILIO_ACCOUNT_SID and TWILIO_AUTH_TOKEN at runtime.
• Network access to Twilio’s REST endpoints (https://verify.twilio.com).

Step 1: Create a Verify Service in the Console

1. Log in to the Twilio Console. 2. Navigate to Verify > Services and click Create new service. 3. Give the service a name (e.g., myapp-verify) and click Save. 4. Copy the generated Service SID for later use.

Step 2: Add Twilio Dependencies

For Maven:

<dependency>
  <groupId>com.twilio.sdk</groupId>
  <artifactId>twilio</artifactId>
  <version>9.28.0</version>
</dependency>

For Gradle:

implementation("com.twilio.sdk:twilio:9.28.0")

Step 3: Configure Credentials in application.yml

twilio:
  account-sid: ${TWILIO_ACCOUNT_SID}
  auth-token: ${TWILIO_AUTH_TOKEN}
  verify-service-sid: ${TWILIO_VERIFY_SERVICE_SID}

Use a secrets manager or Docker secrets to inject these variables at runtime. Never commit them to source control.

Step 4: Create a Verify Service Bean

Encapsulate Twilio API calls in a Spring @Service so that they can be reused and unit‑tested.

@Service
public class TwilioVerifyService {
    private final VerifyService verifyService;

    public TwilioVerifyService(@Value("${twilio.account-sid}") String accountSid,
                               @Value("${twilio.auth-token}") String authToken,
                               @Value("${twilio.verify-service-sid}") String serviceSid) {
        Twilio.init(accountSid, authToken);
        this.verifyService = VerifyService.creator(serviceSid).create();
    }

    public String sendOtp(String phoneNumber, String channel) {
        Verification verification = Verification.creator(
                verifyService.getSid(),
                phoneNumber,
                channel) // "sms" or "call"
                .create();
        return verification.getSid();
    }

    public Verification checkOtp(String verificationSid, String code) {
        return VerificationCheck.creator(
                verifyService.getSid(),
                code)
                .setVerificationSid(verificationSid)
                .create();
    }
}

Key points:

• The Verification.creator call returns a Verification object containing the sid and status (pending, approved, denied).
• Use VerificationCheck.creator to validate the code entered by the user.
• Handle ApiException for HTTP errors such as 400 (bad request) or 429 (rate limit).

Step 5: Expose REST Endpoints

Define a simple controller to trigger OTP sending and verification. Use DTOs for request validation.

@RestController
@RequestMapping("/auth")
public class AuthController {
    private final TwilioVerifyService verifyService;

    public AuthController(TwilioVerifyService verifyService) {
        this.verifyService = verifyService;
    }

    @PostMapping("/send-otp")
    public ResponseEntity<String> sendOtp(@RequestBody @Valid SendOtpRequest req) {
        String sid = verifyService.sendOtp(req.getPhoneNumber(), req.getChannel());
        return ResponseEntity.ok(sid);
    }

    @PostMapping("/check-otp")
    public ResponseEntity<Boolean> checkOtp(@RequestBody @Valid CheckOtpRequest req) {
        Verification check = verifyService.checkOtp(req.getVerificationSid(), req.getCode());
        boolean approved = "approved".equalsIgnoreCase(check.getStatus());
        return ResponseEntity.ok(approved);
    }
}

@Data @NoArgsConstructor @AllArgsConstructor
class SendOtpRequest {
    @NotBlank
    private String phoneNumber;
    @NotBlank
    private String channel; // "sms" or "call"
}

@Data @NoArgsConstructor @AllArgsConstructor
class CheckOtpRequest {
    @NotBlank
    private String verificationSid;
    @NotBlank
    private String code;
}

Security note: The verificationSid should be stored by the client (e.g., in local storage) and sent back only over HTTPS. Do not expose the Twilio API directly to browsers.

Step 6: Handle Common Errors

Wrap API calls in try‑catch blocks and translate Twilio error codes to user‑friendly messages.

try {
    Verification verification = verifyService.sendOtp(...);
} catch (ApiException e) {
    switch (e.getStatusCode()) {
        case 400: // Bad request
            // e.g., invalid phone number
            break;
        case 429: // Rate limit
            // Inform user to wait
            break;
        default:
            // Generic error
    }
}

Step 7: Verify Delivery and Cost in Twilio Console

1. Navigate to Verify > Services and click your service.
2. Under Verifications, locate the verificationSid used in your request.
3. Check the Status column: approved indicates successful delivery and code entry.
4. Under SMS or Voice tabs, review the Cost column to see the per‑message charge for the destination country.
5. Use the API Explorer or curl to fetch a verification’s status programmatically:

   curl -X GET "https://verify.twilio.com/v2/Services/{ServiceSid}/Verifications/{VerificationSid}" \
        -u {AccountSid}:{AuthToken}


Step 8: Unit Testing with a Mocked Twilio Client

Use Mockito or WireMock to simulate Twilio responses without incurring real costs.

@ExtendWith(MockitoExtension.class)
class TwilioVerifyServiceTest {
    @Mock
    private VerifyService mockService;

    @InjectMocks
    private TwilioVerifyService verifyService;

    @Test
    void sendOtp_success() {
        Verification mockVerification = mock(Verification.class);
        when(mockVerification.getSid()).thenReturn("VAXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX");
        when(mockService.create()).thenReturn(mockVerification);

        String sid = verifyService.sendOtp("+15551234567", "sms");
        assertEquals("VAXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX", sid);
    }
}

Expected Checks and Recovery Options

• Check 1: HTTP 200 response – indicates the request reached Twilio. Log the verificationSid for later reference.
• Check 2: Status in console – should be pending immediately after send, then approved or denied after user input.
• Check 3: Cost per message – compare against your budget. If costs exceed expectations, consider using call channel or a different Twilio region.
• Recovery: 429 Too Many Requests – implement exponential back‑off and notify the user to retry after a short pause.
• Recovery: 40004 Invalid Phone Number – validate the phone number format client‑side using libphonenumber before sending.
• Recovery: 20404 Resource Not Found – verify that the serviceSid and verificationSid are correct and that the Verify service is active.

Practical Verification Checklist

Checklist Item	How to Verify
OTP sent via SMS	Receive the message on the target device.
OTP validated correctly	Enter the code in the app and confirm the API returns approved.
Cost matches console	Check the console’s cost column for the message.
Rate limit handling	Trigger multiple sends in quick succession and observe 429 responses.

Limitations

• Twilio Verify enforces a minimum OTP length (typically 6 digits). Adjust your client UI accordingly.
• OTP expiry is governed by Twilio’s default (usually 5 minutes). If your use case requires a different window, configure it in the Verify service settings.
• SMS delivery can be delayed by carrier networks; consider fallback to Voice calls for time‑critical flows.
• Costs are per message and vary by destination country. Monitor the Twilio usage dashboard to avoid unexpected charges.

Conclusion

By following this guide you can reliably integrate Twilio Verify into a Spring Boot application, handle common errors gracefully, and monitor delivery and cost in real time. The modular service design makes unit testing straightforward and keeps your credentials secure.
