Instrument a Spring Boot Microservice with OpenTelemetry Auto-Instrumentation and Jaeger

Goal

Enable end-to-end tracing for a Spring Boot microservice without modifying application source code. By using the OpenTelemetry Java agent, you can automatically generate spans for HTTP requests, JDBC queries, and gRPC calls, then export them to a Jaeger backend via the OpenTelemetry Protocol (OTLP) over gRPC.

Prerequisites

• Java 17 or newer installed.
• Spring Boot 2.7+ or 3.x.
• A Jaeger instance reachable on port 14250 (OTLP gRPC endpoint).
• Network access to the Jaeger UI on port 16686.

Setup Procedure

1. Download the Java Agent

   Download the latest otel-javaagent.jar from the official OpenTelemetry Java instrumentation releases. This JAR acts as a runtime agent that modifies bytecode to inject tracing logic.

2. Configure Agent Parameters

   Configuration can be handled via system properties or a YAML file. Using a YAML file is recommended for complex environments to avoid excessively long startup commands.

   otel:
     service:
       name: my-spring-service
     resource:
       attributes:
         - service.namespace=demo
     sampler:
       type: probability
       param: 0.1
     exporter:
       otlp:
         endpoint: http://jaeger-collector:14250
         compression: gzip
     logging:
       level: info


   The sampler.param: 0.1 setting implements probability sampling, capturing 10% of traces to reduce telemetry overhead and JVM memory pressure.

3. Launch the Application

   Run the application by passing the -javaagent flag. This must be specified before the -jar argument.

   # Running via CLI
   java -javaagent:/path/to/otel-javaagent.jar \
        -Dotel.config.file=/path/to/otel-configuration.yaml \
        -jar myapp.jar


   For containerized deployments, include the agent and config in your Dockerfile:

   FROM eclipse-temurin:17-jre-alpine
   WORKDIR /app
   COPY myapp.jar .
   COPY otel-javaagent.jar .
   COPY otel-configuration.yaml .
   ENTRYPOINT ["java", "-javaagent:/app/otel-javaagent.jar", "-Dotel.config.file=/app/otel-configuration.yaml", "-jar", "myapp.jar"]


Verification

To confirm the instrumentation is active and communicating with the backend:

• Trigger Traffic: Execute a request against your service: curl -i http://localhost:8080/api/hello.
• Inspect Jaeger UI: Navigate to http://localhost:16686, select my-spring-service from the service dropdown, and click Find Traces.
• Diagnostic Logs: If traces are missing, restart the app with -Dotel.logging.level=debug. Search the logs for SpanExporter events to verify if spans are being sent or if the agent is encountering connection timeouts.

Operational Checks & Limitations

Check	Expected Result	Risk/Limitation
Memory Usage	JVM heap increase of ~20-50MB	May cause OOM if -Xmx is too tight
Sampling Rate	~10% of requests traced	Low rates may miss intermittent errors
Context Propagation	Continuous trace across services	Custom HTTP clients may require manual propagation

Recovery & Troubleshooting

Issue: No traces appear in Jaeger

• Verify network connectivity to the OTLP port: telnet jaeger-collector 14250.
• Ensure the otel.exporter.otlp.endpoint is correct. Note that OTLP gRPC typically uses port 4317 or 14250 depending on the Jaeger version.

Issue: High Resource Consumption

• Lower the sampling rate (e.g., param: 0.01).
• Disable specific instrumentations that are too noisy using -Dotel.instrumentation.jdbc.enabled=false.

Rollback: To remove instrumentation, remove the -javaagent and -Dotel.config.file flags from the startup command and restart the JVM.
