Implementing Room-Based Matchmaking and State Sync in Photon Realtime

Multiplayer applications face a fundamental challenge: efficiently grouping players into sessions and ensuring all participants see a consistent game state. Photon Realtime addresses this using a 'Room' architecture, where a central server manages the lifecycle of a group and synchronizes data between clients. This guide demonstrates how to implement metadata-based matchmaking and state synchronization using observable properties.

Prerequisites

Before implementing the network layer, ensure the following are configured:

• Photon AppID: A Realtime-type ID generated from the Photon Dashboard.
• SDK Integration: The Photon SDK installed in your project (C#, Java, or C++).
• Event-Driven Architecture: A class structure capable of handling asynchronous callbacks.

Establishing Connection and Lifecycle Callbacks

Photon uses a ConnectionSettings object to define the network topology, including the AppId and AppVersion. To respond to network events, you must implement the RoomCallbacks interface, which listens for lifecycle events such as joining a room or disconnecting.

// Example implementation in C#
public class NetworkManager : MonoBehaviour, RoomCallbacks {
    private LoadClient client;

    void Start() {
        ConnectionSettings settings = new ConnectionSettings() {
            AppId = "YOUR_APP_ID_HERE",
            AppVersion = "1.0",
        };
        client = new LoadClient();
        client.Callbacks = this;
        client.ConnectUsingSettings(settings);
    }

    public void OnConnected() {
        // Triggered when the client successfully connects to the Photon server
        Debug.Log("Connected to Server. Ready for matchmaking.");
    }

    public void OnJoinedRoom(Room room) {
        // Triggered when the client successfully enters a room
        Debug.Log($"Joined room: {room.RoomName}");
    }
}

Matchmaking via Room Properties

Hardcoding room names is inefficient for scaling. Instead, use Room Properties—metadata key-value pairs—to filter rooms based on game parameters (e.g., map name or difficulty) before a client joins.

To create a room with specific matchmaking metadata, configure a CreateRoomRequest:

CreateRoomRequest request = new CreateRoomRequest() {
    RoomName = "MapA_Lobby",
    MaxPlayers = 4,
    CustomProperties = new Dictionary<string, object>() {
        { "MapType", "Forest" },
        { "Difficulty", "Hard" }
    }
};
client.CreateRoom(request);

Clients searching for a game should use FindRandomRoomRequest with a property filter. The server will only return rooms where the CustomProperties match the requested criteria, reducing the need for clients to join and leave rooms to find a match.

Synchronizing State: Observable Properties vs. RPCs

Once players are in a room, you must choose the correct synchronization method based on the data type. Photon provides two primary mechanisms: Observable Properties and Remote Procedure Calls (RPCs).

Observable Properties for Continuous State

Observable properties are designed for data that changes frequently, such as health points or coordinates. When a property is updated on one client, Photon automatically broadcasts the change to all other connected clients.

RPCs for Discrete Events

RPCs are used for "one-time" events, such as a player firing a weapon or sending a chat message. Because RPCs are asynchronous, developers must implement client-side prediction to mask network latency and prevent the game from feeling unresponsive.

Method	Best Use Case	Sync Logic	Overhead
Observable Properties	High-frequency data (Health, Position)	Automatic on change	Low
RPCs	Instant events (Jump, Chat, Fire)	Manual call per event	Variable

Verifying Synchronization and Performance

To ensure state synchronization is functioning correctly and within limits, perform the following checks:

1. Multi-Client Test: Launch two instances of the application and join the same Room ID.
2. Property Trigger: On Client A, update a property (e.g., room.SetCustomProperty("Health", 80)). Confirm that Client B's OnPropertyChanged event triggers and reflects the value 80.
3. CCU Monitoring: Check the Photon Dashboard to monitor Concurrent User (CCU) counts. Exceeding your subscription limit will result in connection rejections.
4. Message Rate: Monitor the "Message Rate" metric in the dashboard to ensure high-frequency updates aren't saturating the bandwidth.
