Implementing Parallel Regions in an SDL State Machine: A Step‑by‑Step Guide
Learn how to model concurrent sub‑states in SDL using parallel regions, from prerequisites to simulation and model‑checking. This guide walks through a concrete example, highlights common pitfalls, and shows how to verify correct behavior.
18 Aug 2026, 02:35 UTC

Desired Outcome
By the end of this guide you will have a working SDL state machine that uses parallel regions to model two independent sub‑states that can be active simultaneously. You will be able to simulate the model, check for deadlocks, and verify that transitions target the correct region.
Prerequisites
- Commercial SDL modeling tool installed (e.g., SDL Studio 3.2.2, SCADE System 5.3, or equivalent). The tool must support the
parallelkeyword and integrated model‑checking. - Basic knowledge of SDL syntax: states, transitions, events, and actions.
- Administrative access to create and modify projects on the machine.
- Optional: a test harness or external system to generate events for simulation.
Step‑by‑Step Construction
- Create a New Project
- Launch the SDL tool and select New Project → State Machine.
- Name the project
ParallelDemoand choose a location on disk. - Verify that the project is set to SDL version 3.2.2 or later.
- Define the Parent State
- Create a state named
Processingin the main state machine. - In the state properties, check the box labeled Parallel (or add the keyword
parallelin the advanced text editor). - Set the initial state of
ProcessingtoStart(the default).
- Create a state named
- Add Nested States (Regions)
- Within
Processing, add two child states:InputandOutput. Each of these becomes a parallel region. - Give each region a unique name and add entry/exit actions. Example:
state Input entry: log("Input entered") exit: log("Input exited") end state Output entry: log("Output entered") exit: log("Output exited") end
- Within
- Define Transitions Within Regions
- In
Input, add a transition on eventdata_readyto a sub‑stateProcessData.state ProcessData entry: log("Processing data") end transition Input.process_data event: data_ready target: ProcessData end - In
Output, add a transition on eventsend_completeto a sub‑stateSendAck.state SendAck entry: log("Sending acknowledgment") end transition Output.send_ack event: send_complete target: SendAck end
- In
- Transitions Between Regions (Optional)
- To coordinate between regions, use a wildcard transition that targets both. Example: a global event
resetthat brings both regions back to their initial sub‑state.transition Processing.reset event: reset target: Input.Start, Output.Start end
- To coordinate between regions, use a wildcard transition that targets both. Example: a global event
- Validate Syntax and Names
- Run the tool’s syntax checker. Confirm that region names
InputandOutputare unique withinProcessing. - Check that all transitions explicitly reference a region or use a wildcard. Ambiguous targets are flagged as errors.
- Run the tool’s syntax checker. Confirm that region names
- Simulate the Model
- Start the simulation engine from the tool’s toolbar.
- Send events manually or via the test harness:
data_ready,send_complete,reset. - Observe the state diagram: both
ProcessDataandSendAckshould be active concurrently when their events occur. - Use the State History view to verify that transitions are evaluated independently.
- Run Model‑Checking
- Open the Model‑Check panel and select the property set:
No Deadlock,Event Propagation. - Execute the check. The report should list no violations if transitions are correctly scoped.
- Review any warnings about unreachable states or missing exit conditions.
- Open the Model‑Check panel and select the property set:
- Recover from Common Issues
- Ambiguous Transition Target: If the checker flags a transition, ensure you prefix the target with the region name, e.g.,
Input.ProcessData. - Unintended Wildcard Capture: If a wildcard transition consumes events meant for a specific region, replace it with a region‑specific transition.
- Missing Exit Condition: If a region has no exit state, the simulation may hang. Add an explicit
Exitstate or a transition that brings the region back to its initial state. - Deadlock Reported: Verify that all parallel regions have at least one exit path. If a region can become stuck, introduce a timeout transition or a global reset.
- Ambiguous Transition Target: If the checker flags a transition, ensure you prefix the target with the region name, e.g.,
- Export and Deploy
- Once verified, export the model as a target‑specific code file (e.g., C, Ada) using the tool’s code generator.
- Integrate the generated module into your system, ensuring that the event dispatching layer sends the correct SDL events.
Expected Checks and Verification
- Simulation Log: Confirm that entry and exit actions fire for both regions independently.
- State Diagram: At any simulation step, the diagram should show two active leaf states under
Processing. - Model‑Check Report: No deadlock or unreachable state warnings. If any appear, follow the recovery steps above.
- Runtime Monitoring: In a deployed system, use a watchdog to detect if either region remains in a non‑terminal state beyond a threshold.
Practical Tips
- Keep region names short but descriptive to avoid confusion when referencing them in transitions.
- Use the tool’s Transition Editor to visually confirm that a transition’s source and target are correctly linked to the intended region.
- When adding new regions, immediately run a quick simulation to ensure the parent state’s parallel flag remains active.
- Document each region’s purpose in the model’s comments; this aids future maintenance.
Limitations and Caveats
- Parallel regions are only supported in SDL versions 3.0+; older tools will reject the
parallelkeyword. - Model‑checking performance degrades with many regions and complex transitions; consider modularizing the state machine if you hit timeouts.
- Some commercial tools may require a separate license for the model‑checking feature.
- Runtime execution of parallel regions depends on the underlying code generator’s support for concurrency (e.g., multi‑threaded vs. cooperative scheduling).
Conclusion
Parallel regions provide a clean way to model concurrent behavior in SDL. By following this guide—defining unique regions, explicitly targeting transitions, and validating through simulation and model‑checking—you can build robust, deadlock‑free state machines that reflect real‑world concurrent processes.
