Implementing OAuth2 Security with Swagger Annotations in Spring Boot

Why Use a Global OAuth2 Scheme?

When an API requires OAuth2, you normally need to annotate every @Operation or @ApiOperation with a security reference. That repetition is error‑prone and clutters the code. Springdoc‑OpenAPI lets you declare a single @SecurityScheme that the entire specification consumes. Once the scheme is defined, you can apply it at the controller or method level with @SecurityRequirement, and Swagger‑UI will render an "Authorize" button that drives the OAuth2 flow.

Defining the Security Scheme

Place the scheme declaration in a configuration class that is scanned by Springdoc. The annotation must appear before any operation annotations; otherwise the generated spec will omit the security section.

@Configuration
@SecurityScheme(
    name = "oauth2",
    type = SecuritySchemeType.OAUTH2,
    flows = @OAuthFlows(
        authorizationCode = @OAuthFlow(
            authorizationUrl = "https://auth.example.com/oauth/authorize",
            tokenUrl = "https://auth.example.com/oauth/token",
            scopes = {
                @OAuthScope(name = "read", description = "Read access"),
                @OAuthScope(name = "write", description = "Write access")
            }
        )
    )
)
public class OpenApiConfig {
    // No additional beans are required for the spec itself
}

Key points:

• name is the identifier used in @SecurityRequirement.
• Use SecuritySchemeType.OAUTH2 for OAuth2; other types (APIKEY, HTTP, etc.) are also supported.
• The authorizationUrl and tokenUrl must be reachable from the browser that opens Swagger‑UI.

Mapping the Scheme to Endpoints

Apply @SecurityRequirement(name = "oauth2") to a controller class or individual methods. The annotation automatically injects a security array into the OpenAPI operation.

@RestController
@RequestMapping("/api/v1/items")
@SecurityRequirement(name = "oauth2")
public class ItemController {

    @GetMapping
    @Operation(summary = "List items")
    public List<Item> list() { /* ... */ }

    @PostMapping
    @Operation(summary = "Create item")
    @SecurityRequirement(name = "oauth2", scopes = {"write"})
    public Item create(@RequestBody Item item) { /* ... */ }
}

Notice the method‑level override that restricts the write scope for the POST endpoint. If you omit scopes, the operation inherits all scopes defined in the scheme.

Example Controller

Below is a minimal controller that demonstrates both read and write operations with the OAuth2 scheme applied.

@RestController
@RequestMapping("/api/v1/users")
@SecurityRequirement(name = "oauth2")
public class UserController {

    @GetMapping
    @Operation(summary = "Get all users", description = "Requires read scope.")
    public List<User> getAll() { return userService.findAll(); }

    @PostMapping
    @Operation(summary = "Create user", description = "Requires write scope.")
    @SecurityRequirement(name = "oauth2", scopes = {"write"})
    public User create(@RequestBody User user) { return userService.save(user); }
}

Verifying the Generated Spec

1. Inspect the JSON: Open /v3/api-docs in the browser. Search for components.securitySchemes – it should contain an oauth2 entry with the URLs and scopes you defined.
   • Each operation that has @SecurityRequirement will have a security array referencing the scheme.
2. Test Swagger‑UI: Navigate to /swagger-ui.html (or /swagger-ui/index.html depending on your setup). The "Authorize" button should show an OAuth2 tab. Clicking it should open the authorization server’s consent screen.
   • After granting access, Swagger‑UI attaches the returned access_token to subsequent requests automatically.
3. Manual call: Use curl or Postman. Example:

   curl -H "Authorization: Bearer <token>" http://localhost:8080/api/v1/users


   The request should succeed only if the token is present and has the required scope.

Common Pitfalls and Limits

• Annotation Order: If @SecurityScheme appears after @Operation annotations, Springdoc ignores it. Always declare the scheme first.
• Swagger‑2 vs OpenAPI‑3 Mix‑ups: Using legacy @Api or @ApiOperation can suppress the security field. Stick to OpenAPI 3 annotations from io.swagger.v3.oas.annotations.
• HTTPS with Self‑Signed Certs: Swagger‑UI runs in the browser; if the authorization server uses a self‑signed certificate, the browser may block the OAuth2 request. Either use a trusted cert or configure the browser to accept it.
• Class‑Level Overrides: Applying @SecurityRequirement on a class overrides method‑level annotations. If a method is meant to be public, you must explicitly annotate it with @SecurityRequirement(name = "oauth2", scopes = {}) or remove the class annotation.
• Missing tokenUrl: Without a token endpoint, the UI can’t exchange the code for a token, resulting in a 400 error. Verify the endpoint is reachable.
• Scope Mis‑configuration: If the scopes in @SecurityRequirement don’t match those defined in the scheme, Swagger‑UI will still render but the authorization server will reject the request.

Conclusion

Defining a single OAuth2 @SecurityScheme and mapping it with @SecurityRequirement keeps your Spring Boot API documentation clean and functional. Verify the spec via /v3/api-docs and the UI, and watch out for the common ordering and configuration mistakes highlighted above. Once in place, Swagger‑UI becomes a powerful tool for developers to test secured endpoints directly from the browser.
