Implement weight‑based traffic splitting in Traefik Mesh with TrafficSplit

Overview

This guide shows how to configure weight‑based traffic splitting in Traefik Mesh so that a portion of incoming requests goes to one version of a service and the remainder to another version, without modifying the application.

Desired outcome

Route, for example, 70 % of traffic to version v1 and 30 % to version v2 of a service named myservice.

Prerequisites

• A Kubernetes cluster (v1.21 or newer) with Traefik Mesh installed and mTLS enabled.
• kubectl configured with cluster‑admin or mesh‑admin permissions.
• Two Deployments that represent the service versions, each labelled with app=myservice and a version label, e.g. version=v1 or version=v2.
• A headless Service that selects both Deployments via the app=myservice label (no version label).

Procedure

1. Save the following TrafficSplit manifest to a file, e.g. trafficsplit-myservice.yaml. Adjust the namespace, service name, and weight values as needed.

apiVersion: split.traefik.io/v1alpha1
kind: TrafficSplit
metadata:
  name: myservice-split
  namespace: default   # replace with your namespace
spec:
  service: myservice   # must match the Service that selects both Deployments
  backends:
    - service: myservice-v1   # optional: you can reference the same Service and use selectors
      weight: 70
      tags:
        version: v1
    - service: myservice-v2
      weight: 30
      tags:
        version: v2

1. Apply the manifest:

kubectl apply -f trafficsplit-myservice.yaml

Traefik Mesh controller will reconcile the TrafficSplit and update the Envoy sidecar configuration for the matching pods.

Expected checks

1. Verify the Mesh controller is ready:

kubectl get meshcontroller -n traefik-mesh -o wide

Look for READY: True.

1. Confirm the TrafficSplit was accepted:

kubectl get trafficsplits -n default -o yaml

The observedGeneration should match the metadata.generation of the object.

1. Inspect the generated proxy configuration (optional):

kubectl get proxies -n default -l app=myservice -o yaml

Each proxy’s spec.config should contain a weighted cluster referencing the two backends.

1. Validate request distribution:

# Assuming an ingress exposes the service at http://myservice.example.com
for i in {1..100}; do
  curl -s -H "Host: myservice.example.com" http:/// | grep -o "X-Version: [^"]*";
done | sort | uniq -c

Each version should return a distinct header (e.g., X-Version: v1 or X-Version: v2) applied by the Deployments. The counts should approximate the 70/30 split.

Recovery options

• If the split does not behave as expected, delete the TrafficSplit to revert to default routing:

kubectl delete trafficsplit myservice-split -n default

• Check the Mesh controller logs for errors:

kubectl logs -n traefik-mesh deploy/traefik-mesh-controller

• Correct any issues (e.g., mismatched labels, weight sum not equal to 100) and re‑apply the manifest.

Limitations

• Traefik Mesh traffic splitting requires mTLS to be enabled; disabling mTLS prevents the controller from applying the TrafficSplit resource.
• The Service referenced in the TrafficSplit must select all pod versions intended for the split. If a version’s pods lack the Service’s selector, they will be excluded from the weighted routing.
• Weight values must be integers that sum to 100; otherwise the controller will reject the resource.

Practical verification tip

To avoid reliance on external tools, have each version emit a unique response header (e.g., X-Version: v1) in its container. Then a simple curl loop as shown above provides an immediate, observable check of the distribution.
