Implement Server‑Side Pagination, Sorting, and Filtering with Angular Material MatTable

Desired Outcome

Create a read‑only mat-table that loads data from a backend API on demand, updating the view whenever the user changes the page, sorts a column, or types a filter term. The table should show a loading indicator while waiting for the server and display an error message if the request fails.

Prerequisites

• Angular CLI version 15 or newer.
• Packages @angular/material and @angular/cdk installed in the project.
• Basic knowledge of Angular components, RxJS Observables, and TypeScript.
• A data service that can accept pagination, sorting, and filter parameters and returns an object with data (array of rows) and totalCount (total number of records).

Procedure

1. Import the required Material modules in the feature module (e.g., app.module.ts or a dedicated module):

   import { MatTableModule } from '@angular/material/table';
   import { MatPaginatorModule } from '@angular/material/paginator';
   import { MatSortModule } from '@angular/material/sort';
   import { MatInputModule } from '@angular/material/input';

   @NgModule({
     imports: [
       MatTableModule,
       MatPaginatorModule,
       MatSortModule,
       MatInputModule,
       // other imports
     ],
   })
   export class MyFeatureModule {}

2. Create a custom DataSource class. Place it in a file like server-data-source.ts:

   import { DataSource } from '@angular/cdk/collections';
   import { Observable, Subject, merge, of } from 'rxjs';
   import { map, catchError, startWith, switchMap, debounceTime } from 'rxjs/operators';

   export class ServerDataSource extends DataSource {
     private _paginatorPage$ = new Subject();
     private _sortChange$ = new Subject();
     private _filterChange$ = new Subject();

     constructor(private dataService: YourDataService) {
       super();
     }

     /** Called by the table to obtain an observable stream of data rows */
     connect(): Observable {
       const dataRequests = [
         this._paginatorPage$,
         this._sortChange$,
         this._filterChange$.pipe(debounceTime(300))
       ];

       return merge(...dataRequests).pipe(
         startWith(null),
         switchMap(() => {
           // Build request payload from current state
           const payload = {
             pageIndex: this.paginator?.pageIndex ?? 0,
             pageSize: this.paginator?.pageSize ?? 10,
             sortActive: this.sort?.active ?? '',
             sortDirection: this.sort?.direction ?? '',
             filter: this.filterValue
           };
           return this.dataService.getData(payload).pipe(
             map(res => res.data),
             catchError(() => of([])) // empty array on error
           );
         })
       );
     }

     disconnect(): void {
       this._paginatorPage$.complete();
       this._sortChange$.complete();
       this._filterChange$.complete();
     }

     // Setters used by the template
     set paginator(p: MatPaginator) { this._paginator = p; }
     private _paginator: MatPaginator | null;
     get paginator(): MatPaginator | null { return this._paginator; }

     set sort(s: MatSort) { this._sort = s; }
     private _sort: MatSort | null;
     get sort(): MatSort | null { return this._sort; }

     set filterValue(v: string) {
       this._filterChange$.next(v);
     }
     private filterValue = '';
   }


3. Use the data source in a component template (my-table.component.html):

   <div class="example-container">
     <mat-form-field>
       <input matInput (keyup)="dataSource.filterValue = $event.target.value" placeholder="Filter">
     </mat-form-field>

     <table mat-table [dataSource]="dataSource" class="example-table">

       <ng-container matColumnDef="name">
         <th mat-header-cell *matHeaderCellDef mat-sort-header> Name </th>
         <td mat-cell *matCellDef="let row">{{row.name}}</td>
       </ng-container>



       <tr mat-header-row *matHeaderRowDef="displayedColumns"></tr>
       <tr mat-row *matRowDef="let row; columns: displayedColumns"></tr>
     </table>

     <mat-paginator [pageSizeOptions]="[5, 10, 25]"></mat-paginator>

     <div *ngIf="dataSource.isLoading$ | async" class="example-loading">
       Loading...
     </div>
     <div *ngIf="dataSource.hasError$ | async" class="example-error">
       Failed to load data. <button mat-button (click)="reload()">Retry</button>
     </div>
   </div>


4. In the component class (my-table.component.ts) instantiate the data source and wire paginator/sort:

   import { Component, OnInit, ViewChild } from '@angular/core';
   import { MatPaginator } from '@angular/material/paginator';
   import { MatSort } from '@angular/material/sort';
   import { ServerDataSource } from './server-data-source';
   import { YourDataService } from './your-data.service';

   @Component({
     selector: 'app-my-table',
     templateUrl: './my-table.component.html',
     styleUrls: ['./my-table.component.css']
   })
   export class MyTableComponent implements OnInit {
     displayedColumns: string[] = ['name', /* other columns */];
     dataSource: ServerDataSource;

     @ViewChild(MatPaginator) paginator!: MatPaginator;
     @ViewChild(MatSort) sort!: MatSort;

     constructor(private dataService: YourDataService) {
       this.dataSource = new ServerDataSource(this.dataService);
     }

     ngOnInit(): void {
       this.dataSource.paginator = this.paginator;
       this.dataSource.sort = this.sort;
     }

     reload(): void {
       // forces a refresh by paging to first page
       this.paginator.firstPage();
     }
   }


5. Add minimal styling (my-table.component.css) to show loading/error states:

   .example-container {
     display: flex;
     flex-direction: column;
   }
   .example-table {
     width: 100%;
   }
   .example-loading {
     align-self: center;
     padding: 16px;
   }
   .example-error {
     align-self: center;
     padding: 16px;
     color: rgba(0,0,0,0.87);
   }


Expected Checks

• On first load the table displays the first page of data returned by the service.
• The paginator shows the correct length (total count) and updates pageIndex when navigating.
• Clicking a column header toggles the sort arrow and triggers a new request with the updated sortActive and sortDirection values.
• Typing in the filter input (after the debounce) sends a request containing the entered filter string.
• In the browser’s DevTools Network tab, each user interaction results in exactly one XHR request with the expected query parameters.
• While a request is pending, the “Loading…” message appears; on error, the error message and retry button are shown.

Recovery Options

• If the service returns an error, the catchError inside the data source returns an empty array, preventing the table from breaking.
• The retry button calls paginator.firstPage(), which forces a fresh request from the first page.
• Optionally, cache the last successful data set in the component and display it as “stale” while a retry is in progress.

Limitations and Practical Verification

• The implementation assumes the backend returns a consistent shape: { data: [], totalCount: number }. Adjust the mapping in ServerDataSource if your API differs.
• Memory leaks can occur if the internal subjects are not completed in disconnect(). Always call disconnect() (handled automatically by the table) or manually clean up in ngOnDestroy if you keep a reference.
• To verify correct behavior, open Chrome DevTools → Network, filter for XHR, and confirm that each pagination change, sort click, or filter keystroke (after debounce) produces a single request with the right parameters. Check that the response data populates the table rows and that the paginator’s length matches the totalCount field.
