Handling Large Datasets in Clarity: Implementing Server-Side Pagination

The Performance Wall of Client-Side Tables

Loading 5,000 rows into a browser table doesn't just slow down the initial page load; it degrades every single interaction. When you bind a massive array to a data grid, the browser must manage thousands of DOM elements, leading to "janky" scrolling and unresponsive filtering. The solution is server-side pagination: shifting the burden of data slicing from the client's memory to the database.

In the Clarity Design System for Angular, the goal is to create a stateless grid. The UI should not know about the entire dataset; it should only know how many items exist in total and which specific slice is currently visible.

Connecting the Data Grid to the Pagination Component

Clarity separates the table display (clr-datagrid) from the navigation controls (clr-pagination). To make them work together for server-side operations, you must synchronize three key pieces of data: the current page index, the page size, and the total record count.

The clr-pagination component acts as the trigger. Instead of the grid automatically slicing an array, you use the (clrPaginationPageChange) event to notify your backend service that the user has moved to a different page. This event provides the new page number, which you then use to construct your API request (e.g., /api/users?page=2&size=10).

Implementation Example: The Stateless Grid Pattern

This example assumes you are using @clr/angular. The key is to ensure the clr-datagrid is bound to a variable that only holds the current page's results.

<clr-datagrid>
  <clr-dg-column>ID</clr-dg-column>
  <clr-dg-column>Name</clr-dg-column>

  <clr-dg-row *ngFor="let user of users">
    <clr-dg-cell>{{user.id}}</clr-dg-cell>
    <clr-dg-cell>{{user.name}}</clr-dg-cell>
  </clr-dg-row>
</clr-datagrid>

<clr-pagination
  [clrPaginationTotalItems]="totalRecords"
  [clrPaginationItemsPerPage]="pageSize"
  (clrPaginationPageChange)="onPageChange($event)">
</clr-pagination>

// component.ts
export class UserListComponent {
  users = [];
  totalRecords = 0;
  pageSize = 10;

  constructor(private userService: UserService) {}

  ngOnInit() {
    this.loadData(1);
  }

  onPageChange(page: number) {
    this.loadData(page);
  }

  loadData(page: number) {
    // The service handles the HTTP request with page and size params
    this.userService.getUsers(page, this.pageSize).subscribe(res => {
      this.users = res.data; // Only 10 items
      this.totalRecords = res.total; // e.g., 5000
    });
  }
}

Execution Details

• Run Location: Angular Component template and TypeScript class.
• Permissions: Requires @clr/angular package installed and imported in the module.
• Expected Result: The DOM should only contain the number of clr-dg-row elements equal to pageSize, regardless of the totalRecords value.
• Risk: If totalRecords is not updated from the server after a filter is applied, the pagination component may allow users to navigate to empty pages.

Critical Trade-offs and Limitations

While server-side pagination solves memory issues, it introduces new complexities:

• Filter Synchronization: If you implement a search bar, you cannot use client-side filtering. You must send the search term to the server, reset the pagination to page 1, and update the clrPaginationTotalItems based on the filtered result count.
• DOM Overhead: Even with pagination, setting a pageSize that is too high (e.g., 500+ rows) can cause rendering lag. For datasets requiring massive single-page views, consider virtual scrolling instead of standard pagination.
• State Management: Since the grid is stateless, refreshing the page will return the user to page 1 unless you persist the page index in the URL query parameters.

Verifying the Implementation

To confirm your pagination is truly server-side and not just hiding rows, perform these checks:

1. Inspect the DOM: Open Browser DevTools. Ensure the number of <clr-dg-row> elements matches your pageSize, not your total dataset size.
2. Network Tab: Click the "Next" button in the pagination component. Verify that a new HTTP request is dispatched with the updated page parameter.
3. Boundary Test: Set totalRecords to a value slightly higher than your current data (e.g., 11 items with a page size of 10). Ensure the second page loads exactly one row and the "Next" button becomes disabled.
