Gazebo ModelPlugin Architecture: Injecting Custom C++ Logic into Simulated Robots

The Problem and the Takeaway

You need custom C++ logic inside a Gazebo simulation — perhaps a specialized controller, sensor noise model, or joint-level force application that ROS 2 controllers cannot express. A ModelPlugin is a shared library loaded by Gazebo at world start that receives a pointer to the physics::Model and an SDF element with your parameters. It runs in Gazebo's main simulation thread, giving you per-step access to joints, links, and sensors via the Update() callback connected to event::Events::ConnectWorldUpdateBegin.

Useful takeaway: ModelPlugins are the right tool when you need deterministic, in-process access to the physics engine at every simulation step. They are the wrong tool for heavy computation (blocks the physics step) or when a ROS 2 controller via ros_gz_bridge can express the same logic — choose one authority per joint to avoid solver fights.

Lifecycle Callbacks: Load, Init, Update

Every ModelPlugin implements up to three entry points:

• Load(physics::ModelPtr model, sdf::ElementPtr sdf) — one-time setup: cache joint/link pointers, parse SDF parameters, create Transport subscribers/publishers.
• Init() — optional post-load initialization after all plugins have loaded; useful for cross-plugin dependencies.
• Update() — your per-step logic, connected to WorldUpdateBegin inside Load(). Fires at every physics iteration (default 1 kHz).

Unfamiliar term: physics::ModelPtr is a shared pointer to the simulated model, providing access to joints (model->GetJoint(\"name\")), links, and sensors (model->GetSensor(\"name\")).

Worked Example: Differential-Drive Plugin

Below is a minimal, complete plugin that reads left/right wheel joint names from SDF, subscribes to /cmd_vel (gz::msgs::Twist), and applies wheel forces in Update() using a simple kinematic model.

1. Plugin Source (diff_drive_plugin.cc)

#include <gz/sim/Model.hh>\n#include <gz/sim/Util.hh>\n#include <gz/plugin/Register.hh>\n#include <gz/transport/Node.hh>\n#include <gz/msgs/Twist.pb.h>\n#include <gz/common/PID.hh>\n\nnamespace my_plugins\n{\nclass DiffDrivePlugin : public gz::sim::System,\n                        public gz::sim::ISystemConfigure,\n                        public gz::sim::ISystemPreUpdate\n{\npublic:\n  void Configure(const gz::sim::Entity &_entity,\n                 const std::shared_ptr &_sdf,\n                 gz::sim::EntityComponentManager &_ecm,\n                 gz::sim::EventManager &/*_eventMgr*/) override\n  {\n    this->model = gz::sim::Model(_entity);\n    if (!this->model.Valid(_ecm)) {\n      gzerr << \"DiffDrivePlugin: invalid model entity\\n\";\n      return;\n    }\n\n    // Parse SDF parameters with guards\n    if (!_sdf->HasElement(\"left_joint\") || !_sdf->HasElement(\"right_joint\")) {\n      gzerr << \"DiffDrivePlugin: missing left_joint or right_joint in SDF\\n\";\n      return;\n    }\n    this->leftJointName = _sdf->Get<std::string>(\"left_joint\");\n    this->rightJointName = _sdf->Get<std::string>(\"right_joint\");\n    this->wheelSeparation = _sdf->Get<double>(\"wheel_separation\", 0.5).first;\n    this->wheelRadius = _sdf->Get<double>(\"wheel_radius\", 0.1).first;\n\n    // Cache joint pointers\n    this->leftJoint = this->model.JointByName(_ecm, this->leftJointName);\n    this->rightJoint = this->model.JointByName(_ecm, this->rightJointName);\n    if (!this->leftJoint || !this->rightJoint) {\n      gzerr << \"DiffDrivePlugin: joints not found\\n\";\n      return;\n    }\n\n    // Transport subscriber for /cmd_vel\n    this->node.Subscribe(\"/cmd_vel\", &DiffDrivePlugin::OnCmdVel, this);\n  }\n\n  void PreUpdate(const gz::sim::UpdateInfo &_info,\n                 gz::sim::EntityComponentManager &_ecm) override\n  {\n    if (_info.paused) return;\n\n    // Throttle to 30 Hz instead of 1 kHz physics rate\n    static gz::common::Time lastUpdate = 0;\n    gz::common::Time now = _info.simTime;\n    if ((now - lastUpdate).Double() < (1.0 / 30.0)) return;\n    lastUpdate = now;\n\n    // Simple differential drive kinematics\n    double v = this->cmdVelLinear;\n    double w = this->cmdVelAngular;\n    double leftVel = (v - w * this->wheelSeparation / 2.0) / this->wheelRadius;\n    double rightVel = (v + w * this->wheelSeparation / 2.0) / this->wheelRadius;\n\n    // Apply velocity commands (SetVelocity fights physics less than SetForce for wheels)\n    this->leftJoint->SetVelocity(0, leftVel);\n    this->rightJoint->SetVelocity(0, rightVel);\n  }\n\nprivate:\n  void OnCmdVel(const gz::msgs::Twist &_msg)\n  {\n    this->cmdVelLinear = _msg.linear().x();\n    this->cmdVelAngular = _msg.angular().z();\n  }\n\n  gz::sim::Model model;\n  gz::transport::Node node;\n  std::string leftJointName, rightJointName;\n  double wheelSeparation = 0.5;\n  double wheelRadius = 0.1;\n  double cmdVelLinear = 0.0;\n  double cmdVelAngular = 0.0;\n  gz::sim::Joint leftJoint = gz::sim::kNullEntity;\n  gz::sim::Joint rightJoint = gz::sim::kNullEntity;\n};\n}\n\nGZ_ADD_PLUGIN(my_plugins::DiffDrivePlugin,\n              gz::sim::System,\n              gz::sim::ISystemConfigure,\n              gz::sim::ISystemPreUpdate)\nGZ_ADD_PLUGIN_ALIAS(my_plugins::DiffDrivePlugin,\n                    \"my_plugins::DiffDrivePlugin\")

2. CMakeLists.txt

cmake_minimum_required(VERSION 3.16)\nproject(diff_drive_plugin LANGUAGES CXX)\n\nfind_package(gz-sim8 REQUIRED COMPONENTS\n  gz-sim\n  gz-transport\n  gz-msgs\n  gz-plugin\n  gz-common\n)\n\nadd_library(diff_drive_plugin SHARED diff_drive_plugin.cc)\ntarget_link_libraries(diff_drive_plugin\n  ${gz-sim8_LIBRARIES}\n  gz-transport::gz-transport\n  gz-msgs::gz-msgs\n  gz-plugin::gz-plugin\n  gz-common::gz-common\n)\ntarget_compile_features(diff_drive_plugin PRIVATE cxx_std_17)\nset_target_properties(diff_drive_plugin PROPERTIES\n  PREFIX \"\"\n  SUFFIX \"${CMAKE_SHARED_MODULE_SUFFIX}\"\n)

Where to run: In your ROS 2 / Gazebo workspace, e.g., ~/gz_ws/src/my_plugins. Permissions: Regular user; no sudo needed if you set GZ_SIM_SYSTEM_PLUGIN_PATH.

3. Model SDF Snippet

<model name=\"my_robot\">\n  <plugin name=\"diff_drive\" filename=\"libdiff_drive_plugin.so\">\n    <left_joint>left_wheel_joint</left_joint>\n    <right_joint>right_wheel_joint</right_joint>\n    <wheel_separation>0.5</wheel_separation>\n    <wheel_radius>0.1</wheel_radius>\n  </plugin>\n  ... links and joints ...\n</model>

The filename is the compiled shared library name without the lib prefix on Linux. Nested tags become children of the SDF element passed to Configure() (Gazebo Harmonic uses ISystemConfigure instead of the classic Load()).

Building and Loading

1. Build: mkdir build && cd build && cmake .. && make -j4 (run in plugin source directory).
2. Export plugin path: export GZ_SIM_SYSTEM_PLUGIN_PATH=$PWD/build:${GZ_SIM_SYSTEM_PLUGIN_PATH} (run in the same shell before launching Gazebo).
3. Launch simulation: gz sim -v 4 my_world.sdf (run from world SDF directory). -v 4 enables verbose console output where gzlog/gzerr from your plugin will appear.

Expected check: You should see your plugin's log lines (if any) in the console. If the plugin fails to load, Gazebo prints Failed to load plugin with the path it searched.

Verifying the Plugin Works

1. Publish a command: In a second terminal (same shell with GZ_SIM_SYSTEM_PLUGIN_PATH set):
   gz topic -t /cmd_vel -m gz.msgs.Twist -p 'linear: {x: 0.5}'
2. Observe wheel velocities: gz topic -e /model/my_robot/joint/left_wheel_joint/velocity — you should see values near 5.0 rad/s (0.5 m/s / 0.1 m radius).
3. Check update rate: Add a log line in PreUpdate() printing _info.simTime.Double() and confirm the delta matches your throttle (≈0.033 s for 30 Hz) or the physics step (0.001 s if unthrottled).

Limits and Common Mistakes

ABI Version Locking

A plugin compiled against gz-sim8 (Gazebo Garden) will not load in gz-sim9 (Gazebo Harmonic) without recompilation. The CMake find_package(gz-sim8 REQUIRED) must match the runtime major version. In CI, build and test against each supported major version in separate jobs.

SDF Parsing Without Guards

Calling sdf->GetElement(\"param\")->Get<double>() on a missing element dereferences a null pointer. Always check HasElement() first or use the two-argument Get<T>(\"param\", default) overload which returns std::pair<T, bool>.

Update() Runs at Physics Rate (1 kHz Default)

If your logic only needs 30 Hz, throttle inside PreUpdate() (or classic Update()) using common::Time as shown in the example. Unthrottled heavy work (e.g., image processing, path planning) will slow the entire simulation.

Joint Authority Conflicts

If you also drive the same joint from a ROS 2 controller via ros_gz_bridge (which writes /model/.../joint/.../cmd_force or cmd_vel topics), the physics solver receives conflicting commands each step. Result: jitter, instability, or energy injection. Pick one authority per joint: either the ModelPlugin or the ROS 2 controller, not both.

Transport Topic and Type Mismatches

Gazebo Transport uses ZeroMQ + protobuf. The topic name (/cmd_vel) and message type (gz.msgs.Twist) must match exactly between publisher and subscriber. Mismatches silently drop messages — no error is logged. Verify with gz topic -l and gz topic -i /cmd_vel.

Plugin Discovery Path

Plugins installed to system paths (/usr/lib/gz/sim8/plugins) require ldconfig after install. For development, GZ_SIM_SYSTEM_PLUGIN_PATH pointing to your build directory avoids sudo and caches. If Gazebo says plugin not found, check echo $GZ_SIM_SYSTEM_PLUGIN_PATH and that the .so exists there.

When to Choose ModelPlugin vs. ROS 2 Control

Rule of thumb: if the behavior exists in gz_ros2_control (diff drive, arm controllers, gripper), use ROS 2 control. Reach for a ModelPlugin only when you need in-process physics access that the bridge cannot provide.

Practical Verification Checklist

• Build plugin against target gz-sim major version; confirm libdiff_drive_plugin.so exists in build directory.
• Set GZ_SIM_SYSTEM_PLUGIN_PATH and launch gz sim -v 4 world.sdf; verify no load errors in console.
• Publish /cmd_vel via gz topic; confirm wheel joint velocities respond via gz topic -e.
• Log _info.simTime in PreUpdate(); confirm throttle or physics-step cadence.
• Cross-compile same source with find_package(gz-sim9 REQUIRED) and test load — validates ABI handling.
• Run headless in CI: gz sim -s -r world.sdf with a script that asserts robot pose after N seconds.

These steps catch regressions in control logic, plugin loading, and version compatibility without manual GUI inspection.
