Framework7 Router: Minimal Architecture for SPA Navigation and Failure‑Safe Design

Requirements

A single‑page application (SPA) built with Framework7 must provide:

• Declarative route definitions that map URLs to page components.
• Back/forward navigation that works with the browser history API.
• Guard callbacks for authentication, data pre‑fetching, or other checks.
• Lifecycle events (pageInit, pageBeforeIn, pageAfterIn, pageBeforeOut, pageAfterOut) for resource management and analytics.
• Graceful handling of navigation errors and missing components.

Minimal Viable Architecture

The smallest production‑ready layout consists of three files:

1. app.js – Entry point that instantiates the Framework7 app and the router.
2. routes.js – Central JSON configuration that lists all routes, templates, and guards.
3. Page templates – Individual HTML or component files (e.g., home.html, about.html, profile.html).

Example routes.js:

export default [
  {
    name: 'home',
    url: '/home/',
    component: HomePage,
    // No guard – always accessible
  },
  {
    name: 'about',
    url: '/about/',
    component: AboutPage,
  },
  {
    name: 'profile',
    url: '/profile/:userId/',
    component: ProfilePage,
    guard: async (route, router) => {
      // Mock auth check – replace with real logic
      const isAuthenticated = await checkAuth();
      if (!isAuthenticated) {
        router.navigate('/home/');
        return false; // Cancel navigation
      }
      return true;
    },
  },
];

Each component receives a data object from the router, ensuring isolation of page state.

Trust & Data Boundaries

Framework7’s router injects a router context into every page component. This context includes:

• router.params – URL parameters.
• router.query – Query string values.
• Event emitters for lifecycle hooks.

Because the router does not expose a global store, pages cannot inadvertently read or modify shared data unless a dedicated store (e.g., Vuex, Redux) is used. This design keeps each page’s data encapsulated and prevents side effects across navigation.

Operational Checks

• Route Matching – The router verifies that the URL corresponds to a defined route pattern before rendering. An unmatched URL triggers the onPageError event.
• Guard Resolution – Guard callbacks must return a Promise that resolves to true or false. A false value aborts navigation and returns to the previous page.
• Component Load – The router attempts to load the component’s template and script. If the component is missing or throws during initialization, onPageError is fired.
• Memory Monitoring – Developers should check the browser’s performance panel for retained DOM nodes after pageAfterOut events. A leak indicates that cleanup code is missing.

Failure Modes

Component fails to loadHistory API unsupported

Scenario	Cause	Router Response
Guard rejects navigation	Authentication fails	Navigation cancelled, previous page remains, onPageError not fired.
Missing template or script error	Router falls back to previous page, emits onPageError with error details.
Legacy browser	Polyfill required; otherwise navigation uses hash mode.

Redesign Triggers

Consider revising the architecture when:

• Routes grow beyond 20–30 entries, making the central JSON unwieldy. Split into feature modules and lazy‑load route definitions.
• Guard callbacks become complex (e.g., multi‑step authentication). Extract guard logic into a dedicated service.
• Memory leaks are detected after repeated navigation. Ensure all event listeners are removed in pageBeforeOut or pageAfterOut.
• Deep linking is required for external traffic. Add a fallback route and ensure the router uses pushState rather than hash mode.

Concrete Example: Home → Profile (Guarded)

1. Navigate to /home/ – pageInit fires, HomePage loads.
2. Click “Profile” link – router matches /profile/123/, executes guard.
3. Guard resolves true (mock auth passes) – router loads ProfilePage, triggers pageBeforeIn and pageAfterIn.
4. Navigate back – pageBeforeOut and pageAfterOut fire, HomePage remains in memory but is detached from the DOM. Verify no retained nodes.

When the mock auth flag is set to false, the guard redirects to /home/ and the ProfilePage never renders. This demonstrates the guard’s ability to block navigation.

Practical Verification Checklist

• Run npm run dev and open http://localhost:8080.
• Open the browser console. Verify that pageInit logs appear for each navigation.
• Toggle the mock auth flag and attempt to access the Profile route. Confirm redirection to Home.
• Use the Performance tab to record a navigation cycle. Look for “Detached DOM trees” after pageAfterOut.
• Delete profile.html temporarily and navigate to /profile/123/. Observe the onPageError event and fallback to Home.

Summary

The Framework7 router offers a lightweight, declarative navigation model that fits well into a minimal SPA architecture. By centralizing route definitions, leveraging guard callbacks, and listening to lifecycle events, developers can maintain data isolation, detect failures early, and keep memory usage under control. When the application scales or requires deeper integration (e.g., complex auth flows, large numbers of routes), modularizing routes and extracting guard logic will keep the codebase maintainable.
