Expose Multiple Local Services with Reserved ngrok Subdomains from One Config File

Why ad-hoc ngrok sessions break down with multiple services

Running a separate ngrok http command for each local service produces random URLs, forces you to manage multiple terminal windows, and makes it easy to lose track of which port maps to which public endpoint. A single configuration file removes that friction: you describe each tunnel once, assign a stable identifier, and start every session together.

Desired outcome

By the end of this guide you will have an ngrok.yml file that defines two or more HTTP tunnels, each pointing to a different local port and exposing either a reserved ngrok.io subdomain or a custom domain you own. You will start them with one command and confirm that each public URL reaches the correct local service.

Prerequisites and plan limits

• ngrok CLI installed on the machine that runs your local services.
• An authtoken from the ngrok dashboard. This links the agent to your account.
• A paid plan if you want to reserve a specific subdomain under ngrok.io. Free accounts receive randomly generated subdomains and cannot request a custom one.
• Local services already listening on the ports you plan to expose (for example, a development API on port 3000 and a web front end on port 8080).
• DNS management access if you intend to use a custom domain rather than an ngrok.io subdomain.

Store the authentication token

ngrok needs an authtoken to reserve subdomains and to associate traffic with your account. You can provide it in two ways:

• Set the NGROK_AUTHTOKEN environment variable before starting the agent.
• Place an authtoken key directly in your ngrok.yml file.

Both methods work, but the config file stores the token in plain text on disk. If the host is shared or compromised, anyone with file access can use your account. For production or CI environments, prefer a secrets manager or environment injection, and restrict file permissions on the config itself.

Define multiple tunnels in ngrok.yml

The tunnels section is a map of named entries. Each entry needs at minimum a proto (the protocol, usually http) and an addr (the local address and port). Add a subdomain key to request a stable ngrok.io hostname.

Create or edit your config file (commonly ngrok.yml in your home directory, or pass an explicit path with --config):

authtoken: <your-ngrok-authtoken>
tunnels:
  billing-api:
    proto: http
    addr: 3000
    subdomain: acme-billing
  storefront:
    proto: http
    addr: 8080
    subdomain: acme-store

In this example, billing-api and storefront are arbitrary labels you choose. The subdomain values must be unique across all ngrok users; if acme-billing is already taken, the agent will fail to start that tunnel.

Using a custom domain instead

If you own a domain, replace subdomain with custom_domain:

tunnels:
  marketing-site:
    proto: http
    addr: 4000
    custom_domain: app.example.com

Before starting the tunnel, create a CNAME DNS record for app.example.com that points to the ngrok hostname provided for your account (for example, the ngrok.io address shown in your dashboard). SSL certificates for custom domains are typically managed through the ngrok dashboard; you may need to wait for certificate issuance after the DNS record propagates.

Start all tunnels at once

Run the following command in a terminal on the host where your local services run. No elevated privileges are required:

ngrok start --all

The agent reads the config file, opens a session for every tunnel listed, and prints the public URL for each one. You should see output similar to:

billing-api    https://acme-billing.ngrok.io -> http://localhost:3000
storefront     https://acme-store.ngrok.io  -> http://localhost:8080

Note: exact formatting varies by ngrok version. The key check is that each named tunnel appears with the subdomain or custom domain you requested.

Verify that traffic reaches the right service

Use curl from any machine with internet access, substituting the subdomain or custom domain from your config:

curl -I http://acme-billing.ngrok.io

A successful response returns HTTP headers from your local service, not from ngrok. If you receive a connection error, confirm the local service is listening and that the addr port matches.

For deeper inspection, open the ngrok web interface in a browser on the same machine:

http://127.0.0.1:4040/tunnels

This page lists every active tunnel, its public URL, and its target address. It also captures request and response details, which is useful when a tunnel starts but the application returns unexpected errors.

Recovery options when a tunnel fails

Symptom	Likely cause	What to do
Agent exits with a subdomain error	Free plan, or subdomain already reserved by another account	Upgrade to a paid plan or choose a different subdomain value
Custom domain returns certificate warnings	CNAME not fully propagated, or SSL not yet issued	Verify DNS resolution, then re-check the ngrok dashboard for certificate status
connection refused in the inspector	Local service is down or addr points to the wrong port	Restart the local service and confirm the port with a local request first
Token rejected at startup	Invalid or revoked authtoken	Copy a fresh token from the dashboard and update the config or environment variable

Limitations and current verification

Reserved subdomains are a paid feature; attempting to use the subdomain key on a free account will prevent that tunnel from starting. DNS changes for custom domains can take several minutes to propagate, so a newly created CNAME may not resolve immediately. Because ngrok's plan features and configuration schema can change, verify the current requirements for subdomain reservation, custom domain SSL, and config file syntax against the official ngrok documentation before relying on this setup in production.

A quick way to confirm the final state

After starting the tunnels, check three things: the console shows one URL per named tunnel, curl against each public URL returns content from the expected local service, and the inspector at 127.0.0.1:4040 lists both tunnels as active. If all three pass, your multi-tunnel configuration is working.
