Export Publication-Quality Static Images from Plotly with Kaleido

Desired Outcome

Produce high-resolution PNG, SVG, PDF, or JPEG files from Plotly figures without a browser, suitable for reports, publications, or automated pipelines. The Kaleido engine provides a self-contained binary that eliminates external dependencies such as Chrome or the legacy Orca service.

Prerequisites

• Python 3.7 or newer
• Plotly 5.0 or newer
• Kaleido package installed: pip install -U plotly kaleido

Kaleido bundles its own rendering binary, so no system-level browser installation is required. On minimal Linux containers (e.g., Alpine or slim Debian), you may still need a few shared libraries for the binary to execute; see the recovery section for a typical apt-get list.

Procedure

Single-Figure Export

Import plotly.io, create a figure with Plotly Express or Graph Objects, then call write_image with the Kaleido engine:

import plotly.io as pio
import plotly.express as px

fig = px.scatter(x=[1, 2, 3], y=[1, 3, 2], title="Simple Scatter")
fig.write_image(
    "output.png",
    engine="kaleido",
    scale=2,           # 2× the default 72 DPI → 144 DPI
    width=1200,
    height=800
)

The same call works for "output.svg", "output.pdf", or "output.jpg"; the format is inferred from the file extension.

Batch Configuration

To avoid repeating arguments across a pipeline, set module-level defaults once:

pio.kaleido.scope.default_format = "png"
pio.kaleido.scope.default_scale = 2
pio.kaleido.scope.default_width = 1200
pio.kaleido.scope.default_height = 800

# Later in the script
fig.write_image("batch_output.png")  # uses the defaults above

Using pio.write_image Directly

If you prefer a functional style, pio.write_image(fig, "out.png", engine="kaleido", scale=2) is equivalent.

Expected Checks

1. File existence and size: confirm the output file exists and has non-zero bytes (os.path.getsize("output.png") > 0).
2. Visual verification: open the image and inspect fonts, colors, axis labels, and legend placement.
3. Dimension validation: use an image utility (e.g., identify output.png from ImageMagick or file output.png) to verify the pixel dimensions match width × height × scale.
4. Stress test: export a complex figure (many traces, annotations, subplots) to ensure no clipping or missing layers.

Recovery Options

Symptom	Likely Cause	Remediation
FileNotFoundError: Kaleido executable not found	Corrupted or incomplete kaleido wheel	pip install --force-reinstall kaleido
Missing glyphs or fallback fonts	Requested font family not installed on the system	Install system fonts (e.g., apt-get install -y fonts-dejavu-core) or set a safe default: fig.update_layout(font_family="DejaVu Sans")
MemoryError or OOM on large figures	High scale with many pixels	Reduce scale (e.g., 1.5) or export to vector SVG: fig.write_image("out.svg", engine="kaleido")
WebGL traces (scattergl, heatmapgl) render incorrectly	Kaleido does not fully support WebGL-based trace types	Switch to SVG-backed traces (scatter, heatmap) for static export, or keep interactive HTML for those figures
Permission denied on the Kaleido binary in CI	Binary lacks execute bit in the container layer	Ensure the container user can execute the binary; in Docker, RUN chmod +x /path/to/kaleido or install required libraries (see below).

Headless CI Library Dependencies

On Debian/Ubuntu-based CI images, the Kaleido binary may require the following libraries (similar to Chrome headless):

apt-get update && apt-get install -y \
  libglib2.0-0 libnss3 libnspr4 libatk1.0-0 libatk-bridge2.0-0 \
  libcups2 libdrm2 libxkbcommon0 libxcomposite1 libxdamage1 \
  libxfixes3 libxrandr2 libgbm1 libasound2

Alpine users should prefer the kaleido wheel built for musl or install the equivalent apk packages.

Limitations

• WebGL traces: scattergl, heatmapgl, and other GL-based traces may render incorrectly or fall back to a blank layer. Test each trace type before committing to a pipeline.
• MathJax/LaTeX: Kaleido's built-in MathJax support is limited. For complex LaTeX labels, consider exporting to SVG and post-processing with an external LaTeX renderer, or use Plotly's built-in mathtext subset (basic Greek, superscripts, subscripts).
• Version coupling: Plotly 5.x pairs with Kaleido 0.1.x+. Verify compatibility with:

  import plotly; print(plotly.__version__)
  import kaleido; print(kaleido.__version__)

Verification Checklist

1. Run a minimal script that creates a simple scatter plot and exports to PNG. Confirm the output is a valid PNG:
   file output.png should report PNG image data, 1200 x 800, 8-bit/color RGBA.
2. Check Plotly and Kaleido versions as shown above to ensure compatibility.
3. In CI, add a test step that exports a representative figure and compares its checksum (e.g., SHA-256) against a known-good baseline to detect rendering regressions.

Quick Reference

Task	Code Snippet
Install	pip install -U plotly kaleido
Export PNG at 2× scale	fig.write_image("out.png", engine="kaleido", scale=2, width=1200, height=800)
Set global defaults	pio.kaleido.scope.default_scale = 2
Export SVG (vector)	fig.write_image("out.svg", engine="kaleido")
Force font family	fig.update_layout(font_family="DejaVu Sans")
