Enforcing Host Firewall Policy Across a RHEL Fleet with the Firewall System Role

The Problem: Drift and Inconsistency at Scale

Managing host-level packet filtering on dozens or hundreds of Red Hat Enterprise Linux (RHEL) systems by hand leads to configuration drift, audit gaps, and the risk of administrator lockout when a manual firewall-cmd change accidentally removes SSH access. The Red Hat firewall system role (redhat.rhel_system_roles.firewall) provides an Ansible-native, supported interface to firewalld (the default RHEL firewall manager), allowing you to define policy once and apply it consistently across RHEL 8 and 9 fleets.

Requirements

• Consistent, auditable host firewall policy on RHEL 8/9 without per-host manual edits.
• Ansible control node with SSH access to managed hosts using key-based authentication.
• firewalld installed and running on every target host.
• rhel-system-roles package (or the equivalent Ansible collection) available on the control node.
• Inventory grouping that reflects security zones (e.g., webservers, databases, bastions).

Smallest Suitable Design

The minimal design consists of a single playbook, one inventory group, and the firewall role. This avoids unnecessary middleware and relies on the native system role provided by Red Hat.

# playbooks/firewall-baseline.yml
---
- name: Apply baseline host firewall policy
  hosts: all
  become: true
  vars:
    firewall:
      - service: ssh
        state: enabled
        permanent: true
        zone: public
      - port: 8080/tcp
        state: enabled
        permanent: true
        zone: public
      - service: cockpit
        state: disabled
        permanent: true
        zone: public
  roles:
    - redhat.rhel_system_roles.firewall

Run the following command from the control node to preview changes:

ansible-playbook -i inventory/prod.yml playbooks/firewall-baseline.yml --check --diff

The --check --diff flags allow you to see exactly which rules will be added or removed before they are applied to the production environment.

Trust and Data Boundaries

Boundary	Description	Risk if Compromised
Ansible control node	Holds inventory, playbooks, and SSH private keys	Full fleet firewall control; ability to open/close any port
Managed node SSH trust	Each host accepts the controller's public key	Potential for lateral movement if the control node is breached
Firewall policy data	Port/service lists defined in playbooks or vars files	Not secret, but misconfiguration can expose sensitive services
firewalld runtime	Local daemon enforcing rules on the host	Manual firewall-cmd edits create drift from the source of truth

To mitigate these risks, restrict control node access via a bastion host with MFA, rotate SSH keys regularly, and treat playbook repositories as privileged infrastructure code requiring peer review and CI linting.

Operational Checks

1. Pre-apply validation: Use ansible-playbook --check --diff to verify the intended state against the current state.
2. Post-apply verification: On a managed host, run the following commands to confirm the policy is active:

   firewall-cmd --list-all
   firewall-cmd --get-active-zones

   Expect to see ssh and 8080/tcp enabled under the public zone, with cockpit absent.
3. Log monitoring: Monitor journalctl -u firewalld for REJECT entries or failed reload events.
4. Drift detection: Schedule a daily --check run against a canary host; any reported changes indicate manual intervention or unauthorized drift.

Failure Modes

Failure	Symptom	Root Cause	Mitigation
SSH lockout	Controller cannot reconnect to host	ssh service omitted or disabled in vars	Always explicitly declare service: ssh, state: enabled
Role version mismatch	Task fails with "unsupported parameter"	Collection version differs from RHEL release	Pin collection version in requirements.yml
Missing firewalld	"firewalld service not found" error	Minimal install omitted the package	Add pre-task to ensure firewalld is installed and started
Manual drift	Rules differ from playbook	Admin ran firewall-cmd --permanent locally	Enforce a "no manual changes" policy

Conditions That Change the Design

• Per-host exceptions: If hosts require unique rules, move from static variables to data-driven inventory (host_vars/group_vars) or use Jinja2 templates to merge baseline and exception lists.
• Container workloads: For OpenShift or Kubernetes, shift enforcement to NetworkPolicies; the host firewall should then only manage node-level services like kubelet and SSH.
• RHEL Image Mode: In immutable deployments (Bootc), runtime firewalld management is replaced by baking the policy into the container image at build time.
• Multi-zone requirements: If hosts require distinct zones per interface (e.g., DMZ vs. Internal), extend the role variables with firewall_zones and firewall_interface mappings.

Verification Checklist

• Run ansible-playbook --check --diff; confirm only expected changes appear.
• Execute firewall-cmd --list-all on a target host to verify declared services.
• Verify changed=0 on subsequent runs to ensure idempotence.
• Check rpm -q rhel-system-roles on the control node to ensure the version matches the target RHEL minor release.
• Confirm service status: systemctl is-active firewalld should return active.

Limitations

• The role manages firewalld specifically; it does not configure nftables or iptables directly.
• There is no built-in automated rollback; version control (Git) for playbooks is the primary recovery mechanism.
• Requires a RHEL subscription for supported collection access.
• IPv6 rules follow standard service/port declarations; explicit IPv6-only rules require firewall-cmd --direct, which the role does not abstract.
