F# Units of Measure: Compile-Time Dimensional Safety Guide

F# Units of Measure attach compile-time dimension metadata to numeric types, preventing unit mismatches before runtime.

The Problem: Silent Unit Mismatches

Numeric calculations in most languages treat all numbers as interchangeable. A function expecting meters receives seconds, a currency conversion uses raw decimals without tracking dollars versus euros, and the compiler stays silent. Bugs surface only at runtime—or in production.

F# Units of Measure attach compile-time dimension metadata to numeric types. The compiler rejects mismatched units before code runs, while erasing the metadata at runtime for zero overhead.

Prerequisites

F# 5.0 or later (included with .NET SDK 5.0+)
dotnet CLI available on PATH
Basic F# syntax familiarity
A project or script file (.fs or .fsx)

Define Measures and Annotate Values

Create a new script file units-demo.fsx and add measure definitions using the [<Measure>] attribute:

[<Measure>] type m\n[<Measure>] type s\n[<Measure>] type kg\n\nlet distance = 100.0<m>\nlet time = 9.58<s>\nlet mass = 70.0<kg>

Each measure creates a distinct type: float<m>, float<s>, and float<kg> are incompatible with each other and with raw float.

Write Dimension-Aware Functions

Functions declare expected units in their signatures. The compiler enforces them at call sites:

let speed (d: float<m>) (t: float<s>) : float<m/s> = d / t\n\nlet momentum (m: float<kg>) (v: float<m/s>) : float<kg*m/s> = m * v\n\n// Valid usage\nlet v = speed distance time        // float<m/s>\nlet p = momentum mass v            // float<kg*m/s>

Compound units like m/s and kg*m/s are inferred automatically from arithmetic operators.

Observe Compile-Time Rejection of Mismatches

Attempting to add incompatible units produces a compile error. Add this line to the script:

// This line will not compile\nlet invalid = distance + time

Run the script with F# Interactive to see the error:

dotnet fsi units-demo.fsx

Where to run: Terminal in the script directory. Permissions: Standard user. Expected check: Compiler emits error FS0001: \"The unit of measure 'm' does not match the unit of measure 's'.\" Risk: None—this is a compile-time check only.

Handle Conversions Explicitly

No implicit casting exists. Define conversion factors as measured constants:

let metersPerKilometer = 1000.0<m/km>\nlet kilometersPerMile = 1.60934<km/mi>\n\nlet toMeters (km: float<km>) : float<m> = km * metersPerKilometer\nlet toKilometers (mi: float<mi>) : float<km> = mi * kilometersPerMile

Raw literals require annotation when used with measured values:

// Correct: annotate the constant\nlet halfDistance = distance * 0.5<m>\n\n// Error: raw float cannot multiply float<m>\n// let wrong = distance * 0.5

Verify Runtime Behavior

Units are erased in compiled IL. The runtime values are plain numbers. Confirm this by printing results:

printfn \"Speed: %f m/s\" (float v)\nprintfn \"Momentum: %f kg*m/s\" (float p)\nprintfn \"Distance in meters: %f\" (float (toMeters 5.0<km>))

Run again with dotnet fsi units-demo.fsx. Output shows raw numeric values with no unit metadata attached.

Work with Generic Code

Units integrate with generics via inline functions and static member constraints. Example: a generic magnitude function:

let inline magnitude (x: ^a) (y: ^a) : ^a =\n    sqrt (x * x + y * y)\n\n// Works with any measured type supporting * and +\nlet hypotenuse = magnitude 3.0<m> 4.0<m>  // float<m> = 5.0<m>

The inline keyword enables compile-time resolution of the arithmetic operators for the specific measure.

Limitations and Cross-Language Boundaries

Runtime erasure: Reflection returns base types (System.Double). Debuggers and serializers see raw numbers.
C#/VB consumers: Exposed APIs show only double, float, decimal. Document expected units in XML comments.
No runtime validation: Parsing external data (JSON, databases) requires manual unit assignment after parsing raw numbers.

Recovery from Unit Mismatch Errors

Read the compiler error—it names the expected and actual measures.
Locate the call site. Check whether a constant needs annotation (e.g., 0.5<m>) or a conversion function is missing.
Add the appropriate conversion or annotation. Recompile.
If the mismatch stems from external data, parse to raw numeric first, then apply the measure: let parsed = Double.Parse(input) * 1.0<m>.

Practical Verification Checklist

dotnet build succeeds with zero unit-related errors
Runtime output matches expected numeric results
No float literals appear unannotated in measured expressions
Public APIs include XML comments specifying expected units for non-F# consumers
