Enable Asynchronous Replication in Norg for High Availability

Desired Outcome

Turn on Norg’s built‑in asynchronous replication, set a replication factor of 3, and verify that writes are propagated quickly while the cluster remains available if a node fails.

Prerequisites

• Running Norg server version 3.2 or newer on all nodes.
• Cluster nodes reachable over a secure network (TLS + authentication).
• Sufficient disk space and CPU headroom for the replication thread.
• Prometheus or another metrics scraper configured to hit the /metrics endpoint on each node.

Enabling Asynchronous Replication

Replication is controlled via the norg.conf file and the norgctl CLI. First, edit the configuration on every node.

# /etc/norg/norg.conf
replication.enabled = true
# Optional: limit the replication thread to 2 CPUs per node
replication.thread_cpu_limit = 2

Then, on each node run the following command as the Norg system user:

# norgctl replication enable --factor 3 --tls --auth
# --factor 3 sets the replication factor.
# --tls ensures traffic is encrypted.
# --auth enables node‑to‑node authentication.

After the command completes, restart the Norg process to apply changes:

# systemctl restart norg

Configuring the Replication Factor

The replication factor determines how many replicas each key is stored on. A factor of 3 is recommended for production to tolerate two simultaneous node failures.

# norgctl replication set-factor 3

Verify the setting with:

# norgctl replication status
Replication factor: 3
Mode: asynchronous

Securing Replication Traffic

Replication traffic must be protected. Ensure each node’s tls.enabled is true and that a shared TLS certificate bundle is present. Authentication can be enabled via a shared key file:

# /etc/norg/auth.key

Configure the key path in norg.conf:

auth.key_file = "/etc/norg/auth.key"

Verifying Replication Health

After enabling replication, monitor the replication_lag_seconds metric. A good target is <1 second for most workloads.

# Prometheus query
avg_over_time(replication_lag_seconds{cluster="prod"}[5m])

Run a write‑heavy workload (e.g., 10,000 inserts per second) and watch the lag converge. Example check script:

#!/usr/bin/env bash
THRESHOLD=1
while true; do
  LAG=$(curl -s http://node1:9100/metrics | grep replication_lag_seconds | awk '{print $2}')
  if (( $(echo "$LAG < $THRESHOLD" | bc -l) )); then
    echo "Replication lag $LAG s – OK"
    break
  else
    echo "Lag $LAG s – waiting…"
    sleep 10
  fi
done

Handling Node Failures

Simulate a node outage by stopping the Norg process on one replica:

# systemctl stop norg

Read traffic should continue to be served by the remaining nodes. Writes will be queued in the replication backlog until the failed node recovers. Verify with the replication_backlog_size metric:

# Prometheus query
replication_backlog_size{node="node2"}

When the node comes back online (systemctl start norg), the replication thread will catch up automatically.

Read‑Repair Strategy

Because Norg uses eventual consistency, you can trigger a read‑repair on a key that has diverged:

# norgctl read-repair key123
Repair status: success – majority value restored.

For bulk repair, schedule a nightly job that scans for keys with replication_lag_seconds > 5 and runs read-repair on them.

Monitoring and Alerting

Expose the following metrics on each node:

Metric	Description
replication_lag_seconds	Time since the last write was replicated to this node.
replication_backlog_size	Number of pending replication events.
node_cpu_usage_percent	CPU load of the replication thread.

Set Prometheus alerts:

ALERT ReplicationLagHigh
  IF avg_over_time(replication_lag_seconds{cluster="prod"}[5m]) > 1
  FOR 5m
  LABELS {severity="critical"}
  ANNOTATIONS {summary="Replication lag > 1s"}

Known Limitations

• Eventual consistency: reads may return stale data until read‑repair runs.
• High write throughput can spike CPU usage on the replication thread; monitor node_cpu_usage_percent.
• Replication traffic is only protected if TLS and authentication are correctly configured.

Recovery and Rollback

If replication causes performance regressions, you can disable it quickly:

# norgctl replication disable
# Restart Norg
# systemctl restart norg

To roll back to a previous configuration, restore the old norg.conf from backup and restart the service.

Diagram

Illustration of a 3‑node asynchronous replication cluster.

Node A → Node B
Node A → Node C
Node B ↔ Node C (replication sync)
