Diagnosing Streamlit Caching Problems: Stale Data, Hash Errors, Mutations, and Memory Leaks

Quick Reference: Common Cache Symptoms

Symptom	Typical Cause	First Check
Function returns stale data after source change	File watcher disabled or mutable arguments not re‑hashed	Verify runOnSave and clear cache
UnhashableTypeError or pickle error on decorator	Arguments/return contain DB connections, locks, open handles	Identify offending argument by removing args one‑by‑one
Cached object mutates across sessions	Caller modifies returned list/dict/DataFrame in‑place	Search for .append(), .update(), df[col]=… on cached return
Process memory grows until OOM	Unlimited max_entries; many large DataFrames accumulate	Monitor RSS with ps or top; log cache size
Cache miss despite identical arguments	Volatile attributes (timestamps, random seeds, object ids) in hash	Log argument hashes via wrapper; compare custom hash_funcs

Condition 1 – Stale Results After Code or Data Changes

Cause

@st.cache_data hashes the function source and all arguments. If the file watcher (runOnSave) is off, Streamlit does not re‑hash when the source file changes. Mutable arguments (e.g., a list passed by reference) also keep the same hash because the object identity does not change.

Ordered Checks

1. Open .streamlit/config.toml and confirm runOnSave = true (default).
2. Run streamlit cache clear (or st.cache_data.clear() in code) and re‑run the app.
3. If the function receives mutable containers, add a deterministic hash_funcs mapping, e.g. hash_funcs={list: lambda x: tuple(x)}.

Fixes

• Restart the Streamlit server after enabling runOnSave.
• Decorate with @st.cache_data(ttl="1h", hash_funcs={list: lambda x: tuple(x)}) to force periodic refresh and stable hashing.

Escalation

If stale data persists, inspect the pickle files in ~/.streamlit/cache. Corrupted pickles can be removed manually; the next run will rebuild them.

Condition 2 – UnhashableTypeError / Pickle Errors

Cause

Arguments or return values contain objects that Python cannot hash or pickle: database connections, threading locks, open file handles, or third‑party SDK clients.

Ordered Checks

1. Comment out all arguments; add them back one at a time until the error reappears.
2. Check the return type – a connection object returned from a cached function will also trigger the error.

Fixes

• Move resource creation outside the cached function and decorate the singleton with @st.cache_resource.
• For arguments that must stay, provide a custom hash_funcs that extracts a stable identifier (e.g., connection string).

@st.cache_resource
def get_db_engine():
    return create_engine(os.getenv("DB_URL"))

@st.cache_data(hash_funcs={Engine: lambda e: e.url.render_as_string(hide_password=False)})
def run_query(sql: str, engine):
    return pd.read_sql(sql, engine)

Escalation

If a third‑party object cannot be hashed, cache only primitive inputs (query string, parameters) and reconstruct the heavy object downstream.

Condition 3 – Unexpected Mutation Across Sessions

Cause

@st.cache_data returns the *same* object reference on every hit. In‑place modifications (list.append, dict.update, df['col'] = …) affect the cached instance for all users.

Ordered Checks

1. Search the codebase for methods that mutate the returned value: .append(), .extend(), .update(), DataFrame column assignment.
2. Confirm whether the mutation is intentional (e.g., building a UI state) or accidental.

Fixes

• Return an immutable copy: return df.copy(), return list(cached_list), or rely on the default copy=True for DataFrames (Streamlit ≥1.18).
• If a third‑party library mutates the object, wrap the call: return copy.deepcopy(third_party_call()).

Escalation

When mutation originates from code you cannot change, consider switching to @st.cache_resource for that object and manage cloning manually.

Condition 4 – Unbounded Memory Growth

Cause

Default max_entries=None means the cache never evicts. Each distinct argument combination stores a full copy of the return value (often large DataFrames). Over time the process RSS climbs until the container OOM killer terminates it.

Ordered Checks

1. Run watch -n 5 'ps -o pid,rss,cmd -p $(pgrep -f streamlit)' to observe RSS growth.
2. Add a temporary log line: logger.info(f"Cache entries: {len(my_func.cache)}") (accessible via my_func.__wrapped__.cache in 1.28+).

Fixes

• Set a hard limit: @st.cache_data(max_entries=100, ttl="2h").
• For @st.cache_resource singletons, implement a manual clear on logout or a background timer: st.cache_resource.clear().

Escalation

If memory still grows after limits, profile non‑cached objects (e.g., session state, large uploaded files). Consider moving heavy caches to an external store like Redis.

Condition 5 – Cache Misses Despite Identical Arguments

Cause

Hash includes volatile fields: timestamps, random seeds, object id(), or mutable containers that change identity between calls.

Ordered Checks

1. Wrap the cached function to log the computed hash: def logged(*a, **kw): h = my_func._hash_func(a, kw); logger.debug(h); return my_func(*a, **kw).
2. Compare hashes across two runs with the same logical input.

Fixes

• Normalize arguments before calling: strip timestamps, convert objects to tuples of primitives.
• Provide deterministic hash_funcs for custom classes, e.g., hash_funcs={MyConfig: lambda c: (c.param1, c.param2)}.

Escalation

If instability originates in an upstream library (e.g., a request object that regenerates a nonce), cache at a higher level – store the raw HTTP response bytes instead of the parsed object.

Practical Verification Steps

1. Enable debug logging: streamlit run app.py --logger.level=debug (requires Streamlit ≥1.28). Cache hits/misses appear as Cache hit for … or Cache miss for ….
2. Inspect cache directory: ls -l ~/.streamlit/cache. Each pickle file corresponds to a cached entry; verify eviction after setting max_entries.
3. Load test: Use locust -f locustfile.py --headless -u 50 -r 10 --run-time 5m to simulate concurrent users and watch RSS stability.
4. Confirm version: streamlit version. Caching API stable since 1.18; debug logs since 1.28.

Limitations & Gotchas

• st.cache_data.clear() clears the cache for *all* users sharing the same server process.
• TTL and max_entries are per‑function, not global.
• Custom hash_funcs must be pure and deterministic across processes; avoid id(), random, or time‑based values.
• External caches (Redis, Memcached) are not built‑in; they require manual serialization.

Checklist for a Clean Cache Setup

• ✅ runOnSave = true in .streamlit/config.toml.
• ✅ Use @st.cache_resource for connections, models, and other singletons.
• ✅ Annotate every @st.cache_data with max_entries and ttl appropriate to data volatility.
• ✅ Return copies (.copy(), list()) or rely on default copy=True for DataFrames.
• ✅ Provide hash_funcs for any non‑primitive argument types.
• ✅ Monitor RSS in staging; set alerts if growth exceeds 80 % of container limit.
