Diagnosing Prometheus Remote Write Failures: Step‑by‑Step Guide

Recognizable condition

Prometheus server logs repeatedly contain messages like failed to send batch to remote storage and the metrics remote_write_samples_total or remote_write_success_samples_total show zero or near‑zero successful samples. The remote_write_status gauge (if exposed) stays at 0, indicating a persistent transmission problem.

Cause / diagnostic table

Potential cause	Typical evidence in logs/metrics	Quick diagnostic clue
Network connectivity (firewall, DNS, routing)	Connection timeouts, i/o timeout errors	Cannot reach the endpoint from the Prometheus host
TLS certificate problems (expired, untrusted CA)	Handshake failure, x509: certificate signed by unknown authority	TLS handshake fails even though host is reachable
Authentication/token issues (missing, wrong, expired bearer token)	HTTP 401/403 responses, unauthorized in logs	Endpoint reachable but server rejects the request
Misconfigured URL or path in remote_write stanza	404 Not Found, no route to host for wrong host	Endpoint returns 404 or similar despite correct network/TLS
Remote storage ingestion limits or schema mismatch	429 Too Many Requests, 400 Bad Request, storage‑side error logs	Requests arrive but are rejected by the remote system

Ordered checks

1. Verify endpoint reachability

   Run from the Prometheus host (requires shell access, typically root or the prometheus user):

   # Replace with your remote_write URL
   REMOTE_URL="https://remote-storage.example.com/api/v1/write"
   curl -v -o /dev/null -s -w "%{http_code}\n" "$REMOTE_URL"

   If curl times out or returns a non‑HTTP error (e.g., Could not resolve host), note the output. You can also use nc -zv for TCP connectivity.

2. Check TLS certificates and authentication headers

   If the URL is HTTPS, inspect the certificate chain:

   openssl s_client -connect remote-storage.example.com:443 -servername remote-storage.example.com

   Look for Verify return code: 0 (ok). Any other value indicates a problem. For bearer token validation, manually add the token to a curl request:

   curl -v -H "Authorization: Bearer $TOKEN" "$REMOTE_URL" -X POST --data-binary @- <<< ''

   A 401/403 response points to token issues.

3. Inspect the Prometheus configuration file

   Locate prometheus.yml (usually /etc/prometheus/prometheus.yml) and examine the remote_write block:

   remote_write:
     - url: "https://remote-storage.example.com/api/v1/write"
       bearer_token_file: /etc/prometheus/token
       tls_config:
         ca_file: /etc/prometheus/ca.crt
         cert_file: /etc/prometheus/client.crt
         key_file: /etc/prometheus/client.key


   Ensure the URL matches the endpoint, the token file exists and is readable, and TLS file paths are correct.

4. Review remote storage side logs

   Ask the storage team to check logs for incoming requests from the Prometheus host’s IP. Look for:

   • Authentication failures
   • TLS handshake errors
   • 4xx/5xx responses (e.g., 429, 400)
   • Schema validation errors

   If the storage system exposes its own metrics, verify that request counters increase when Prometheus attempts to send data.

Fixes tied to findings

• Connectivity failure: adjust firewall rules, correct DNS entries, or fix routing. After changes, re‑run the curl test.
• TLS/certificate failure: renew or replace the expired certificate, update the CA bundle, or correct tls_config paths. Reload Prometheus (kill -HUP $(pidof prometheus)) after editing prometheus.yml.
• Authentication failure: generate a new bearer token, store it in the configured file, and ensure file permissions allow the prometheus user to read it (chmod 600). Update any other Prometheus instances that share the same token.
• Misconfigured URL/path: edit the url field in remote_write to the correct endpoint, then reload Prometheus.
• Remote storage rejection: work with the storage team to increase ingestion limits, adjust schema validation, or clear temporary backpressure. If the storage returns 429, consider enabling queue_config with appropriate max_samples_per_send and max_shards to smooth bursts.

Escalation criteria

If after applying the relevant fix the error persists for more than 5 minutes or the remote_write_failed_samples_total metric shows >10% of total samples, proceed as follows:

1. Engage the remote storage team or vendor support.
2. Enable debug logging in Prometheus by setting --log.level=debug and restarting.
3. Collect a recent snippet of the Prometheus log (journalctl -u prometheus or /var/log/prometheus/*.log) and share it with the support team.
4. Consider temporarily disabling remote_write (remote_write: []) to protect local disk space while the issue is investigated, ensuring local storage retention is sufficient.

Verification

After a fix, confirm success by:

• Checking Prometheus logs for lines like Successfully sent batch to remote storage.
• Observing the metric remote_write_samples_total increase (e.g., promtool query remote_write_samples_total or via the UI).
• Querying the gauge remote_write_status; a value of 1 indicates the last batch succeeded.
• Optionally, push a test metric via the Pushgateway or a short‑lived scrape job and verify it appears in the remote storage after a few seconds.

Limitations and practical checks

Increasing the remote_write queue size indefinitely can lead to out‑of‑memory (OOM) conditions; always monitor process_resident_memory_bytes and keep queue_config within sensible bounds. Changing authentication tokens without updating all Prometheus instances may cause partial data loss; roll out token changes in a coordinated fashion or use a shared secret management system.
