Diagnosing Overlapping Labels in Matplotlib with Constrained Layout

Recognizable Condition

When saving a figure that contains multiple subplots, long tick labels, axis labels, a suptitle, or external artists such as colorbars or legends, you may observe:

• Tick labels overlapping neighboring axes or being clipped at the figure edge.
• Axis titles or suptitle touching or overlapping tick labels.
• Colorbars or legends drawn outside the axes being cut off.

The issue often appears only after plt.savefig (or when exporting to PDF/SVG) and may not be visible on‑screen depending on the backend DPI or figure size.

Cause & Diagnostic Table

Symptom	Likely Cause	Quick Check
Overlap/clipping only after save, not on screen	Default fixed layout ignores text extents; backend DPI/size differs	Call fig.get_layout_engine(); compare fig.get_size_inches()*fig.dpi with screen DPI
Persistent overlap even after tight_layout()	tight_layout() or subplots_adjust() masking the real issue	Search code for those calls; temporarily comment them out
Colorbar or legend clipped	Artist placed outside Axes without layout engine reserving space	Verify if fig.colorbar was called without ax= argument

Ordered Checks

1. Confirm layout‑engine support
   Ensure Matplotlib ≥ 3.6 (where set_layout_engine exists). Run:

   import matplotlib
   print(matplotlib.__version__)


   Required permission: none; just import the library.
2. Identify active engine
   After creating the figure, inspect:

   fig = plt.figure()
   print(fig.get_layout_engine())


   Expected output for constrained layout: <matplotlib.layout_engine.ConstrainedLayoutEngine object at 0x...>. If the engine is None or a FixedLayoutEngine, constrained layout is not active.
3. Check for conflicting layout calls
   Look for plt.tight_layout(), fig.tight_layout(), or manual subplots_adjust in the script. Temporarily disable them to see if the overlap changes.
4. Inspect external artists
   Verify that any fig.colorbar, fig.legend, or ax.annotate calls pass the parent axes (ax=) when you want the layout engine to shrink the parent axes accordingly.
5. Test with a minimal reproducer
   Create a two‑subplot figure with long y‑tick labels and a colorbar:

   import matplotlib.pyplot as plt
   import numpy as np

   x = np.linspace(0, 2*np.pi, 400)
   y = np.sin(x)

   fig, axs = plt.subplots(2, 1, layout='constrained')  # try without layout later
   for ax in axs:
       ax.plot(x, y)
       ax.set_yticks([-1, -0.5, 0, 0.5, 1])
       ax.set_yticklabels(['minimum', '-0.5', 'zero', '0.5', 'maximum'])
       ax.set_ylabel('Very long y‑axis label that needs space')

   # Add a colorbar to the first axis
   im = axs[0].scatter(x, y, c=x)
   fig.colorbar(im, ax=axs[0], label='Colorbar label')

   plt.savefig('test_constrained.png', dpi=150)
   plt.close()


   Run the script twice: once with layout='constrained' and once with the default layout (remove the argument). Compare the saved PNGs visually.

Fixes Tied to Findings

• Enable constrained_layout
  Replace manual subplots_adjust calls with either:
  • When creating subplots: plt.subplots(nrows, ncols, layout='constrained')
  • Or after figure creation: fig.set_layout_engine('constrained')
  This makes the solver reserve space for tick labels, axis labels, titles, and external artists.
• Properly attach colorbars and legends
  Use the ax= keyword so the layout engine knows which parent axes to shrink:

  fig.colorbar(im, ax=axs[0])
      fig.legend(axs, loc='outside upper center')


  If you must keep a colorbar without specifying ax=, manually increase padding:

  engine = fig.get_layout_engine()
  engine.set(w_pad=0.4, h_pad=0.4)  # adjust as needed


• Fine‑tune padding
  After enabling constrained_layout, adjust whitespace with the engine’s set method:

  fig.get_layout_engine().set(w_pad=0.2, h_pad=0.2, wspace=0.05, hspace=0.05)


  Values are in inches; increase if labels still touch, decrease to save space.
• Fallback to bbox_inches='tight'
  If you cannot change the layout engine (e.g., third‑party code), save with:

  plt.savefig('out.pdf', bbox_inches='tight')


  This trims excess whitespace but may still clip if the artist lies outside the figure bounding box; use only as a last resort.

Escalation Criteria

If the above steps do not resolve the issue, consider:

• Incompatible GridSpec constraints – constrained_layout cannot satisfy contradictory height/width ratios. In such cases, manually compute positions with fig.add_axes([left, bottom, width, height]) or use GridSpec with explicit height_ratios and width_ratios.
• Artists added after the draw call – any artist created after fig.canvas.draw() (or after saving) is not seen by the layout engine. Ensure all annotations, colorbars, and legends are added before the first draw or save.
• Animation or interactive resizing – constrained_layout runs at draw time, so temporary overlap may appear during rapid resizing. This is expected; you can disable the engine for the animation loop if needed.
• If you suspect a bug, create a minimal, self‑contained script that reproduces the problem and file an issue on the Matplotlib repository, including the output of matplotlib.__version__ and fig.get_layout_engine().

Verification

After applying a fix, verify the result by:

1. Re‑running the minimal reproducer and visually inspecting the saved file.
2. Printing the active layout engine and padding values:

   print('Engine:', fig.get_layout_engine())
   print('Padding:', fig.get_layout_engine().get_w_pad(), fig.get_layout_engine().get_h_pad())


3. Checking that no tight_layout or subplots_adjust calls remain in the execution path (you can temporarily add a print statement to detect them).
4. Running the script in a clean virtual environment or on another machine to rule out local rcParams or style‑sheet interference.

---

Note: constrained_layout and tight_layout are mutually exclusive; calling both leads to undefined behavior. Always pick one layout strategy per figure.
