Diagnosing OpenSSL TLS Certificate Verification Failures: A Practical Checklist

Problem: TLS Handshake Failures with OpenSSL

When a client or library that uses OpenSSL cannot establish a secure connection, the most common symptom is a line in the console that looks like:

verify error:num=20:unable to get local issuer certificate

Other typical error numbers include num=10 (certificate expired), num=9 (certificate not yet valid), and num=19 (self‑signed certificate in chain). These messages appear both when using the command‑line tool openssl s_client and when a production application fails to connect.

Recognizable Conditions

• Missing intermediate – num=20
• Expired or not yet valid – num=10 / num=9
• Self‑signed in chain – num=19
• Hostname mismatch – no error code in s_client unless -verify_hostname is used
• Trust store mis‑configured – num=20 even with a complete chain

Root Causes & Diagnostic Table

Condition	Likely Cause	Quick Check
num=20	Missing or misordered intermediate certificate on the server	Inspect Certificate chain section in s_client -showcerts
num=10 / num=9	Certificate outside its validity window or wrong system clock	Check dates with openssl x509 -in cert.pem -noout -dates
num=19	Chain contains a self‑signed certificate that is not the root	Verify that every certificate except the last is signed by the next one
Hostname mismatch	Server presents a cert that does not match the SNI or the client’s expected hostname	Run s_client -servername host -verify_hostname host
num=20 (client side)	Client’s default CA bundle points to the wrong location or is empty	Run openssl version -d to see the default path

Ordered Checks

1. Capture the full handshake

   openssl s_client -connect example.com:443 -servername example.com -showcerts


   Look for the Verify return code line and the list of certificates.

2. Validate the chain depth

   openssl verify -CAfile /etc/ssl/certs/ca-certificates.crt -untrusted intermediates.pem server.pem


   Replace the paths with your CA bundle and the intermediate file you extracted from the s_client output.

3. Check each certificate’s dates and issuer linkage

   openssl x509 -in cert.pem -noout -dates -issuer -subject


   Do this for the server cert, each intermediate, and the root.

4. Confirm the trust store path and contents

   openssl version -a


   Verify that the listed OPENSSL_CONF or CApath points to a bundle that contains the expected root.

5. Test hostname verification

   openssl s_client -connect example.com:443 -servername example.com -verify_hostname example.com


   If this fails while the earlier run succeeded, the application’s hostname check is stricter.

6. Re‑run with the application’s TLS settings

   Use the same protocol version and cipher suite constraints as the application (e.g., -tls1_2 or -cipher).

Fixes Tied to Findings

• Missing intermediate – Deploy the full chain on the server. Most web servers accept a concatenated file of server cert followed by intermediates.
• Expired or not yet valid – Renew the certificate or adjust the system clock.
• Self‑signed in chain – Remove the self‑signed cert from the chain or replace it with the proper intermediate.
• Hostname mismatch – Configure the server to present a cert whose Common Name (CN) or Subject Alternative Name (SAN) matches the requested hostname.
• Trust store mis‑configured – Point the client to the correct CA bundle with -CAfile or -CApath, or install the bundle in the default location.
• Protocol or cipher mismatch – Update the server or client to support the same TLS version and cipher suites.

Escalation Criteria

• Failure occurs only with a specific TLS version or cipher suite – investigate policy or legacy algorithm support.
• Private or internal CAs are involved – verify cross‑signing chains and that the client trusts the intermediate.
• Packet capture shows the handshake aborting before the server sends the certificate – suspect a middlebox or firewall interfering.
• All local checks pass but the application still fails – review application‑level pinning or custom verification callbacks.

Concrete Example: Fixing a Missing Intermediate

Assume example.com returns num=20 when connecting with s_client. The output shows only the server certificate:

-----BEGIN CERTIFICATE-----
MIID... (server cert)
-----END CERTIFICATE-----

Steps:

1. Download the intermediate from the CA’s website or extract it from the s_client output if present further down.

2. Create a file chain.pem containing the server cert followed by the intermediate:

   cat server.pem intermediate.pem > chain.pem


3. Configure the web server (e.g., Apache SSLCertificateFile and SSLCertificateChainFile) to use chain.pem.

4. Restart the server and re‑run:

   openssl s_client -connect example.com:443 -servername example.com -showcerts


   The last line should now read Verify return code: 0 (ok).

Limitations & Practical Verification

• OpenSSL 3.x disables legacy algorithms by default; a SHA‑1 cert may fail on 3.x but succeed on 1.1.1.
• Different distributions ship different CA bundle paths; always confirm the path with openssl version -a.
• Application code may perform additional checks (pinning, custom callbacks) that s_client does not emulate.
• Time‑based errors can be caused by client clock skew; verify with date and ntpdate or equivalent.

Key Takeaways

• Start with s_client -showcerts to see the exact chain presented by the server.
• Use openssl verify to validate the chain against the intended trust store.
• Check dates and issuer links for each certificate; an expired cert or a self‑signed intermediate is a common culprit.
• Confirm the client’s CA bundle path; a missing or empty bundle produces the same num=20 error.
• Escalate only when the failure is isolated to particular TLS versions, private CAs, or network interference.
