GitHub Actions Runner Offline Diagnosis

A step‑by‑step guide to identify why a self‑hosted runner shows as offline and how to restore it.

Recognizable condition

In the repository or organization settings under Settings → Actions → Runners, a self‑hosted runner appears as Offline or never picks up jobs, even though the host machine is reachable.

Short cause/diagnostic table

Observed symptom	Likely cause
Runner service not active	Service crashed, failed to start, or was stopped
Runner process runs but no jobs	Outbound traffic to GitHub blocked (firewall, proxy, DNS)
Runner reports version mismatch	Out‑of‑date runner binary
Registration fails with token error	Expired, revoked, or insufficient‑scope token
Runner stays busy after a job	Long‑running step or infinite loop preventing new work

Ordered checks

Verify the runner service status
On Linux:
```
sudo systemctl status actions.runner.*
```
Look for active (running). On Windows, open Services MMC, find the GitHub Actions Runner service and confirm its state is Running.

Required permission: root/sudo on Linux or Administrator on Windows.

Risk: Restarting the service will interrupt any job currently executing on that runner.
Test outbound connectivity to GitHub services
From the runner host, run:
```
curl -v https://github.com
curl -v https://pipelines.actions.githubusercontent.com
```
On Windows PowerShell:
```
Test-NetConnection -ComputerName github.com -Port 443
Test-NetConnection -ComputerName pipelines.actions.githubusercontent.com -Port 443
```
Expect a TLS handshake and an HTTP 200 response (or equivalent TCP success). If the connection times out or fails, investigate firewall rules, proxy settings, or DNS resolution.

Required permission: none beyond normal user access to network tools.
Check the runner application version
Navigate to the runner directory (e.g., /home/user/actions-runner) and run:
```
./config.sh --version
```
Compare the printed version with the latest release listed on GitHub Actions runner releases. A significant lag (more than one minor version) may cause registration failures.

Required permission: read access to the runner directory.
Validate the authentication token
Attempt to re‑register the runner in interactive mode (do not use --unattended) to see if the token is accepted:
```
./config.sh --url  --token <TOKEN>
```
If the script prompts for errors such as Bad credentials or Missing required scope, the token is invalid or lacks admin:repo (for repository‑level runners) or admin:org (for organization‑level runners).

Required permission: ability to create a new token with the appropriate scope in GitHub.

Risk: Exposing the token in terminal output; ensure the screen is not shared and rotate the token if leakage is suspected.
Look for a stuck job
Check the runner’s internal logs:
```
cat /home/user/actions-runner/_diag/*.log
```
or on Windows:
```
Get-Content C:\actions-runner\_diag\*.log
```
Search for patterns like Running step without a subsequent Step completed or evidence of an infinite loop. If a job appears to be hanging, you can safely stop the runner service, which will terminate the process, then restart it.

Required permission: same as service control.

Risk: Stopping the service aborts the current job; ensure it is safe to do so (e.g., the job is not holding external resources that need cleanup).

Fixes tied to findings

Service not running:
```
sudo systemctl restart actions.runner.*
```
(on Windows: restart the service via Services MMC). After restart, refresh the runner page; it should show Online within a minute.
Network blocked:
Adjust outbound firewall rules to allow TCP 443 to github.com and pipelines.actions.githubusercontent.com. If a proxy is required, set HTTP_PROXY and HTTPS_PROXY environment variables for the runner service or configure the proxy in the runner’s .Runner file. Verify connectivity again with the curl or Test-NetConnection commands.
Outdated runner:
Download the latest runner binary for your OS/architecture from the releases page, extract it into a new directory, and run config.sh (or config.cmd) with the existing URL and token. Do not overwrite the existing directory while the service is running; stop the service first, then replace the binaries.
Invalid token:
Generate a new token with the required scope (admin:repo for a repository runner, admin:org for an organization runner). In the runner directory, run ./config.sh --remove to unregister the old runner, then ./config.sh --url <URL> --token <NEW_TOKEN> to register again. Start the service afterward.
Stuck job:
Stop the runner service, verify that no critical processes remain (ps -ef | grep Runner.Listener on Linux, or Task Manager on Windows), then start the service again. The runner will appear online and be ready to accept new jobs.

Escalation criteria

If after performing all checks and applying the corresponding fix the runner still shows as Offline:

Collect the runner’s diagnostic logs (_diag folder) and the system logs (journalctl -u actions.runner.* on Linux, or Event Viewer → Windows Logs → Application on Windows).
Verify that the host’s system time is synchronized (NTP); a large clock skew can cause TLS handshake failures.
Open a support ticket with GitHub Support, providing the logs, runner version, host OS details, and a summary of the steps already taken.

Limitations and practical verification

This guide assumes a standard self‑hosted runner installed via the official actions/runner binary. Custom wrappers or containerized runners may require additional steps (e.g., checking container network mode).

To confirm that the runner is truly operational after a fix:

Refresh the repository’s runner settings page; the status should change to Online.
Trigger a minimal workflow (e.g., a job that runs echo hello) and verify that the job is picked up and completes successfully.
Check the runner’s own log for a line similar to Listening for Jobs followed by Job received when the test workflow runs.
